VDO HPS 10 Quick Start Manual

Thank you for purchasing a VDO Dayton
subwoofer. Please follow these instructions
carefully so as to fully benefit from the
features that this subwoofer brings to your in
car environment. This manual is produced to
help give you the basic information related to
this system so as to result in a trouble free
installation. In the majority of cases specialist
assistance will be required so as to make the
most from this subwoofer and to ensure that
it delivers a sonic reproduction that is as
accurate as possible therefore we advise that
you seek professional advice.
Important
VDO Dayton subwoofers are designed to suit
a broad range of mobile audio applications
to produce extended, powerful bass in a
limited amount of vehicle space. The installa-
tion can require some extensive knowledge
of the car environment. Although these
instructions explain how to install a VDO
Dayton subwoofer in a general sense, they do
not show box-construction details and exact
installation methods for your particular
vehicle. If you do not feel you have the
necessary tools or experience, do not attempt
the installation yourself. Instead ask your
authorised VDO Dayton dealer about
professional installation options to ensure
maximum subwoofer performance.
Remember to keep your sales receipt with
this manual in a safe place so both are
available for future reference.
Think Safety First!
Please ensure that you can hear traffic at all
times and that this installation in no way
hinders the safe operation of the vehicle due
to distraction of the driver.
VDO Dayton accepts no liability for hearing
loss, bodily injury or property damage
resulting from use or misuse of this product.
We want you to fully enjoy this product, so
please use it sensibly.
For more details:
Visit our homepage www.vdodayton.com
General information
on loudspeaker installation
Recommendations
• While preparing the installation of your
subwoofer, please leave it in the box so as
to avoid any damage.
• Please contact your dealer for the correct
mounting solution for your car so that you
allow your subwoofer to perform to the
maximum. For example, there must be
enough room for the cone to extend to its
full excursion.
• Please ensure that the subwoofer does not
hinder the safe operation of the vehicle.
• Due to the weight and size of this
subwoofer, it will work at its best if the
correct mounting solution is custom made
for your vehicle. To get the most detail and
power from your loudspeaker, make sure
that it has a solid mounting free from
vibration. We recommend the use of an
enclosure.
• To further improve the installation, we
recommend the use of damping material.
Please consult your dealer for details.
• Finally, ensure that the installation is
completely airtight.
Adjusting subwoofer level
The subwoofer level can be adjusted to suit
the environment, placement and personal
preference. You should not be able to hear
the subwoofer as a separate source. Its sound
should be an integrated part of your total
system.
Let your personal preference be the deciding
factor!
