VAS 6790
VAS 6790/1
VAS 6791
Pneumatic/hydraulic
blind riveting tool
BA2
Setup – Installation: Rivet clamp
Additional information to the instruction manual
BA1 (VAS 6790/2, VAS 6792, VAS 6792/1, VAS 6792/2)
ATTENTION
This supplementary sheet serves as a supplement to the instruction manual BA1
(VAS 6790/2, VAS 6792, VAS 6792/1, VAS 6792/2) and may only be used in
conjunction with it.
Translation of the original instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAS 6790/1 and is the answer not in the manual?

Questions and answers

Summary of Contents for TKR Group VAS 6790/1

  • Page 1 VAS 6790 VAS 6790/1 VAS 6791 Pneumatic/hydraulic blind riveting tool Setup – Installation: Rivet clamp Additional information to the instruction manual BA1 (VAS 6790/2, VAS 6792, VAS 6792/1, VAS 6792/2) ATTENTION This supplementary sheet serves as a supplement to the instruction manual BA1 (VAS 6790/2, VAS 6792, VAS 6792/1, VAS 6792/2) and may only be used in conjunction with it.
  • Page 2 Owner‘s manual USB-Stick www.tkr-support.com VAS 611 007 Elektronisches Messsystem zur Nockenwelleneinstellung Betriebsanleitung Originalbetriebsanleitung Owner‘s manual 1. Download current digital owner‘s manuals 2. Support...
  • Page 3: Table Of Contents

    Chapter Page Safety Designations Technical data Scope of supply, rivet clamp set Technical Specifications Technical Data Rivet Clamp Technical data, screw needles Overview of rivet inserts Application Connecting the rivet clamp to the pressure generator 11 Inserting the riveting tool Areas of application Checking Riveting Results Cleaning the Riveting Tools...
  • Page 4: Designations

    Designations Information regarding this manual For safe handling, it is essential that you observe the safety and application instructions in the original VAS 6790/ VAS 6791 instruction manual. Marking on the rivet clamp 1.1.1 Symbol to read the instruction manual Symbol to wear protective gloves Symbol to wear protective goggles Manufacturer‘s identification...
  • Page 5: Scope Of Supply, Rivet Clamp Set

    Scope of supply, rivet clamp set VAS 6790/1 2.1.1 1x Rivet clamp NB-230-140 1 unit extension Technical Specifications Environmental 5–50 °C / 41–122 °F temperature Prescribed safety Protective gloves, face mask (refer also to BGR 192) clothing...
  • Page 6: Technical Data Rivet Clamp

    Technical Data Rivet Clamp 2.3.1 NB-45-40 VAS 6790/57 2.3.2 NB-230-140 VAS 6790/58...
  • Page 7 Title NB-45-40 NB-230-140 Art. No. VAS 6790/57 VAS 6790/58 Length 112 mm 348 mm Width 58 mm 58 mm Height 110 mm 364 mm Clamp aperture 40 mm 140 mm Aperture depth 45 mm 230 mm Weight 1.4 kg 9.2 kg Extension –...
  • Page 8: Technical Data, Screw Needles

    Technical data, screw needles 2.4.1 Ø 2,4 mm Ø 4,0 mm Ø 4,8 mm Title Screw needles Art. No. VAS 6790/53 VAS 6790/52 VAS 6790/51 Ø 2.4 mm 4.0 mm 4.8 mm Color brown yellow green...
  • Page 9: Overview Of Rivet Inserts

    Overview of rivet inserts VAS 6790/24 VAS 6790/25 VAS 6790/26 VAS 6790/27 VAS 6790/28 VAS 6790/29 VAS 6790/31 VAS 6790/32 VAS 6790/30 VAS 6790/33 VAS 6790/35 VAS 6790/36 VAS 6790/37 VAS 6790/38...
  • Page 10 Overview of rivet inserts VAS 6790/37 VAS 6790/38 VAS 6790/39 Ø 3 mm Ø 3 mm VAS 6790/40 VAS 6790/41 VAS 6790/42 Ø 5 mm VAS 6790/43 VAS 6790/44 VAS 6790/45 Ø 5 mm VAS 6790/46 VAS 6790/47...
  • Page 11: Connecting The Rivet Clamp To The Pressure Generator

