Operator's Manual
Section Aware
Wi-Fi Air Drill Rate and Blockage ECU
MND172201
P a g e
| 1
Software Revision 1.4.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Legend and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AGTRON Legend

  • Page 1 Operator’s Manual Section Aware Wi-Fi Air Drill Rate and Blockage ECU MND172201 P a g e Software Revision 1.4.1...
  • Page 2 MND172201 P a g e Software Revision 1.4.1...

  • Page 3: Quick Start Guide

    A Speed is needed in order to set up the Seed Rate Wizard. Note: If you are using Test Speed: In order for the Legend GPS to work, GPS needs to be enabled on your tablet as well. 1. On the Seeder Setup screen , set the Seeder Test Speed Please consult your tablets owner’s manual on...
  • Page 4 Set Seed Rate Wizard To start, tap the Run/Hold button to switch from Hold to Run. This enables alarms. You must be seeding, with no blockages or sensor errors, in order to use the Seed Rate Wizard. On the Main screen: 1.
  • Page 5 Agtron Enterprises Inc. will not accept any responsibility for any damage or malfunctions resulting from failure to comply with the operator’s manual. If you do not understand the information in this manual, or if you have any questions, contact Agtron Enterprises Inc. ...

  • Page 6: Table Of Contents

    Seed Sensor and Legend Loop Cable Installation ...... 11 Legend S.A. Air Cart Harness Installation ......... 12 Legend S.A. Loop Harness Installation (60 Sensor per Loop or Less) ................... 12 Legend S.A. Sure Seal Harness Installation (Over 60 Sensors per Loop) ..................
  • Page 7 Appendix C: Seed Sensor Sensitivity Values ......56 Appendix D: Conversion Factors ..........57 Appendix E: Loop Diagnostic Settings ........58 Appendix F: Logging Data ............59 Warranty ................60 Warranty Guidelines for Canada and The United States ... 60 MND172201 P a g e Software Revision 1.4.1...

  • Page 8: Introduction

    Introduction About THE LEGEND SECTION AWARE Wi-Fi THE LEGEND S.A. Wi-Fi THE LEGEND S.A Wi-Fi is a Rate and Blockage ECU that communicates with tablet computers using Wi-Fi technology. The Wi-Fi system communicates with the smartphone/tablet via an “App” (short for application). The App provides a user interface to display the information about the air seeder operation.

  • Page 9: Using Your Tablet With The Legend

    The Wi-Fi device can be used to operate and monitor your Seed Rate operation manual. and Blockage. The Legend App must be the active App on the device in order to indicate a blockage or change in seed rate (App must be open and visible on the screen)

  • Page 10: Installation

    (See the parts list associated with Figure 4-11) Main Extension Cables may be needed to mount Disconnect the antenna from the LEGEND S.A. Wi-Fi the ECU in the desired location (Part# ECU.

  • Page 11: Seed Sensor And Legend Loop Cable Installation

    Sensors should be mounted on a relatively straight part of the hose for Attach a Legend Loop cable to the male end of the last best performance. sensor on the first manifold. Tip:...

  • Page 12: Legend S.a. Air Cart Harness Installation

    Legend S.A. Air Cart Harness Installation Disconnect manufacturers 2 pin Deutsch connector from Section 1 solenoid. Connect 2 pin Deutsch connector for Section 1 on Legend Air Cart Harness (AGD1725) into Section 1 solenoid. Connect manufacturers 2 pin Deutsch connector for Section 1 into Section 1 on Legend S.A.

  • Page 13: Legend S.a. Sure Seal Harness Installation (Over 60 Sensors Per Loop)

    Legend S.A. Sure Seal Harness Installation (Over 60 Sensors per Loop) Select a mounting location for the Legend S.A. Harness in the center of the implement. Connect the 35 pin black Ampseal connector to the ECU. Connect the 12 pin Deutsch connector to the Legend No Section Alarm Harness (AGD1725).
  • Page 14 Y-Cable Select a mounting location for the Y-Cable in the center of the implement. Connect the large blue male end to the main cable (shown in Figure 4-8), which is connected to the ECU on Loop 1 or Loop 2. Secure the ring terminal of the Y-Cable to the chassis of the implement to ground the cable.

