DSP Starter Kit (DSK) for the TMS320C6416T (1 GHz)
C6416 DSK Board
C6416 DSK Code Composer
Studio CD ROM
System Requirements
•
500MB of free hard disk space
•
Microsoft Windows™ 2000/XP
•
128MB of RAM
•
16-bit color display
•
CD-ROM Drive
Service and Support
Web
http://support.spectrumdigital.com
E-Mail
support@spectrumdigital.com
12502 Exchange Dr., Ste 440, Stafford, TX. 77477
Downloaded from
Elcodis.com
electronic components distributor
Quick Start Installation Guide
Kit Contents
+5V Universal
Power Supply
TMS320C6416 DSK
Technical Reference
Description
The 6416 DSP Starter Kit (DSK) is an all-in-one evaluation
platform for the TMS320C6416T Digital Signal Processor
from Texas Instruments. It includes a target board that
can be used as a reference design for interfacing the DSP
to common devices such as SDRAM, Flash and a codec
as well as a special introductory version of TI's flagship
Code Composer Studio development tools. An on-board
JTAG emulator allows debug from Code Composer Studio
through your PC's USB port.
This kit contains everything you need to get started with TI
DSPs. It can also be used with the full version of Code
Composer Studio and an external JTAG emulator.
508036-4001A
T:281.494.4505, F:281.494.5310
AC Power
Cord
USB Cable
