Seneca Z-FLOWCOMPUTER Installation Manual

Computer for the calculation of flow and energy of liquids, gases and steam

Advertisement

Quick Links

Z-FLOWCOMPUTER / Z-FLOWCOMPUTER-B
Computer for the calculation of flow and energy of liquids, gases and steam
CONTENTS:
PRELIMINARY WARNINGS .............. 2
INSTRUCTIONS ................................. 2
GENERAL FEATURES ....................... 2
INSTALLATION RULES ..................... 4
SIGNALS VIA LED ON FRONT
PANELErrore. Il segnalibro non è definito.
ACCESSORIES .................................. 7
DISPOSAL .......................................... 8
Manufacturer
Website
Mail
This document is the property of SENECA srl. Unauthorized duplication and reproduction is
strictly forbidden. The content of this document corresponds to the described products and
technologies. Stated data may be modified or supplemented for technical and/or sales
purposes.
INSTALLATION MANUAL










MI003722-E
Registered office: Via Austria 26
35127 - Z.I. - Padua - I
Tel. +39.049.8705355 - 8705355
Technical support:
Product information:
Seneca srl
Fax +39 049.8706287
www.seneca.it
support@seneca.it
sales@seneca.it
ENGLISH 1/8