  • Page 15: Figure 4-11 Installation Diagram

    Figure 4-11 Installation Diagram Diagram is not to scale Figure 4-11 Part Number Description AGD1710 The Legend S.A. Wi-Fi ECU 050013005 Antenna 2.4 GHZ 7” AGD2006 Battery Harness 22ft (6.7m) AGD1733 Legend S.A. Wi-Fi Power Harness AGD1719 Legend S.A. Loop Harness AGD1725 Legend S.A.

  • Page 16: Figure 4-12 Seed Sensor Installation Diagram - Bourgault

    The Legend Seed Sensor 7/8” (22mm) AGST24E The Legend Seed Sensor 15/16” (24mm) AGST25E The Legend Seed Sensor 1” (25mm) AGST32E The Legend Seed Sensor 1 ¼” (32mm) AGST38E The Legend Seed Sensor 1 ½” (38mm) 9ASTX10 The Legend Loop Cable 10ft (3m) 9ASTX20...
  • Page 17 The Legend Seed Sensor 7/8” (22mm) AGST24E The Legend Seed Sensor 15/16” (24mm) AGST25E The Legend Seed Sensor 1” (25mm) AGST32E The Legend Seed Sensor 1 ¼” (32mm) AGST38E The Legend Seed Sensor 1 ½” (38mm) 9ASTX10 The Legend Loop Cable 10ft (3m) 9ASTX20...
  • Page 18 Figure 4-14 Legend S.A. Installation Diagram – Tow Behind Cart AGD1733 AGD2006 AGD1710 Wi-Fi Power Toolbar Harness Air Cart Harness Battery Wi-Fi ECU Harness Table 4-1 Table 4-2 Harness Figure 4-14 Section Control Connectors Figure 4-15 Legend S.A. Installation Diagram – Tow Between Cart...
  • Page 19 Table 4-1 Toolbar Harness Part Numbers Part Description Number AGD1719 Bourgault Toolbar Harness AGD1726 Generic Toolbar Harness Table 4-1 Table 4-2 Air Cart Harness Part Numbers Part Description Number 3151-77 Bourgault Air Cart Harness AGD1725 Generic Air Cart Harness Table 4-2 Note: Bourgault Air Cart Harness (PN –...

  • Page 20: Optional Sensor Installation

    Optional Sensor Installation **Refer to Appendix B: Optional Sensors for more information** GPS/Radar Speed Sensor Connect to the output of your GPS/Radar unit to connector labeled Speed on Air Cart harness. Tips: Turn to the Calibration and Operation portion of this manual for information on how to set up optional sensors in the The Single and Dual Loop ECU’s require a pulse or radar style signal...

  • Page 21: App Installation (If Not Already Installed On Tablet)

    Wi- down until to the Products section of the forum. Fi (rather than using desktop Click the link for The Legend, then select the thread for the computer). Go directly to Agtron.com to download the App.

  • Page 22: Calibration

    Ensure that Wi-Fi is enabled on your tablet. For more information on how to enable Wi-Fi on your tablet refer to your tablets operating manual. On the tablet App screen, tap THE LEGEND Wi-Fi App icon. The following screen appears.

  • Page 23: Setup Wizard

    Setup Wizard Before using THE LEGEND S.A. Wi-Fi you must connect to the ECU and calibrate it for your air seeder system. This is done using the Setup Wizard. Setup Wizard Setup Wizard Figure 5-2 Tap the Setup Wizard icon for loop 1.
  • Page 24 Enter the Legend ECU Serial Number Tip: The serial number is located at the back of the Legend ECU. Figure 5-4 Tap Next for Step 2. Enter speed you drive while seeding. (if using GPS or a speed sensor set speed to zero) Figure 5-5 Tap Next for Step 3.
  • Page 25 Enter the number of sensors on section 1 and tap Next. Figure 5-6 Continue tapping Next and entering the number of sensors for each section (up to ten sections). Tap Done when you have entered the number of sensors for the last section on your drill.

