Summary of Contents for Shenzhen Haojiehua Technology eFollower H101
- Page 1 eFollower H101 PPT Presenter User’s Guide Support Windowsxp and MacOs 10.10 & above verisions...
- Page 2 H101 Features This guide describes how to use the eFollower PPT presenter H101 and run the operating software. Be sure that you read this guide and understand its contents before using it. 1. It is a wireless presenter with a display digitron and vibrating motor, plus the somatic mouse function.
- Page 3 I. H101 Operation Steps Step 1: Pull-out Receiver From Presenter There is a build-in receiver on the back of presenter H101. Please pull it out before using. Step 2: Insert The Receiver Into The USB Port Of The Computer Only one side of the receiver can be inserted into the USB port of the computer. Step 3: The Receiver Establish Connection With The Computer After the receiver is inserted into the USB port, it needs to establish a connection with the computer.
- Page 4 Step 5: Install The Computer-Aided Software 5.1 Install The Software On Windows System Considering many users often change their speech computers. We made the Windows version software as green software, i.e., it need not be pre-installed before using. You can double-click the application icon (. exe file) to run it.
- Page 5 Step 6: Run The Computer Aided Software 6.1 Run Software On Windows System Double click to run the executable file(eFollowerPresenterH101.exe or eFollowerPresenterH101_xp.exe) of corresponding version. 6.1.1 Where Is The Software After Starting After the program is running, the welcome window appears for 2 seconds , and then disappear. Actually, the program did not stop.
- Page 6 A) Click “Finder ”, ”Applications”. And find the icon of eFollowerPresenterH101。 B) Press and hold the key “control”, and Click the icon” eFollowerPresenterH101”. Select "open" menu after the prompt window is popped up. C) Click the “Open” button. 6.2.2 Pop-up Window “enable accessibility access” Appears This step is the requirement of PresenterH101.
- Page 7 1) Click ”Later” that runs the software for this time。However, this pop-up window will appear for every run. 2) Click “OK” and the following pop-up window appears 1) Click the bottom part to unlock (need to enter the login password). 2) Select the check box before eFollowerPresenterH101 icon.
- Page 8 If the presenter is not turned on or the receiver has not been inserted into USB port, the icon is B) When the icon is , clicking the icon will prompt you to insert the receiver or turn on the presenter.
-
Page 9: Scene Settings
II. H101 Software Functions When working, click the icon of task bar to open the settings window。 1. Overviews: 2. Scene Settings Spotlight Mode: The background brightness can be adjusted by H101 software. And whether the mouse pointer icon is displayed or not is selectable. Digi-Laser Mode: The color of the digital laser can be adjusted. -
Page 10: Alarm Timer
5. Anti-lost After the wireless is disconnected for 20 seconds (the presenter is off), the computer will play a sound to prompt you to remove the receiver if the receiver is still plugged. (default：function closed ) 6. Alarm timer Set the alarm timer (maximum: 199 minutes) in spotlight setting window. When meeting timer is up, the H101 presenter will vibrate to alert you. - Page 11 III. H101 Presentor Functions 1. H101 Key Descriptions Click: press the left mouse button and lift it immediately Long-press: press and hold for at least a second. 2. Combination Keys 2.1 Reduce The Aperture Press and hold key③for one second and then press the key① simultaneously to reduce the aperture. 2.2 Increase The Aperture Press and hold key③...
-
Page 12: Other Functions
3. Other Functions 3.1 After Startup Open the H101 presenter to show the remaining time of alarm timer. If the timer is not set, "0" will be displayed. When displaying " " and flashing for three seconds it means the voltage of the battery is low. - Page 13 ” sign disappears. It shows the calibration is successful. Note: During gyro sensor recalibration, H101 presentor cannot be placed on a shaking or slightly vibrating table. Shenzhen Haojiehua Technology Co.,Ltd Room B1-619,Huayuan science and technology park, Bao Yuan Road, Baoan District, Shenzhen, Guangdong, China...
- Page 14 Technical Support： support@haojiehua.com...
- Page 15 FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
