MODEL 2852-LPS WITH S00445C LEAK SENSOR
Continental North America Toll Free 1-(800) 387-9487
Ph: +1 (905) 829-2418 Fx: +1 (905) 829-4701
Area Leak Alarm
User Manual
Technical Support
A Product of Arjay Engineering Ltd.
Oakville, Ontario, Canada
www.ArjayEng.com
MODEL:
HARDWARE NO.:
SOFTWARE NO.:
SERIAL NO.:
5.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2852-LPS and is the answer not in the manual?

Questions and answers

Related Manuals for ARJAY ENGINEERING 2852-LPS

Summary of Contents for ARJAY ENGINEERING 2852-LPS

  • Page 1 MODEL 2852-LPS WITH S00445C LEAK SENSOR Area Leak Alarm User Manual Technical Support Continental North America Toll Free 1-(800) 387-9487 Ph: +1 (905) 829-2418 Fx: +1 (905) 829-4701 A Product of Arjay Engineering Ltd. Oakville, Ontario, Canada www.ArjayEng.com MODEL: HARDWARE NO.: SOFTWARE NO.:...
  • Page 2 ENGINEERING Reliable monitoring of liquid leaks in containments and floor spaces Over 40 years of capacitance experience stands behind the 2852-LPS leak alarm. The sensors continuously monitor for the accumulation of liquid in a normally dry condition. • capacitance technology alarms on any liquid •...
  • Page 3 The unique PMC circuit design, installed at the probe and exclusive to Arjay, immediately converts the sensor signal to a frequency pulse for furtherance to the controller. ENGINEERING Arjay Engineering Ltd. 2851 Brighton Road Oakville, Ontario Canada L6H 6C9 http://www.arjayeng.com telephone: ++1 905-829-2418 N.

  • Page 4: Table Of Contents

    Model: 2852-LPS User Manual Rev: 0.0 TABLE OF CONTENTS   INSTRUMENT OVERVIEW .................... 3     Features ......................3     Model Number vs. Voltage Input ................ 3     Specifications ..................... 4     INSTALLATION ....................... 6    ...

  • Page 5: Instrument Overview

    Modbus protocol via RS-485 for access by Arjay handheld, Central Access Panel or compatible system  Local Auto calibration or remote calibration via network  User specified custom features may be added by contacting Arjay Engineering Ltd. Model Number vs. Voltage Input  2852-LPS-1-X 100-240 VAC power input ...

  • Page 6: Specifications

    0.002% of Full Scale capacitance via network display Calibration Single point: Auto calibration Environmental: Operating conditions Continuous -20 °C to +55 °C 2852-LPS controller Operating Temperature -60 °C to +55 °C PMC 2800TMP -60 °C to +260 °C Sensor Probe (S00445C) Relative humidity 0 to 95% (non-condensing) Altitude ≤2000 m...
  • Page 7 Model: 2852-LPS User Manual Rev: 0.0 Installation Category Pollution Degree Equipment mobility Fixed Refer to Dimensional Drawing Mechanical Specification: Enclosure Rating Type 4 / IP65 Painted Steel Type 4x / IP66 Polycarbonate Type 4x / IP66 316 Stainless Steel Options on Enclosure...

  • Page 8: Installation

    User Manual Rev: 0.0 INSTALLATION NOTE: If any damage to the instrument is found, please notify an Arjay Engineering representative as soon as possible prior to installation. Controller Installation Choose the mounting location in accordance with good instrument practice. Main controller should be mounted above any possible flood area.

  • Page 9: Sensor Installation (Probe Style)

    Model: 2852-LPS User Manual Rev: 0.0 Sensor Installation (Probe Style) Sensors should be mounted in a containment area OR at the lowest elevation in the area so that the liquid can pool around the sensor. Once installed, wire each sensor back to the main controller using the 50ft of 3 wire cable supplied.