  • Page 26: Seeder Setup

    Seeder Setup The Seeder Setup screen is used to setup and monitor multiple functions on the system. To access the Seeder Setup screen: Select the Seeder Setup icon in the menu bar at the top right of the screen. Figure 5-7 Loop 1 and Loop 2 Total Loop 1 and Loop 2 total is the number of sensors installed on each loop.
  • Page 27 Test Speed Test speed is a valuable tool you can use when performing diagnostics. It supplies a speed signal that simulates the forward motion of the tractor and implement. A Test speed is set during the Setup Wizard, but if you need to adjust the value use the following Tips: instructions.
  • Page 28 Speed Type Tank Sensor The speed sensor is installed on a wheel or shaft that turns when the seeder is in motion. Mount the speed sensor within ½-inch of the magnet. Tap Speed Type to display TANK SENSOR. Proceed to Speed Cal. ISO Ground/Wheel Speed If paired with an ISOBUS Compliant Universal Terminal, the tablet can display the speed from the CANBUS.

  • Page 29: Gps Settings Screen

    Speed Cal When a wheel speed sensor is used, Speed Cal is the circumference of the wheel or shaft. When using a GPS or radar speed signal, Speed Cal is the distance travelled per pulse. To set the Speed Cal value: Tap the Speed Cal button.

  • Page 30: Section Setup

    Section Setup The Section setup is completed during the Setup Wizard. Changes can be made if needed. To access the Section Setup Screen, tap the Section Setup Icon located in the menu bar in the top right of the main screen.

  • Page 31: Operation

    Operation Each box on the screen represents a seed sensor. You group the sensors by section to enable the Section Aware capability of the system. There are 3 modes of operation.  Seed Rate Mode Used when monitoring seed rate & blockage. ...

  • Page 32: Blockage Mode

    Blockage Mode Sensitivity is used to set up blockage monitoring. The sensitivity value (between 1 and 100) sets the minimum seeds per second that seed must flow through the sensors before a blockage alarm occurs. It is normal for seed flow rate to vary slightly during seeding. The goal is to set the sensitivity value high enough to detect actual Tip: blockages without causing nuisance alarms due to slight variations in...

  • Page 33: Product Setup

    Product Setup The Legend has the ability to save your calibrations for a specific product, to recall at a later date. To save a product: Tap the Seed Rate Wizard. A box opens and the on-screen keyboard appears. Instead of entering a seed rate again, select the Product soft key.

  • Page 34: Section Aware Mode

    Section Aware Mode The Legend Section Aware allows no blockage alarms when a section is disabled.. When a section is disabled the sensors on that section will turn purple. If the loop is operating normally the sensors will be green or purple.

  • Page 35: Key Modes

    Key Modes The Legend has the ability to be used with an Android tablet, an iPad or an ISOBUS virtual terminal. You will notice in the bottom right corner of the main screen a key icon. Key Icon Android Mode When the key is blue the Android app is controlling the ECU and is the only app that can calibrate.
  • Page 36 Monitor Only Mode When the key is red, the system is in monitor only mode. You will not be able to calibrate the system when the key is red. MND172201 P a g e | 36 Software Revision 1.4.1...

  • Page 37: Diagnostics

    Diagnostics The Legend has Diagnostic screens to aid in using the system and to help troubleshoot. They are:  Sensor Diagnostic Screen  Loop 1 & Loop 2 History Screen  ECU Diagnostics Screen  Message Lists Sensor Diagnostics Screen The Sensor Diagnostic screen provides status information on all sensors in each loop.

  • Page 38: Loop 1 And Loop 2 History Screen

    The active button can be switched to Ignore and all alarms for that sensor will be shut off. Sensors that have been deactivated will show as not communicating. Tap the Next button to go to the next sensor’s information and Previous to go to the previous sensor’s information. Tap Exit to leave the Sensor Diagnostics screen.

