Summary of Contents for OneAccess UDgateway H5
- Page 1 UDgateway High-End Appliance Hardware Guide V 5.3 Ref.: RD-HGHGW050300-EN-02...
- Page 2 OneAccess. OneAccess and the distributors can in no case be held responsible for direct or indirect damage of any kind incurred as a result of any error in the software or guide.
-
Page 3: Table Of Contents
Contents Contents 1. Read Me First ......1 1.1. Who should use this manual ..... 1 1.2. - Page 4 4. Technical Data ......19 4.1. UDgateway H5 hardware specifications ... 19 4.1.1.
- Page 5 Contents LIST OF FIGURES Figure 1 - UDgateway - H5 hardware - Front Panel......3 Figure 2 - UDgateway - H5 hardware - Rear Panel ......4 Figure 3 - UDgateway - H3 hardware - Front Panel.
- Page 6 Contents This page is intentionally blank Ref: RD-HGHGW050300-EN-02 UDgateway - Hardware Guide...
-
Page 7: Read Me First
Read Me First 1.1. Who should use this manual This guide is intended for installation engineers, product support engineers and service personnel. It is not intended for the end-user of the system. 1.2. How to use this manual This user manual is for UDgateway ® . Use the instructions in this manual to make physical connections for the installation of the system and to configure the system parameters. -
Page 8: General Safety Instructions
Read Me 1.3. General safety instructions Comply with all national and local safety requirements when installing this equipment. Additionally, note the following general safety instructions: WARNING Do not install the equipment if it is damaged. Notify the supplier immediately to arrange replacement equipment/parts. WARNING In case of fire Switch off power to the equipment immediately... -
Page 9: Udgateway Overview
Characteristics: Standard 19 inch rack mounting, 1U height Cover and housing: metal Compared to H3 hardware model, UDgateway H5 hardware model has an additional Ethernet board to connect the UDgateway to a multi-WAAN environment with Link Management option. 2.1.1. -
Page 10: Rear Panel
UDgateway Overview 2.1.2. Rear Panel All connections are made from the rear panel. The rear panel provides the following connectors: Figure 2 - UDgateway - H5 hardware - Rear Panel Power supply bay 2 Power supply bay 1 HP iLO management port Serial connector Video connector xl0 (WAN) - RJ-45 Ethernet connector - Optimized interface... - Page 11 UDgateway Overview xl1 (WAN1) - RJ-45 Ethernet connector - Optimized interface Led activity xl1 First led: Turns on 100 Mbits/s link (green) Second led: Turns on 1000 Mbits/s link (green) Third led: Turns on any link speed, blinks on activity (green) If bypass: both, first and second leds are green USB connectors (2) RJ-45 Ethernet connector (UNUSED)
-
Page 12: Hardware Model : H3
UDgateway Overview 2.2. Hardware model : H3 The UDgateway ® High-End appliance is intended for installation in 19-inch telco racks. Characteristics: Standard 19 inch rack mounting, 1U height Cover and housing: metal Compared to H2 hardware model, UDgateway H3 hardware model: has an additional Ethernet bypass board is sized to support CPS40 and CSP60 software packages. -
Page 13: Rear Panel
UDgateway Overview External health LED (power supply) Green = Power supply health is normal Amber = Power redundancy failure occurred Off = Power redundancy failure has occurred. When the server is in standby mode, power supply health is normal. UNUSED UNUSED NOTE: Ethernet bypass LEDs for the bypass board are located on the rear panel. - Page 14 UDgateway Overview fxp0 - RJ-45 Ethernet connector - Interception interface Led activity fxp0 First led: Turns on 100 Mbits/s link (green) Second led: Turns on 1000 Mbits/s link (green) Third led: Turns on any link speed, blinks on activity (green) If bypass: both, first and second leds are green USB connectors Note: VGA / PS/2 connectors or Serial connector can be used to directly...
