SUBSINO HAPPYLAND Operation Manual

Interactive kiddie driving games
Hide thumbs
Table of Contents

Advertisement

Quick Links

HAPPYLAND
INTERACTIVE KIDDIE DRIVING GAMES
OPERATION GUIDE
NOTICE
In order to use this product safely and correctly; please must read in detail this
manual and understand fully operation method before using.
Please be sure to keep this manual in the specified place after you read, in order to
be able to use anytime.
© SUBSINO CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAPPYLAND and is the answer not in the manual?

Questions and answers

Summary of Contents for SUBSINO HAPPYLAND

  • Page 1 In order to use this product safely and correctly; please must read in detail this manual and understand fully operation method before using. Please be sure to keep this manual in the specified place after you read, in order to be able to use anytime. © SUBSINO CO.,LTD.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS ● ● IN BEGINNING ● Specification Notice of Safety ● Work according to the indication of this manual ● Dangerous degree ● About Graphic Presentation indication ● Handler ● Attention for Installation ● The attention of moving while carrying and fix of installation position ●...

  • Page 3: In Beginning

    IN BEGINNING Thank you very much for the purchase of HappyLand CO-Dream MI003. This manual regards owner, administrator and operator as the target, using for explanation the method of Safety installation, Operating, Maintenance, Inspection and movement and so on. Concerning the installation, management, maintenance, inspection and movement of this product, please read thoroughly this manual.

  • Page 4: Notice Of Safety

    1 Notice of Safety ● Work according to the indication of this manual The manual will explain to work and considering accident prevention. If not stated according to the manual and carry on the work, it will become the reason of the accident. The corporation includes not the reparations obligation to the third party and does not owe all responsibility in regard to the accident damage due to the inadequate handling which you do not follow the notice of this manual statement.

  • Page 5: Handler

    1 Notice of Safety ● Handler The parts changes, maintain, inspect and when abnormal must handle by maintenance worker or technician in the arcade/ game center only. Arcade’s maintenance worker: Arcade’s maintenance worker for has the service experience of amusement equipment and, management for the original owner of amusement machines, handle ordinarily for sets up &...
  • Page 6 1 Notice of Safety WARNING This product is for indoor use. Please do not install no matter what in the place where it is stated in the outside and description below. It becomes cause of accident and breakdown. Rain leakage place High Moisture place Near air conditioning and electric heater of heating system, high temperature difference place...

  • Page 7: The Attention Of Moving While Carrying And Fix Of Installation Position

    Notice of Safety WARNING While pulling out and inserting power plug, please don’t make absolutely the item which stated on description below. It becomes cause of the accident of electric shock and reason of the breakdown. The behavior which takes out and puts in the plug by the hand which gets wet. The behavior which pulls carelessly.

  • Page 8: Attention That Is Operated

    1 Notice of Safety ● Attention that is operated The case of handling this product, please pay attention to the below-mentioned point sufficiently. WARNING Please use this product in this country. When you use in the other country, it may becomes cause of accident and breakdown.

  • Page 9: Attention While Maintenance

    1 Notice of Safety ● Attention while maintenance The case of maintain this product; please pay attention to the below-mentioned point sufficiently. WARNING Please be sure to turn off the power switch and to pull out the power plug from the electrical outlet before the job.

  • Page 10: About The Display

    1 Notice of Safety ● About the display The case of maintain this product; please pay attention to the below-mentioned point sufficiently. DANGER No matter what please do not touch inside monitor other than the service man (an electric knowledge, the repair experience person of the game machine). It becomes cause of fire and electric shock accident.

  • Page 11: Inspection After Movement

    2 Inspection after movement Usually, our product is normal and perfect situation in the factory; and you can use the product immediately after the carrying. But, the abnormality may cause on the carrying sometime, please inspect and verify the below-mentioned items before turning on power for it was carried in satisfactory state. Inspection contents Check 1.

  • Page 12: List Of The Accessory

    List of the accessory ● Operation manual (This manual) --------------------------------------- 1 ● Main Door key ------------------------------------------------------------ 1 ● Cash Box key ------------------------------------------------------------- 1 ● Rear Door key ------------------------------------------------------------ 1...

  • Page 13: Name Of Every Parts

    Name of every parts Top Sign FRP Front Plate LCD Monitor Steering Wheel Start Button Speaker Coin Validator Main Door Lock/ Key Stand LCD Monitor PC Board Rear Door Lock/ Key Speaker AC Power Cable Inversion Prevention Plate Wheel (Please release the plate to the ground and fix it after installation)
  • Page 14 Name of every parts Volume Control Test/Setup/Book Button Coin Meter Power Switch Cash Box Cash Box Lock/ Key...

  • Page 15: Explanation Of Operation

    Explanation of Operation ● Introduction of Games Introducing a video-based, kiddies driving game with exciting interactive features. This three-minute game features a continuous, animated Attract Mode that will thrill children while assuring parents that their kids are in good hands. This driving game features a colorful, friendly story about a little girl that takes a ride through the neighborhood.

  • Page 16: Control Panel

    Explanation of Operation ● Control Panel ► Steering Wheel (1) Drive and turn directions when playing. (2) Select the setup item in Setup mode. ► Play Button (1) Change the action of Car or Plane or other main role when playing. (2) Change the setup value in Setup mode.
  • Page 17 Explanation of Operation Drive the Steering Wheel to select the item; Press Play Button (in the right of control panel) to adjust the value, which will show immediately. Drive the Steering Wheel to EXIT item and press Play Button to exit and back to Main screen. New value you adjusted would available instantly after EXIT.

  • Page 18: Check Regularly

    Check regularly ● Exchange of button lamp WARNING Please be sure to turn off the power switch and pull out the power plug from the electrical outlet before working. It becomes cause of electric shock and breakdown. Please use the designated rated Light Bulb. If use different rated Light Bulb, it becomes cause of fire and breakdown.

  • Page 19: Troubleshooting

    Troubleshooting WARNING Before troubleshooting, please turn off power switch. It becomes cause of electric shock and short accident. ● Error Message When error occurs in the machine, error message is indicated on the screen. Please comply with the handle method of error message. MESSAGE DESCRIPTION System Error...

  • Page 20: Adjustment Of Coin Selector

    7 Troubleshooting ● Adjustment of Coin Selector When reading Coins/ Tokens with wrong, please do the adjustment of Coin Selector. The Coin Selector of this machine used the electronic Coin Selector. Please adjust the sensitivity of Coins/ Tokens. a. Open the door of main cabinet. Insert Coin/ Token b.

  • Page 21: Connection Of Machine

    8 Connection of Machine ● Connection Pin Assignment of Game PC Board PARTS SIDE SOLDER SIDE +12V +12V COIN COUNTER FUNCTION LAMP MOTOR CONTROL SPEAKER (+) SPEAKER GND VIDEO RED VIDEO GREEN VIDEO BLUE VIDEO SYNC VIDEO GND SETUP/BOOK COIN SW WHEEL - SENSOR 1 WHEEL - SENSOR 0 PLAY BUTTON...

  • Page 22: Connection Diagram Of Equipment

    7 Connection of Machine ● Connection Diagram of Equipment Sensor 0 Sensor 1 Steering Wheel Wheel Sensor +12V PCB. Lamp Out BUTTON Play Button (With Lamp) PCB. Button Out Any +12V in the pin Counter Counter PCB. Counter Out...
