Summary of Contents for EnPointe Piste Box EP-G01
- Page 1 Piste Box (EP-G01) User Manual...
-
Page 2: Table Of Contents
The EnPointe Wireless Fencing System The Piste Box Updating your Wireless System Batteries and Power Checking the Battery Level Replacing the Batteries Turning on/Switching off Cancelling Hits to a Metallic Piste Preparing the Piste Touching On the Piste Box Connecting the Wires... -
Page 3: The Piste Box
The Piste Box This Piste Box is designed to be used with the EnPointe Wireless Fencing System (EP-R01, EP-P01). The EnPointe Wireless Fencing System is not included in this set. This Piste Box, in conjunction with an EnPointe Wireless System and Scoring Machine, cancels hits to a metallic piste. -
Page 4: Updating Your Wireless System
5 of your original Wireless Fencing User Manual for more details. Please Note: If you purchased your EnPointe Wireless Fencing System after 20/12/2018, you will not need to install an update, as your system should come preloaded with the latest Piste Box firmware. -
Page 5: Batteries And Power | 3
Replacing the batteries: The Piste Box uses two (2) standard AAA batteries, and lasts for approximately 100 hours of continuous fencing, or around three months of regular club use. The Piste Box batteries can be replaced by pulling the lift tab shown in [D]. Turning on the Piste Box: Once a Piste Box is paired to a Relay Box, it will switch on with the rest of the system, and begin cancelling the piste immediately. -
Page 6: Cancelling Hits To A Metallic Piste | 4
Touch on the Piste Box first. This can be done by holding the Piste Box and using three fingers to touch pins [A], [B], and the EnPointe logo [C]. Hover the Piste Box over the centre of the Relay Box. The three green lights on the Relay Box will flash once to indicate the Piste Box has touched on. -
Page 7: Connecting The Wires
It can attach to either the piste’s existing grounding wire, or to the piste itself. Tape over the last 20cm of conductive tape with the insulation tape, making sure that the crocodile clip does not detach. EnPointe logo Connects to Connects conductive tape... -
Page 8: Tips And Troubleshooting
Tips and Troubleshooting Error Solution Hits are not being cancelled properly. Firstly check that the Piste Box has sufficient charge, and has not disconnected from the Relay Box. Then check the connections between piste>wire>box, and tape>wire>box. To help diagnose the issue, you can have the fencers test the wire/piste grounding screw or wire directly, to see if it’s a broken connection, or an issue with the... -
Page 9: Tips And Troubleshooting
The connectivity error lights This indicates that there is a wireless constantly flashing. connectivity issue between the Piste Box and the Relay Box, or the Pocket Boxes and the Relay Box. The Relay Box will attempt to reconnect, and the off-target lights will display if the box is disconnected for a long enough period of time that a hit could have occurred. - Page 10 If you prefer the Piste Box is not located To avoid a tripping hazard or for convenience, directly next to the piste. you can extend the connection of the tape loop, by attaching a length of conductive tape to the loop (as described above), and running the tape away from the fencing area to a place where the Piste Box can be safely placed.
-
Page 11: Faqs
Frequently Asked Questions (FAQs) Does my metallic piste need to be grounded, in order for the Piste Box to work? No. Both grounded and non-grounded pistes will be cancelled with a Piste Box attached. Where can I get more conductive tape? You can purchase conductive tape separately from our online shop. -
Page 12: Warranty And Disclaimer
For more information about how to designate your EnPointe Fencing System or Piste Box for recycling, please contact our customer services team on +613 9015 4441, or support@enpointefencing.com... -
Page 13: Safety Message
Disclaimer and Safety Message All our wireless fencing products have been designed for fencing under normal conditions, and to the FIE rules and scoring specifications. If fencers use the system under non-standard or unsafe fencing conditions (for example, not wearing shoes, or not wearing a glove on the weapon hand) we cannot guarantee the reliability of the system. -
Page 14: Compliance Information
CE Compliance Notice: The EnPointe Piste Box (EP-G01) meets the minimum requirements for safety and electromagnetic compatibility of electronic devices, and conforms with the relevant European Union directives and recommendations: Directive 2011/65/EU Directive 2014/53/EU Directive 2014/30/EU Council Recommendation 1999/519/EC of 12th July 1999 More information about our compliance, including the relevant harmonised standards, can be found in our declaration of conformity, available at enpointefencing.com/downloads.
