Summary of Contents for Embention Veronte HCS
- Page 1 VERONTE HCS User Manual Embention 15/12/2017...
-
Page 2: Table Of Contents
1 Contenido Overview ..........................4 Typical applications ....................... 4 Package Content ......................5 Veronte HCS Parts ......................5 Radio communications ....................6 Connection ..........................7 Operation ..........................8 Battery Charge ....................... 8 Battery Characteristics ....................8 Operation ........................8 Good Practices and maintenance ..................10 Contact Information ...................... - Page 3 CHANGES RECORD Issue Date Change description 02/04/2016 Initial Issue document 20/12/2017 Operational information added 22/02/2018 Updated to the new version. 06/03/2018 Battery information added. VERONTE HCS 15/12/2017...
-
Page 4: Overview
2.1 Typical applications Veronte HCS is the main control station used to operate Veronte systems. This system is available in multiple configurations to fit each application requirements. Some of the main applications for the system are: •... -
Page 5: Package Content
2.2 Package Content Units Item Veronte HCS control station Veronte HCS charger 2.3 Veronte HCS Parts Main control station parts are described below for further reference. VERONTE HCS 15/12/2017... -
Page 6: Radio Communications
Moreover, the customer can ask Embention to internally integrate any communication systems that fulfils the final user country’s regulation. For operation within Spain, Embention recommends the use of 2.4 Ghz modems. If any other band is required, authorization from the regulatory authorities might be required. -
Page 7: Connection
Ethernet Amphenol: RJF6MB USB Male Amphenol: MS3116F12-10S Joystick Amphenol: MS3116F8-2S RF Antenna SMA Male Connector’s pinout is shown below (HCS front view). Please ask Embention for custom pinout configuration or custom wiring development. Power Joystick SIGNAL SIGNAL SIGNAL PPM- VERONTE... -
Page 8: Operation
Vmin:17.5V Limits can be selected in Veronte software Pipe in order to set up user alarms 4.3 Operation Veronte HCS is highly intuitive and easy to operate; main steps in order to operate the system are as follow: • Place the control station in a firm, dry surface and open the suitcase. - Page 9 The system can be connected to the internet by using the WIFI connection available on the system or the Ethernet port. VERONTE HCS 15/12/2017...
-
Page 10: Good Practices And Maintenance
5 Good Practices and maintenance Veronte HCS is not water resistant once opened. Please keep it in a dry space during the • operation. Do not use chemical cleaners for product maintenance; a damp cloth is enough to • perform the cleaning. -
Page 11: Contact Information
6 Contact Information You may contact Embention to ask for help related to its products. Contact can be done by phone, email or at our facilities: Phone number: (+34) 965 115 421 Email: embention@embention.com or support@embention.com Address: Polígono Industrial Las Atalayas, C/ Chelín, Nº 16, CP 03114, Alicante (España).
