Coleman BRITE 085-2314-0 Manual

PARTS

3
2
8
6
7
1

BATTERY INSTALLATION

1 2
3 4

MOUNTING THE BARBECUE LIGHT

1 2
3 4
Coleman_Brite manual_Dec4.indd 1
BRITE™ BARBECUE LIGHT
085-2314-0 | FL-4101C
1
Led Light
4
2
Multi-Directional Pivoting Head
3
High, Low, Off Button
4
Battery Compartment Cover
5
5
Battery Cradle
6
Handle Bracket
7
Mounting Screw
8
Bracket Cushions
1.
Turn the battery cover counter–clockwise
to remove.
2.
Remove battery cradle.
3.
Insert 3 NEW AA batteries according to polarity
indicators. Batteries sold separately.
NOTE: The negative "-" terminal should always
connect to the "spring" end of the cradle.
4.
Reposition the battery cradle into the handle,
and secure with the battery cover. Turn clockwise
until secure.
1.
Open the handle bracket by removing the
mounting screw.
2.
Place the handle bracket on your barbecue lid
handle as shown.
3.
Reconnect and tighten the mounting screw to
secure the handle bracket.
4.
Move the barbecue light up and down, or rotate
side to side, to adjust the angle of the light.
NOTE: Your BRITE™ BARBECUE LIGHT has been
shipped with two additional bracket cushions to
allow for the ideal fit.
ATTENTION: Do not mount Your BRITE™
BARBECUE LIGHT on a surface that can become
hot to the touch.
REMOVING & STORING YOUR BARBECUE LIGHT
•
DO unclip the barbecue light when storing the barbecue for long periods of time.
•
DO remove the batteries from the barbecue light compartment during storage periods.
•
DO avoid water and environmental damage by removing the barbecue light during harsh weather.

HOW TO USE

CARE AND MAINTENANCE

•
Wipe with a damp cloth to clean.
•
DO NOT use alcohol-based or harsh abrasives.
•
DO NOT submerge in water.
CAUTION!
Read and follow all safety statements, assembly instructions, and use and care directions before attempting to
operate product.
ATTENTION!
•
DO NOT operate the barbecue lights when the barbecue lid is closed.
•
DO NOT attempt to repair or alter the product for any assumed defect.
•
Batteries must be recycled or disposed of properly. Dispose of as per the requirements of your local
municipality.
•
DO replace all batteries at the same time."
•
DO NOT leave the batteries where a child or pet could play with or swallow them.
•
Take care when closing your barbecue lid.
•
Adjust the handle bracket to make sure that the barbecue light does not come in contact with the barbecue
lid or control panel.
©2019 The Coleman Company, Inc.
Coleman, and are registered trademarks of The Coleman Company, Inc., used under license.
The BRITE™ BARBECUE LIGHT
is equipped with a quick release
clip that allows easy removal
of the barbecue light, without
having to remove the bracket.
1.
Press the large red button to turn your
BRITE™ BARBECUE LIGHT to "HIGH".
2.
Press this button a second time for "LOW".
3.
Press a third time for "OFF".
Visit us online at www.colemanbbqs.com