    Connecting the rivet clamp to the pressure generator 3.1.1 3.1.2 3.1.3 3.1.4 3.1.5 3.1.6...
  • Page 12: Inserting The Riveting Tool

    Connecting the rivet clamp to the pressure generator 3.1.1 – 3.1.6 Place the riveting clamp on the Compact Booster cylinder. The arrows and dots must be aligned (position: open). Then turn the rivet clamp to the next marking (position: close) and lock in position with the lever.
  • Page 13 3.2.1 3.2.2 3.2.3 3.2.4 3.2.5 3.2.6...
  • Page 14 Inserting the riveting tool 3.2.7 3.2.8 3.2.1 – 3.2.8 Insert the rivet insert required for the work process into the rivet clamp recess, as required, or insert the plunger rod and secure with 1/4-turn. Do not use force. Select the corresponding counter-piece, locating and locking it in position in the opposite side of the rivet clamp in the same way.
  • Page 15 3.2.11 3.2.12 3.2.9 – 3.2.12 When using a large rivet clamp with a clamp aperture of up to 140 mm, the extension VAS 6790/59 must also be fitted. This is screwed either into the seating on the rivet clamp or into the plunger rod and hand-tightened.
  • Page 16: Areas Of Application

    Areas of application 3.3.1 3.3.2 3.3.3 3.3.4 3.3.5 3.3.6...
  • Page 17 Rivet Procedure Tool pair Pressing out from two-ply sheet connections + D5 Pressing out from 3-ply sheet connections or other thi- + D5 cker connections Punch rivet Setting 5.3x5.5 mm punch rivets S6 + S7 5.3x5.5 mm Setting 5.3x6.5 mm punch rivets S6 + S8 5.3x6.5 mm Pressing out from punch-rivet connections from 2-ply...
  • Page 18 Areas of application 3.3.9 3.3.10 3.3.11 3.3.12 Rivet Procedure Tool pair Pressing out from two-ply sheet connections + D2 Pressing out from 3-ply sheet connections or other thicker Stanzniet D2 + D3 connections Ø 3,2 mm Setting 3.2 mm punch rivets S2 + S3 Ø...
  • Page 19 3.3.13 3.3.14 3.3.15 3.3.16 Rivet Procedure Tool pair Perforating and stamping (with drill hole) D10 + D11 Perforating and stamping (without drill hole) D10 + D11 Full rivet Reshaping the areas of the connection deformed while Ø 4.0 mm D8 + D8 pressing out.
  • Page 20 Areas of application 3.3.17 3.3.18 3.3.19 3.3.20 Rivet Procedure Tool pair Pressing out from 3-ply sheet connections or other thi- D13 + D14 cker connections Full rivet Hole punching and stamping D15 + D16 Ø 6.0 mm Reshaping the areas of the connection deformed while D17 + D17 pressing out.
  • Page 21: Checking Riveting Results

    Checking Riveting Results 3.4.1 3.4.2 3.4.3 3.4.1 – 3.4.3 The results must be checked after the riveting operation. If the installed rivet does not meet quality requirements, the reason for the fault must be determined. If the quality of the installed rivet is acceptable, the work process can be continued. After each riveting operation, check that the heads of the rivets are firmly sea- ted and check the extension (if used).
  • Page 22: Cleaning The Riveting Tools

    Cleaning the Riveting Tools 3.5.1 3.5.2 3.5.1 – 3.5.2 Remove adhesive residue from all contaminated rivet inserts after each completed riveting operation. For this, remove all of the affected tool components and clean with a suitable cleaning agent. If adhesive residue is allowed to remain on the riveting tool, it will eventually cause a malfun- ction.
  • Page 23: Ending The Operation

    Ending the operation 3.6.1 3.6.2 3.6.1 – 3.6.2 Always disconnect the compressed air supply from the pump after riveting or while work is interrupted. If a compressed air hose whips around wildly, it could cause severe bodily injury. Only store rivet clamps in the transport case designed for this purpose.
  • Page 24 Am Waldesrand 9–11 D-58285 Gevelsberg (Germany) Phone: +4923 32 666 07 - 0 Fax: +4923 32 666 07 - 941 E-mail: info@tkrgroup.com Web: www.tkrgroup.com...
