Mercoframes Optical Corp Volk iNview Quick Start Manual

5. Move the Volk iNview Retinal Imager towards
the patient keeping the red reflex centered
on the display.
6. When the red reflex fills the Primary Imaging
View, stabilize device as the auto-acquisition
capability begins to acquire and save retinal
images (indicated by momentary flash of the
screen and/or audible capture sound).
7. After auto-acquisitions starts to occur, image
memory will quickly fill with up to 9 aligned
and focused retinal images.
8. At the user's discretion, user-snapped
images can be obtained by touching the
retina image .
C
H
9. Select Complete Examination from the
Main Program Display.
10. Press on the Image Display Section C
view gallery of taken images.
7. Quick image
Pressing the Quick Image button F
an imaging session and provide the user with a
quick way to conduct an imaging session. The
images that are stored during a Quick Image
session have no patient information attached
and should not be used where image retention
is required.
8. Data Export
The Volk iNview application supports sharing
images within the image gallery and export to a
PC via iTunes.
See the Volk iNview Instructions for Use for Data
Export instructions.
Quick Tips
• Don't worry if the camera is capturing
images that are clearly not retina as you
move into the eye. These will be overwritten
by retina shots once the retina is visualized
on the screen.
• Practice makes perfect. The more you
use the iNview the quicker you will be able
to capture images. This keeps patient
discomfort to a minimum.
• Use the hand nearest the patient's forehead
to control the pupil centration (it can be tricky
to get right at first). The rear hand on the
phone should be used only to steady the
device.
Futher instructions
to
Full instructions for use can be found on the
volk website. For best results with your new
Volk iNview visit www.volk.com/inview and read
the Instructions for Use.
Q u i c k
This Quick Start Guide provides instruction to start up and
will start
For full instructions refer to the Volk iNivew IFU on the Volk website.
s t a r t g u i d e
begin imaging with the Volk iNview retinal imager.
®