  • Page 39: Ecu Diagnostics Screen

    Wifi RSSI Wifi Signal Strength in Strength percent Loop 1/2 Loop Current in milliamps MilliAmps Legend ECU Enter Serial Number of Serial Number Toggle between US & System Units Figure 7-4 Metric units Tapping the Reset Button will reset the Wi-Fi Transmit and Receive (Tx/Rx) TCP count.

  • Page 40: Message Lists

    Message Lists Message lists can be aid in helping Agtron troubleshoot a potential problem with your Legend system. The message lists are:  Wireless Message Lists  Eye Strength Message Lists  Sensor Error History  Create Sensor Data.csv Wireless Message List The Wireless Message List displays information regarding the Wi-Fi connectivity between the ECU &...

  • Page 41: Eye Strength Message List

    Eye Strength Message List The Eye Strength Message List displays the infrared eye strength of every seed sensor installed on each loop. To access the Eye Strength Message List: Tap the menu icon and select Eye Strength Message List. The Eye Strength Message List appears You can choose to save the list to the tablet or delete it.

  • Page 42: Sensor Error History

    Sensor Error History The Sensor Error History page displays the errors/alarms that happened throughout the day as well as how long they were in alarm. To access the Sensor Error History page: Tap the menu icon and select Sensor Error History. The Sensor Error History page appears.

  • Page 43: Create Sensordata.csv

    Access the device storage on your tablet. Tip! Locate the Agtron folder and open it. For more information on The SensorData.csv file will be in the Agtron folder. how to access your tablets device storage. See the manual for your tablet.

  • Page 44: Troubleshooting

    Troubleshooting System Alarms ICON ALARMS ICON ALARMS Not Equal Blocked Alarm High/Low Rate Alarm Sensors not communicating More than one Communication Loop Overload Error (Only appears if entire loop is disconnected) Blocked Alarm with a High or Low Rate alarm with a communication error communication error Sensor clean error with...
  • Page 45 One Disconnect in the System When there is only one disconnect in the Loop the sensor icon turns half orange and depending on status of sensor, the other half can be any of the four colors, green for seed flowing, red for blocked, yellow for high or low rate or grey for sensor needs cleaning.
  • Page 46 Figure 8-4 is showing a blocked sensor with one disconnect between sensor four and sensor five. Sensor four needs to be cleaned and sensor 5 is detecting seed. Break in Loop 1 Sensor needs Cleaning Figure 8-4 Figure 8-5 is showing two blocked sensors with one disconnect between sensor four and sensor five.
  • Page 47 To find out where the cable is disconnected in the loop, tap anywhere on loop 1 (or loop 2) screen area. The Sensor Status screen appears at the bottom indicating where the cable is disconnected in the loop. Figure 8-6 shows a cable disconnected between sensor four and sensor five with seed still flowing through the sensors.
  • Page 48 Multiple Disconnects in the System (Communication Error) When there are multiple cables disconnected in the system you will see sensors not communicating. The sensors are not communicating because they are not receiving Note power from the system. Sensors not communicating does not necessarily mean that those sensors are faulty.
  • Page 49 To find the location of the disconnected cables, tap anywhere on the loop. The sensors appear at the bottom of the screen, as shown in Figure 8-9. Figure 8-9 Wrong Number of Sensors Expected When the wrong number of sensors is detected by the system, compared to what the user has entered, the Not Equal icon will appear as shown in Figure 8-10.
  • Page 50 Tap the Not Equal icon on Main screen and Figure 8-11 will appear. It indicates the wrong number of sensors has been detected. Note: You can choose to update the tower of sensors if the window indicates the correct number of sensors installed, or ignore if the window indicates the wrong number of sensors installed.

