- Page 1 TMS1000 USER MANUAL Reference : MN0482 Release : Date : 2017-09-04 Tous droits réservés © TimeLink microsystems...
- Page 2 A3_EN 2017-09-05 New password associated with LO665A2 Name-Title Date and Signature Author Arnaud FERRARIS 2014-11-19 / AF Software Engineer - TimeLink microsystems Approve by Jean-Claude POUYTES 2014-11-21 / JCP Quality Manager - TimeLink microsystems Tous droits réservés © TimeLink microsystems...
-
Page 3: Table Of Contents
1.2. FUNCTIONAL CHARACTERISTICS ........................5 1.3. PHYSICAL CHARACTERISTICS ........................5 2. PREPARATION FOR USE 2.1. CONNECTIONS ............................. 6 2.2. CONFIGURATION ............................6 2.2.1. TMS1000 SETTINGS ..........................7 3. GETTING STARTED 3.1. POWERING UP ............................. 8 3.2. LEDS ................................8 3.2.1. LEDS AT STARTUP........................... 8 3.2.2. -
Page 4: General Description
Release: A3 Page: 4/18 GENERAL DESCRIPTION The TMS1000 is a GNSS disciplined NTP server. 1.1. FRONT AND BACK PANELS The front panel of the equipment includes the power supply connector, the GNSS antenna connector as well as the 1 PPS output. -
Page 5: Functional Characteristics
SubD 9 pins connector, 115200 bauds, 8bits, 1 stop bit SSH service Port TCP 22 HTTP service Port TCP 80 Remote monitoring UDP connections towards configurable IP/Ports TMS1000 functional characteristics 1.3. PHYSICAL CHARACTERISTICS The table below summarizes the physical characteristics of the equipment. Tous droits réservés © TimeLink microsystems... -
Page 6: Preparation For Use
SDCard inserted in the back of the equipment. The parameters available to the user are located in the "user.ini" file. This file is within the SDCard directory “TMS1000” when mounted using a PC, and within “/config” when accessed through remote access (console or network). -
Page 7: Tms1000 Settings
TMS1000 Reference : MN0482 Date : 2017-09-04 USER MANUAL Release: A3 Page: 7/18 2.2.1. TMS1000 SETTINGS These settings are located in the 'TMS1000/user.ini' file of the SDCARD. Section [NETWORK] Name Description Availability Default value Accepted values IP V4 address of the Mandatory 192.168.10.190... -
Page 8: Getting Started
‘IP:Port’ the UDP frame recipients values Note: other parameters in the “user.ini” file must not be modified without guidance from Timelink microsystems. Those parameters are listed right after the following warning: #-----------------------------------------------------------------------# # >>>> DO NOT MODIFY PARAMETERS UNDER THIS LINE <<<<... -
Page 9: Leds During Operations
Only the 'maintenance' user is authorized to connect to the equipment. After a successful connection, a shell is opened. Being a maintenance mode, the user must take care of its actions as they can result in the equipment no longer being able to serve its primary functions. Tous droits réservés © TimeLink microsystems... -
Page 10: System Software Update
restart or stop the equipment connect as 'root' The default password for both accounts is 'timelink'. 3.3.2.1. SYSTEM SOFTWARE UPDATE The system software update is done using the provided 'update' tool. See the Maintenance section for the procedure. -
Page 11: Http Server
USER MANUAL Release: A3 Page: 11/18 4.1. HTTP Server The integrated http server uses port 80. The following screenshots give a preview of the pages as they appear in a browser: Default screen GNSS screen Tous droits réservés © TimeLink microsystems... - Page 12 TMS1000 Reference : MN0482 Date : 2017-09-04 USER MANUAL Release: A3 Page: 12/18 Oscillator screen Actions screen Tous droits réservés © TimeLink microsystems...
-
Page 13: Manual Time Setting
Once the new date has been selected, click on the icon, on the bottom of the dialog, to be able to set the time: Tous droits réservés © TimeLink microsystems... -
Page 14: Udp Frame
The GNSS receiver status contains 3 fields separated by ':': Antenna status: connected ('C'), not connected ('N') or shorted ('S') Survey progress: value between 000 to 100 (000 may be a normal value if survey is disabled) Tous droits réservés © TimeLink microsystems... -
Page 15: Maintenance
Software update is done by using the provided tool: '/usr/bin/update'. Use it as follow: Copy on the SDCard the file(s) to update. Re-insert the SDCard and restart the equipment Open a shell by connecting with SSH or the Console Execute '/usr/bin/update' Tous droits réservés © TimeLink microsystems... -
Page 16: Software Update
The software update is made by storing the binary file contained in the 'update' directory of the SDcard in the FLASH memory of the processor module. If a new binary file is provided by Timelink microsystems, please copy it first in the SDCard in the /update directory. -
Page 17: Editing From An External System
Depending on the used text editor, verify than the encoding of the end of lines are in the UNIX format (only LF) and not in the WINDOWS format (CR + LF). A bad encoding will lead to an unreadable file in the equipment. Text editor 'Notepad++' is a good choice for updating configuration files. Tous droits réservés © TimeLink microsystems... - Page 18 MASK 255.255.255.0 Depends on equipment serial number 192.168.10.254 BROADCAST 192.168.10.255 NAMESERVER 8.8.8.8 [NTP_SERVER] ENABLE VERSION AUTO NOTIME NO_ANSWER [GPS] UTC_OFFSET [RM] PUSH_TO 192.168.10.191:9000 Password 'maintenance' timelink Password 'root' timelink *** End of document *** Tous droits réservés © TimeLink microsystems...