-
Page 15: Hardware Model : H2
UDgateway Overview 2.3. Hardware model : H2 The UDgateway ® is intended for installation in 19-inch telco racks. Characteristics: Standard 19 inch rack mounting, 1U height Cover and housing: metal Note: The UDgateway hardware model H2 has no Ethernet bypass board. Note: H2 model has no HP iLO software license installed, preventing remote console access through HP iLO interface. -
Page 16: Rear Panel
UDgateway Overview NIC 1 link/activity LED Green = Network link exists Flashing green = Network link and activity exist Off = No link to network exists If power is off, view the LEDs on the RJ-45 connector for status by referring to the rear panel LEDs. -
Page 17: Udgateway Installation
UDgateway Installation 3.1. Safety first Read these safety instructions before starting any installation work. Refer also to the general safety instructions at the beginning of this manual. 3.1.1. Safety instructions WARNING Before applying power to any equipment you are using or installing, look for possible hazards such as moist floors, ungrounded power extension cables or missing safety grounds, and locate the emergency power switch for the room in which you are working so you can isolate power quickly if necessary. -
Page 18: Airflow And Cooling
UDgateway Installation 3.2.2. Airflow and cooling Provision must be made for: at least 10 cm free space around the UDgateway ® for proper air flow ensuring that the UDgateway ® temperature and humidity environment can be maintained - See 'Technical Data' chapter. A sufficient air supply for the system must be provided. -
Page 19: Before Installing A Udgateway
UDgateway Installation 3.3. Before installing a UDgateway® 3.3.1. Pre-requisites Before installing the UDgateway ® , check that following requirements have been met. 3.3.1.1. Network access The standard scenario to configure UDgateway is using a web browser through TCP/ IP connectivity. Any computer with an OS supporting a standard TCP/IP stack and a recent web browser will do. -
Page 20: Prepare Network Architecture
UDgateway Installation 3.3.2. Prepare network architecture Before continuing, you should decide on the following: where you will be locating your equipment, how you will be ensuring network connectivity, and what will be your IP addressing. This is a pre-requisite of installation and configuration. With this information in hand, you will be able to proceed by following the steps described below. -
Page 21: Hardware Installation Details
UDgateway Installation 3.4. Hardware installation details The procedure to install the UDgateway ® successfully is as follows: 1. Unpack the UDgateway ® and check the contents of the package 2. Interconnect the UDgateway ® for configuration For more detailed information on the hardware installation procedure, please refer to the following paragraphs. -
Page 22: Connections
UDgateway Installation 3.4.2. Connections All connectors are on the rear side of the UDgateway ® . Connect all cables according to the cabling plan below. 3.4.2.1. Ethernet connections xl0 (WAN) - This interface must be connected to the Constraint Network. fxp0 (LAN) - This interface must be used for initial configuration (step-by-step configuration) Traffic going through fxp0 interface is intercepted in order to be optimized when... -
Page 23: Figure 10 - Scenario With 2 Switches
UDgateway Installation UDgateway fxp0 (WAN) (LAN) Ethernet switch Ethernet switch Figure 10 - Scenario with 2 switches VLAN xl0 (WAN) UDgateway fxp0 VLAN fxp0 (LAN) (WAN) (LAN) Ethernet switch VLAN capable Figure 11 - Scenario with 1 physical switch on VLAN technology 3.4.2.1.2. -
Page 24: Screen / Keyboard Console Connection
UDgateway Installation UDgateway VLAN xl2 (WAN2) xl2 (WAN2) VLAN xl1 (WAN1) xl1 (WAN1) VLAN xl0 (WAN) xl0 (WAN) fxp0 (LAN) Ethernet VLAN fxp0 (LAN) crossover Ethernet switch VLAN capable Figure 13 - Multi-WAN scenario with 1 physical switch on VLAN technology 3.4.2.2. -
Page 25: Technical Data
Technical Data 4.1. UDgateway H5 hardware specifications 4.1.1. Size and weight specifications Height: 43 mm (1.7 inch) - 1U Width: 426 mm (16,8 inch) Depth: 692 mm (27.2 inch) Weight: 17.9 kg (39.46 lb) 4.1.2. Environmental specifications Temperature range Operating: +10°C to +35°C (+50°F to +95°C) -
Page 26: Console Ports
Technical Data 4.1.4.2. Console ports 1 x RS-232 serial port connection 1 x VGA/PS2 screen/keyboard connection 4.1.4.3. Fans Yes: redundant fans 4.1.4.4. Storage OS storage on 2 redundant hard drives Data storage on 2 redundant hard drives (Hot-swap RAID 1 mirroring) Hard drive features: SAS hard drives RAID1 mirroring... -
Page 27: Udgateway H3 Hardware Specifications
Technical Data 4.2. UDgateway H3 hardware specifications 4.2.1. Size and weight specifications Height: 43 mm (1.7 inch) - 1U Width: 426 mm (16,8 inch) Depth: 692 mm (27.2 inch) Weight: 17.9 kg (39.46 lb) 4.2.2. Environmental specifications Temperature range Operating: +10°C to +35°C (+50°F to +95°C) Storage: -40°C to +70°C (-40°F to +158°F) -
Page 28: Console Ports
Technical Data 4.2.4.2. Console ports 1 x RS-232 serial port connection 1 x VGA/PS2 screen/keyboard connection 4.2.4.3. Fans Yes: redundant fans 4.2.4.4. Storage OS storage on 2 redundant hard drives Data storage on 2 redundant hard drives (Hot-swap RAID 1 mirroring) Hard drive features: SAS hard drives RAID1 mirroring... -
Page 29: Udgateway H2 Hardware Specifications
Technical Data 4.3. UDgateway H2 hardware specifications 4.3.1. Size and weight specifications Height: 43 mm (1.7 inch) - 1U Width: 426 mm (16,8 inch) Depth: 692 mm (27.2 inch) Weight: 17.9 kg (39.46 lb) 4.3.2. Environmental specifications Temperature range Operating: +10°C to +35°C (+50°F to +95°C) Storage: -40°C to +70°C (-40°F to +158°F) -
