- Page 1 INSTRUCTION MODEL: GL-1 1,000-Lbs. Capacity Equipment Lift GOLF-LIFT 2950 S.E. LOOP 820 FORT WORTH, TX 76140 TOLL FREE: 800-788-9789 WWW.GOLF-LIFT.COM...
- Page 2 2. In case of freight damage, call the truck line immediately and report the damage as a freight claim. Final Set-Up for model GL-1 This lift is more than 90% factory pre-assembled. The following steps will guide you through the final set-up.
- Page 3 Disconnect the air pressure when lift is not attended by qualified persons. 5. Install the approach ramp by dropping it into the holes punched on the rear edge of the table. The final Set-Up for the GL-1 model is complete...
- Page 4 8. Drop the ramps for the side extensions in place as shown above. 9. Run the Stabilizing tube through the square tube in the bottom of the lift. Secure it with screws supplied (parts # 64) The final Set-Up for the GL-1 model is complete...
- Page 6 Item Part Number Description AL-1000G Scissor A-Outside AL-2000G Scissor B-Inside AL-3000 Lift Table-Motorcycle lift (only) AL-4000 Lock Bar AL-5202 Center,Approach Ramp B AL-5400 Vise Clamp Handle-Assy AL-5302 Vise,Moving Jaw-Assy AL-5301 Vise,Stationary Jaw AL-5604 Wheel Stop B10-8×20 Bolt M8×20 B40-8 Lock Washer Ø8...
- Page 7 B30-8 Nut M8 B27-10×20 ‘Tie Down’’ Eye Bolt M10×20 B41-10 Flat Washer Ø10 B30-10 Nut M10 B85-6 Grease Zerk M6 B52-3×30 Cotter Pin Ø3×30 B53-12×45 Pin(B) Ø12×45 AL-4004 Plastic Grip/Safety Release AL-5303 Moveable Vise Extension B41-10 Flat Washer Ø10 AL-6006 Bearing/Cylinder AL-6010 Spacer...
