Summary of Contents for AGP EV10ELM
- Page 1 Original instructions...
- Page 2 31+32...
-
Page 3: General Safety Instructions
Technical Data Power Input 1100W See machine nameplate Voltage 12.6 Number of Gears No-Load-Speed min 0-750 Amperes (110V) Amperes (220V) Protection / Class of Protection Double Insulation / II Thread for fixing the Tool Mixing Paddle (Ø max.) 120 mm Weight 4.9 kg GENERAL SAFETY INSTRUCTIONS... -
Page 4: Personal Safety
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. - Page 5 power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools.
- Page 6 Safety Precautions Safe operation of this machine is possible only when the operating instructions and the • safety precautions are read completely and the instructions contained therein are strictly observed. For further notes on safety refer to enclosed Sheet. • The machine is not qualified for operation in environments where danger of explosion •...
- Page 7 Starting Operation and Use Check if the data on the nameplate is corresponding with the actual mains voltage. Improper use may damage the Instrument. Observe therefore these Instructions: Use just mixing paddles up to the specified diameter. • Load the instrument in such a way that the speed would not drop considerably or that it •...
- Page 8 motor housing 25) should be cleaned out. After approx. 100 hours of operation, check the motor brushes and replace if necessary. • Clean the motor housing. After approx. 200 hours of operation, renew the grease filling in the gearbox. • To verify that the protective insulation remains intact, the machine must be subjected to a technical safety test afterwards.
- Page 9 WIRING...
-
Page 10: Exploded View
EXPLODED VIEW... -
Page 11: Parts List
PARTS LIST Parts Name Q'TY Parts Name Q'TY SPINDLE (M14xP2.0) BRUSH CAP (7x11) PARALLEL KEY (5x5x12) OIL SEAL (Ø22xØ32x7) PANHEAD TAPPING SCREW-B (M5x20) PANHEAD TAPPING SCREW (M5x45) HANDLE HALF-RIGHT GEAR HOUSING 31.1 HANDLE HALF-LEFT NEEDLE BEARING (HK 1010) FRONT HANDLE BALL BEARING (6003) 32.1 HANDLE BRACKET...