  • Page 10: Electrical Installation

    Model: 2852-LPS User Manual Rev: 0.0 Electrical Installation Figure 1 – Electrical Installation Overview TB1/TB2 - Relay Output 2 SPDT relay, Dry, N.O. Contact 5A @ 250 VAC (Resistive) and N.C. Contact 3A @ 250VAC (Resistive), selectable failsafe or non-failsafe, selectable high or low acting alarm, programmable time delay: 0 –...

  • Page 11: Input / Output Terminal Specification

    Model: 2852-LPS User Manual Rev: 0.0 2.3.1 Input / Output Terminal Specification Input Terminals – Power Source Terminal Overvoltage Rated Voltage (V) Rated ___ HZ or Specified category Current/power Mains (A/W/VA) fluctuation  100-240V 150mA 50/60Hz  12 OR 24V 250mA ...

  • Page 12: Glossary Of Symbols

    Model: 2852-LPS User Manual Rev: 0.0 Glossary of Symbols Attention, consult accompanying documents Attention, veuillez consulter les documents ci-joints. Protective Earth Fuse Terre de protection Coupe-circuit; fusible Direct Current (DC) Normally open relay contacts Courant continu Contacts travail Normally closed relay contacts...

  • Page 13: Startup And Calibration

    The unit is pre-configured and tested at the factory. However, a quick field calibration is required after power up to tune the sensor to the installation and cable conditions. See section 3.3 to calibrate the 2852-LPS. Menu Flow Chart Background Information The control setup, diagnostics, and calibration are accessed using the display and keypad on the controller.

  • Page 14: Data Entry

    Normal Screen 3.3.1 Site Calibration A factory pre-configuration and set-up has been defaulted into the 2852-LPS. As such, a user set-up is not required in the field. A basic calibration is only required. Be sure all the sensors are wired and placed in their proper location before calibrating.

  • Page 15: Setup, Alarms And Diagnostics

    Model: 2852-LPS User Manual Rev: 0.0 SETUP, ALARMS DIAGNOSTICS 2852 Controller Setup The 2852 controller has the following Setup parameters: 1. Sensitivity The sensitivity determines the amount of pF change required to cause an alarm. The factory default setting is 4.0 pF. Increasing the pF value will increase the amount of liquid required to cause an alarm.

  • Page 16: 2852 Controller Diagnostics

    Model: 2852-LPS User Manual Rev: 0.0 3. Failsafe Failsafe typically means that the relay is held in an energized state when in a normal operating condition as opposed to an alarm condition. In an alarm condition, the relay de- energizes which is identical to when the instrument power is shut off. The rational is that the alarm condition should match the Power Fail condition.

  • Page 17: 2800 Series Modbus Register Mapping

    Model: 2852-LPS User Manual Rev: 0.0 4.4.2 2800 Series Modbus Register Mapping Zero No. of Based DESCRIPTION TYPE 40001 Serial Number float 40003 Hardware Rev / Software Rev byte 40004 Sensitivity / Mode byte 40005 Instrument Status 40006 Model / Modbus Address...

  • Page 18: Maintenance

    Model: 2852-LPS User Manual Rev: 0.0 40063 Temperature dC 40065 Compensated factor: percent per degree 40067 Temperature at Calibration 40069 Temperature offset [mV at 0dC] 40071 Temperature slope [mV per dC] MAINTENANCE There is no routine cleaning required for this controller.

  • Page 19: Troubleshooting

    5. “No TSnr”  Temperature sensor which is embedded in PMC2800-TMP is not wired to main controller OR not working properly. Verify wiring OR replace with new PMC2800-TMP pulse card. ARJAY ENGINEERING TECHNICAL SUPPORT (800) 387-9487 or +1 (905) 829-2418 www.arjayeng.com...

  • Page 20: Flow Charts

    Model: 2852-LPS User Manual Rev: 0.0 FLOW CHARTS...
  • Page 21 Model: 2852-LPS User Manual Rev: 0.0 SHOWN ONLY IF ENABLED BY FACTORY...
  • Page 22 Model: 2852-LPS User Manual Rev: 0.0 SHOWN ONLY IF ENABLED BY FACTORY...