Page 30: Console Ports
Technical Data 4.3.4.2. Console ports 1 x RS-232 serial port connection 1 x VGA/PS2 screen/keyboard connection 4.3.4.3. Fans Yes: redundant fans 4.3.4.4. Storage OS storage on 2 redundant hard drives Data storage on 2 redundant hard drives (Hot-swap RAID 1 mirroring) Hard drive features: SAS hard drives RAID1 mirroring... -
Page 31: Declaration Of Conformity Ce (H5 Model)
Technical Data 4.4. Declaration of conformity CE (H5 model) UDgateway High-End appliance (H5 model) is based on a Hewlett-Packard hardware platform known as HP Proliant DL360-G7 Server. UDgateway - Hardware Guide Ref: RD-HGHGW050300-EN-02... -
Page 32: Declaration Of Conformity Ce (H3 & H2 Models)
Technical Data 4.5. Declaration of conformity CE (H3 & H2 models) UDgateway High-End appliance (H3 & H2 models) is based on a Hewlett-Packard hardware platform known as HP Proliant DL360-G5 Server. DECLARATION OF CONFORMITY according to ISO/IEC 17050-1 and EN 17050-1 DoC #: HSTNS-2115-2 Supplier's Name: Hewlett-Packard Company... -
Page 33: Rohs Compliance
Technical Data 4.6. RoHS compliance HP’s Compliance with Restriction of Hazardous Substances (RoHS) Directives (rev 9 February 2011) HP is committed to compliance with all applicable laws and regulations, including any new material restriction requirements adopted under the revised European Union RoHS Directive, otherwise known as EU RoHS 2 and the upcoming material restriction requirements of China’s Management Methods for Controlling Pollution by Electronic Information Products, otherwise known as China RoHS Phase II. - Page 34 Technical Data Dibutylphthalate (DBP) HP believes other substances should be included in future RoHS legislation. This includes the restriction of polyvinyl chloride (PVC) and brominated flame retardants (BFRs) from electrical and electronic products (EEE). HP believes PVC and BFRs should be the focus for the restriction of chlorine (Cl) and bromine (Br) from electrical and electronic products, where technically feasible.
- Page 35 Technical Data One of HP’s voluntary goals is to remove all mercury – a potentially hazardous substance commonly found in notebook computer screens – from its notebook PCs by the end of 2010. HP also has an internal voluntary goal to apply the EU RoHS 2 substance and exemption requirements outside the EU (and EFTA), except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive), on a worldwide basis within 6 months...
- Page 36 Technical Data 2011 in Annex I of EU RoHS Directive (2002/95/EC) as set out in the EU Commission Decision of September 24, 2010 and earlier Commission Decisions withdrawing exemptions. Ukraine HP products comply with the substance restrictions in Ukraine’s“ Technical Regulation on restrictions as to the use of some dangerous substances in electric and electronic devices”, otherwise known as Ukraine RoHS which came into effect on 1 January 2011.
- Page 37 Technical Data except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive), for virtually all HP branded products in scope of EU RoHS 1. Japan HP products comply with the labeling requirements set out in Japan’s “The Marking of Presence of the Specific Chemical Substances for Electrical and Electronic Equipment”...
-
Page 38: Weee Compliance
Technical Data 4.7. WEEE Compliance HP and WEEE Compliance Background The European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive has already been implemented in most member states, with only a few left to complete transposition. There are several obligations imposed on producers of electrical and electronic equipment, such as HP. - Page 39 Technical Data designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.
- Page 40 Technical Data customers can return their products. Customers can access HP’s recycling service by visiting www.hp.com/recycle 7) Treatment In accordance with Community waste legislation, HP confirms that treatment and recycling of WEEE done on behalf of HP, either by a collective scheme or individually, is carried out in accordance with the requirements of the WEEE Directive, as set out in the implementing legislation of the member states, including requirements respecting special treatment for specified parts...
-
Page 41: Compatibility Matrix
Compatibility matrix 5.1. Hardware/ software compatibility matrix SOFTWARE VERSION HARDWARE MODEL v3.1 v4.1 v4.3 v5.1 v5.3 * memory upgrade SOFTWARE OPTIONS HARDWARE OPTIONS HARDWARE Ethernet Service CIFS WANcompress MODEL Bypass Platform ready ready ready ready up to CSP20 Starting with UDgateway software version 5.1, hardware model can be checked from UDgateway web GUI interface. -
Page 42: Check The Hardware Model
Hardware/Software compatibility matrix 5.2. Check the hardware model If you benefit from v5.x release, you can check hardware model from the UDgateway web GUI interface. For more information about how to enter the UDadmin welcome page, refer to Advanced Configuration Guide. Figure 14 - UDadmin welcome page Ref: RD-HGHGW050300-EN-02... - Page 43 If you have any comments to make, do not hesitate to tell us about them. Just give us the page and the line references. Your comments will be carefully considered. Please send your remarks to: Service Support OneAccess BP 355 2455 route des Dolines 06906 Sophia-Antipolis Cedex...
- Page 44 For local offices and sales representatives, please visit our website: www.oneaccess-net.com Tel: +33 (0)4 93 00 16 60 Fax: +33 (0)4 93 00 16 61 B.P. 355 - 2455, route des Dolines 06906 Sophia Antipolis cedex France...
