Wolf WF-300 LED Floodlite
Operation and Maintenance Instructions
Please Retain – Read Before Use

EC Declaration of Conformity

The Wolf WF-300 LED Floodlite meets all relevant provisions of
the 94/9/EC (ATEX Equipment) Directive by virtue of the issued
EC Type Examination Certificate, demonstrating compliance
with all relevant Harmonised Standards and Essential Health
and Safety Requirements.
The Wolf WF-300 LED Floodlite is a high performance
lightweight portable floodlight. Constructed in marine grade
aluminium, with a polycarbonate lens: the end user must check
that these materials are suitable for the atmosphere the Floodlite
will be used in. The Floodlite can be used in Zone 1 and Zone 2
potentially explosive gas, vapour, mist and dust atmospheres
where the surface temperature / temperature class and gas
group permit.
High Voltage (HV) 100-254V AC +/- 10%
II 2GD Ex emb IIC T4 Gb (Ta = -20
o
Ex t IIIC T103
C Db IP66 & IP67.
The incoming mains cable should not exceed a temperature rise
o
of 61
C above the ambient conditions; select suitable cable and
cable gland.
Low Voltage (LV) 18-54V AC/DC +/- 10%
II 2GD Ex emb IIC T4 Gb (Ta = -20
o
Ex t IIIC T87
C Db IP66 & IP67
The incoming mains cable should not exceed a temperature rise
o
of 34
C above the ambient conditions; select suitable cable and
cable gland.
EC Type Examination Certificate:
Notified
Baseefa Ltd.
Body:
Rockhead Business Park, Staden Lane,
Buxton, SK17 9RZ, UK
Notified body number: 1180
Harmonised standards applied:
EN60079-0:2012, EN60079-7:2007,
IEC60079-18:2009, EN60079-31:2009.
Wolf
LED
Floodlites
are
2008/108/EC EMC Directive.
The product is CE marked showing compliance with all relevant
EC Directives
Alex Jackson – Managing Director
Wolf Safety Lamp Company Ltd
o
o
C to +50
C)
o
o
C to +55
C)
SIRA10ATEX5117X
certified
compliant
with

IMPORTANT

Read these instructions carefully before commencing to use the
Floodlite and retain for future use.
Check the rating label to ensure the Floodlite is suitable for
the supply provided, ambient temperature present and IP
rating.
ATEX certification includes assessment of product safety at
±10% of rated voltage, running lamps outside of this voltage
tolerance will therefore invalidate the ATEX approval and
the product warranty, may result in a dangerous condition,
and could cause the product to fail prematurely.
If the Floodlite is to be used in areas of high vibration,
please consult with Wolf Safety.
ELECTROSTATIC CHARGING HAZARD Clean lens with
damp cloth.
The Floodlite consists of an Ex mb LED chamber and an Ex
emb terminal chamber.
All Floodlites have terminal blocks suitable for up to 4mm
live, neutral and earth.
ATEX approved cable glands must be used and be suitable
for the type of cable used. Any unused cable entries should
be blanked off with a suitable ATEX approved stopper plug
to maintain a minimum IP66/67 rating as marked on the
label.
This product is Class1 equipment and must be earthed.
Floodlites are supplied as standard with 3 core earthed
supply cables. Where the user specifically requires a 24 volt
SELV Floodlite with 2 core cable (+ve and -ve) / a 2 pole
plug, the Floodlite must be used with a separate connection
to earth via the external earth grounding point.
The Floodlite lens is moulded in Polycarbonate, the end
user must ensure that this is suitable for the atmosphere
the Floodlite will be used in.
LV 18-54Volt and 24Volt Floodlites with long cable lengths
(>20m) must be checked to ensure the calculated voltage
drop will not prevent the apparatus from operating within
the specified voltage tolerance (+/- 10%).
Do not connect Floodlites marked 24 volts, product
serial number No. up to 22716 (Except Serial numbers
22591 to 22690), to a centre tapped earth transformer
(CTE), as permanent damage to the product is likely to
occur.
Low voltage Floodlites marked 18-54 volts, product
serial No. from 22717. (Also serial numbers 22591 to
22690), can be connected to a CTE transformer.
24 volt LV Floodlites are Risk Group 1
When user is ≤ 0.35m from the WF-300:
the
HV Risk Group 2.
Caution:
emitted from this product DO NOT stare at the
operating lamp. May be harmful to the eye.
Special conditions for safe use (denoted by X after the
certificate number)
Always use the lamp in the bridle provided.
Except for internal wiring, not more than one single or
multiple strand lead shall be connected into either side of
any terminal, unless multiple conductors have been joined
in a suitable manner, e.g. two conductors into a single
insulated crimped boot lace ferrule.
Leads connected to the terminals shall be insulated for the
appropriate voltage and this insulation shall extend to within
1 mm of the metal of the terminal throat.
possible
hazardous
optical
2
radiation