  • Page 51: Troubleshooting Table

    Troubleshooting Table Type of Problem Symptom/Diagnostic Step Action/Information No loop information The loop indicated is turned off. To turn loop on, increase sensitivity >0. App not connected to ECU Enter serial# and turn on Wi-Fi Communication error App displays Comm Error 1 both ways Check all the cables and connections.
  • Page 52 Type of Problem Symptom/Diagnostic Step Action/Information Blocked Sensor The sensor indicated is blocked. Clean blockage from indicated run. If the indicated run is not blocked… …verify the Sensitivity is not set too high. Check inside the distribution towers for any foreign material. This may cause blockages to move from sensor to sensor.

  • Page 53: Manual

    Manual Opening the Manual on the Tablet The product manual can be opened directly from the Legend App. A PDF reader is required to open the file. To open the Manual, tap the Manual icon To change pages of the Manual, swipe across the screen.

  • Page 54: 10. Appendix

    The Legend Seed Sensor 7/8” (22mm) AGST24 The Legend Seed Sensor 15/16” (24mm) AGST25 The Legend Seed Sensor 1” (25mm) AGST32 The Legend Seed Sensor 1 ¼” (32mm) AGST38 The Legend Seed Sensor 1 ½” (38mm) Optional Parts Part Number Description AGD1726 Legend S.A.

  • Page 55: Appendix B: Optional Sensors

    Appendix B: Optional Sensors This section describes the optional sensors that can be added to the cart. Shaft/Speed/Work Switch Sensor-AGSH001 Low RPM Reed Switch Sensor ½” diameter, mounts using ½” P-clip and #10 self-tapping screw ¾” x 3/16” (included), 3/16” P-clip and #10 self-tapping screw ¾” x 3/16” (included for securing cable), 2 x magnet .950”...

  • Page 56: Appendix C: Seed Sensor Sensitivity Values

    Appendix C: Seed Sensor Sensitivity Values The following sensitivity settings provide a guideline for setting your Seed Rate Monitor sensitivity: Sensitivity Seeds/second Loop is off 1271 2500 Enter the product you are using and the Sensitivity value used for quick value changes Product Sensitivity MND172201...

  • Page 57: Appendix D: Conversion Factors

    Appendix D: Conversion Factors To convert from Imperial to Metric measurements, multiply by the following factors. To Convert Multiply By Inches Millimeters 25.4 Feet Meters 0.3048 Yards Meters 0.9144 Miles Kilometers 1.609 Square Foot Square Meters 0.0929 Acres Hectares 0.4047 Pounds Kilograms 0.4536...

  • Page 58: Appendix E: Loop Diagnostic Settings

    Appendix E: Loop Diagnostic Settings The Loop Diagnostic Setting screen allows users to view and change communication settings. To view the Loop Diagnostic Settings Screen, tap the Loop Communication Setup icon for loop 1 or loop 2. Loop 1 and 2 Communication Setup Figure 10-1...

  • Page 59: Appendix F: Logging Data

    Service in troubleshooting a system. It creates a file that contains all of the message lists. To create an Error File Package Exit the Legend Wi-Fi app by tapping the back soft key. A pop up window appears that says, “Are you sure you want to exit?”...

  • Page 60: 11. Warranty

    Agtron Enterprises Inc. for a return authorization number and supply the replacement warranty parts. 3. If replacement parts are sent by Agtron Enterprises Inc., the customer will have 30 days to return the original defective product. A credit card is required and after 30 days the customer will be charged if the defective product is not received by Agtron Enterprises Inc.
  • Page 61 MND172201 P a g e | 61 Software Revision 1.4.1...
  • Page 62 MND172201 P a g e | 62 Software Revision 1.4.1...
  • Page 63 MND172201 P a g e | 63 Software Revision 1.4.1...
  • Page 64 242 Robin Crescent Saskatoon, Saskatchewan Canada S7L 7C2 TOLL FREE: 1.800.667.0640 P: 306.934.0640 F: 306.668.7666 E: sales@agtron.com W: www.agtron.com MND172201 P a g e | 64 Software Revision 1.4.1...
