- Page 1 FIRETRACE ® AUTOMATIC FIRE SUPPRESSION SYSTEMS Operating Manual: Firetrace Indirect Low ® Pressure Integrated High Throughput Bi-Directional Fire Suppression System for Engine Compartment Please read this manual thoroughly before carrying out the installation of this system Firetrace systems shall only be installed by trained engineers...
-
Page 2: Table Of Contents
Cylinder/Valve and Bracket Assemblies_______________________ 7 Discharge Piping and Nozzles_______________________________ 8 Discharge Line Tees and Angles_____________________________ 8 Firetrace Detection/Actuation/Discharge Tubing_______________ 9-10 Connecting the Firetrace® Tubing onto Fittings________________ 11 Commissioning Instructions________________________________ 12 Service and Maintenance Instructions_____________________________ 13 Service and Maintenance for ABC Dry Chemical Systems__________ 13... -
Page 3: Introduction
1 - Introduction This manual is written for the fire protection professional that designs, installs and maintains Firetrace Ltd Indirect Low Pressure Integrated High-Throughput Bi-Directional system, this system must be designed, installed, inspected, tested, maintained, and recharged by a competent and trained engineer. -
Page 4: System Overview
(SIMI). The integrated ball valve must be kept in closed position at all times when the cylinder is not in service. The system utilizes Firetrace flexible tubing that is attached to the top of the cylinder valve. This tubing is pressurised with nitrogen to maintain the cylinder valve in the closed position. -
Page 5: Abc Dry Chemical Extinguishing Agent
Firetrace® FTILPINTHTBI Systems consist of the following major components: 1. Cylinder/Valve Assembly 2. Cylinder Mounting Bracket 3. Firetrace detection/actuating/discharge tubing and fittings 4. Discharge Nozzles 5. Pressure Switch (Optional) 6. Discharge piping and Fittings For a more comprehensive list of technical illustrations and part numbers, please see section 6. -
Page 6: System Design And Limitations
The normal operating pressure for Firetrace® Systems is 12bar at 20°C (174psig at 68°F). All Firetrace® systems are designed for an operating temperature range of -20°C to +60°C. Table 1 shows the cylinder gauge pressure-temperature relationship based on a charging pressure of 12bar at 20°C. -
Page 7: Nozzle And Discharge Pipe Requirements
Intermittent Temp: 40°C to 140°C (-40°F to 284°F) Firetrace Detection/Actuating/Discharge Tubing For the FTILPINTHTBI System, the Firetrace® tubing is used as a combination for heat detection, system activation and system discharge. The detection/actuation/discharge tubing is heat sensitive and in a fire situation is designed to rupture at any point along the tube upon direct flame impingement or at high temperatures associated with fire conditions. -
Page 8: Firetrace Installation Instructions
Where vertical positioning is not possible the system can be mounted within 45° of vertical. Firetrace Dry Powder Systems are not suitable for horizontal mounting 1. Securely mount the cylinder bracket to structural support using 4 or more mounting holes. -
Page 9: Discharge Piping And Nozzles
Discharge Piping and Nozzles 1. It is advised that a risk assessment is be carried out to determine appropriate discharge pipework and nozzle positioning. 2. Locate the nozzle(s) placement once a risk assessment has been carried out, ensuring design is within limitations and guidelines described in section 3. -
Page 10: Firetrace Detection/Actuation/Discharge Tubing
Firetrace® Detection/Actuation/Discharge Tubing The Firetrace® Automatic Detection tubing is the key part of the system and acts not only as the detector, actuator but also as the delivery method for a percentage of the ABC Powder. The correct installation of the tubing is important to achieve optimum performance from the system. The tubing must be mechanically protected outside the identified risk area and shall remain accessible to allow future servicing. - Page 11 The following models show both “Tyrap” and “P clip” methods of fixing all of which are acceptable: 8mm Firetrace Tubing shall be supported at maximum intervals of 200mm When the tubing is installed with a group of other cables/pipes it must be positioned on the underside of the loom...
-
Page 12: Connecting The Firetrace® Tubing Onto Fittings
5. Undo the nut and inspect the end to ensure the flare has formed correctly. The tubing is now ready to be connected to the system. Visual representation of ideal flare. For a more comprehensive list of Firetrace® Tube Fittings, refer to section 6 Page | 11... -
Page 13: Commissioning Instructions
Install detection tubing, discharge pipework and any accessories according to the procedure in section 4. Remove black transportation cap from the top of the cylinder. Connect the Firetrace® detection tubing to the top of the cylinder valve, tighten spring nut/nut using the appropriate sized spanner then secure the Firetrace®... -
Page 14: Service And Maintenance Instructions
Service and Maintenance for ABC Dry Chemical Systems The Firetrace® systems can operate in a harsh environment and are occasionally subjected to high temperatures and extreme vibration. It is essential that the systems are regularly serviced to ensure their correct operation. -
Page 15: System Component List
Integrated Bi-Directional Valve FT0438/6-HT Diptube High-Throughput 426mm White FT0133-P Steel Cylinder 6kg/Litre with ABC Powder FT0150 6kg Bracket with Stainless Steel Strap FTILPINTHTBI/8 ILP High-Throughput Bi-Directional M18x1 Plug FT1511-8/6-1/8-S 1/8” BSP Fitting for 8mm FT0322/8 Plastic Black Cap for 8mm FTSIMI... -
Page 16: Detection Line Parts List
Detection Line Parts List PART NUMBER DESCRIPTION FT1511-8/6-1/8S Male-Tube/Trace 8mm Trace 1/8” Male – 8mm Special FT1723-8/6-SS Anti-Kink Spring Nut 8mm Stainless Steel FT0269/1/M Banjo Tee Assembly for Valve Male FT0118/8 End of Line – 12bar 8mm (optional) FT0253/8 8mm Blank/Stop End FT1723-8/6-SS FT1511-8/6-1/8-S FT0253/8... -
Page 17: Discharge Line Parts List
Discharge Line Parts List PART NUMBER DESCRIPTION FTILPINTHTBI/8 ILP High-Throughput Bi-Directional M18x1 Plug FT0284/HT High-Throughput Diffuser 3/8” BSP FTILPINTHTBI/11 ILP High-Throughput Bi-Directional Valve M18x1 – 3/8” Adapter FT0260/11 1m 3/8” Flexi Hose 90° Female to Straight Female FT0260/12 3m 3/8” Flexi Hose 90° Female to Straight Female FT0260/13 4m 3/8”... - Page 18 Page | 17...
- Page 19 Page | 18...
- Page 20 Page | 19...
- Page 21 Page | 20...
- Page 22 Page | 21...
- Page 23 Address: Unit 22, Knightsdale Road, Ipswich, Suffolk. IP1 4JJ Telephone: 01473 744090 Facsimile: 01473 744901 Email: info@firetrace.co.uk Website: www.firetrace.co.uk Twitter: @firetrace_uk Page | 22...
