Summary of Contents for MAX-EZ EZ-ACD2AL
- Page 1 EZ-ACD2AL S/PDIF Digital to Stereo Analog Audio Converter USER MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS MAX-EZ DISCLAIMERS.......................02 IMPORTANT SAFETY INSTRUCTION..............03 INTRODUCTION......................04 FEATURES........................04 PACKAGE CONTENTS....................05 PANEL..........................06 INSTALLATION......................07 SPECIFICATION......................08 TROUBLESHOOTING....................08 WWW.MAX-EZ.COM... -
Page 4: Disclaimers
The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from a MAX-EZ Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly or against instructions on User Manual. -
Page 5: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTIONS MAX-EZ Do not expose this apparatus to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus. Do not install or place this unit in a bookcase, built-in cabinet or in another confined space. -
Page 6: Introduction
MAX-EZ INTRODUCTION The EZ-ACD2AL is a high-performance S/PDIF digital to stereo analog audio format converter. The unit converts S/PDIF Coaxial or TOSLINK digital audio signal to stereo R/L RCA and headphone analog audio signals. FEATURES Digital to Analog: • Converts Coaxial or TOSLINK digital audio signal (PCM) to stereo analog audio signal. -
Page 7: Package Contents
PACKAGE CONTENTS MAX-EZ Before you start the installation of the product, please check the package contents: 1 x EZ-ACD2AL 1 x DC5V 0.3A Power Adapter 1 x User Manual WWW.MAX-EZ.COM... -
Page 8: Panel
TOSLINK IN audio source Coaxial digital stereo input,connects to an audio COAX IN source ON:EZ-ACD2AL is powered on. POWER LED OFF:EZ-ACD2AL is powered off. POWER PORT Connects to a DC5V pewer supply. L/R OUT Analog stereo output,connects to a speakers. -
Page 9: Installation
INSTALLATION MAX-EZ Before wiring disconnect the power supplies of all the devices. To wire EZ-ACD2AL : Connect an Audio source device to the TOSLINK IN port via a Optical fiber cable. Connect an Audio source device to the COAX IN port via a digital audio cable. -
Page 10: Specification
SPECIFICATION MAX-EZ Technical 1 x digital audio (S/PDIF TOSLINK) Inputs 1 x digital audio (S/PDIF Coaxial) 1 x analog R/L (RCA connector) Outputs 1 x analog headphone (3.5mm mini jack) Supported Sampling Rates 32KHz/ 44.1KHz/ 48KHz/ 96KHz Resolution Up to 24bit... - Page 12 MAX-EZ M a k e I t E a s y MAX-EZ ELECTRONICS CO., LTD. WWW.MAX-EZ.COM...
