Summary of Contents for Alhafidh WHA-H18000T3S
- Page 1 WHA-C18000T3S WHA-C18000T3S WHA-H18000T3S WHA-H18000T3S WHA-H24000T3S WHA-H24000T3S WHA-C24000T3S WHA-C24000T3S...
- Page 2 SOCIABLE REMARK When using this unit in the European countries, the follow informations must be followed: DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separ- ately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal, there are seve- ral possibilities: A) The municipality has established collection systems, where electronic waste can be disposed of at least free of charge to the user.
-
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTIONS Warning ..........................3 Caution ...........................4 Points for using air conditioner ....................5 Unit identification ........................5 OPERATION INSTRUCTIONS Control panel ...........................6 Adjust air flow direction ......................8 Vent control ..........................8 CARE AND CLEANING Air filter cleaning ........................9 Cabinet cleaning ........................9 Winter storage .........................9 INSTALLATION INSTRUCTIONS Select the best location ......................10... -
Page 4: Safety Precautions
Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect opera- tion due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. -
Page 5: Caution
Safety Precautions CAUTION Ventilate well when used When the air filter is to be Do not clean the air removed, do not touch the together with a stove, etc. conditioner with water. metal parts of the unit. It may cause an injury. An oxygen shortage may occur. -
Page 6: Points For Using Air Conditioner
Safety Precautions Points for using air conditioner WARNING To reduce the risk of fire, electric shock, or injury to persons, read the Safety Precautions be- fore operating this appliance. NOTE: If the air conditioner is turned off, wait 3 minutes before restarting. This allows pressure inside the compressor equa- lize. -
Page 7: Operation Instructions Control Panel
Operation instructions Control Panel The control panel of the unit you purchased may look like one of the following: Cooling only models Cooling & Heating models AUTO SWING AUTO SWING SELECTOR THERMOSTAT THERMOSTAT SELECTOR HIGH HIGH HIGH COOL COMP. COOL COMP. - Page 8 Operation instructions THERMOSTAT Thermostat The thermostat is used to set the desired room temperature when the unit is being operated in the COOL MODE. To set the desired room temperature, rotate the thermostat switch to the desired setting. The temperature you are setting gets higher from to 1 , lower from 6 to 12 .
-
Page 9: Adjust Air Flow Direction
Operation instructions Adjust air flow direction Horizontal air flow adjustment AUTO SWING When the AUTO SWING switch is turned to ON position, the vertical louvers automatically oscillate right and left sweeping the cold air alternately to obtain comfortable cooling. The vertical louvers may be stopped at any position when the AUTO SWING switch is turned OFF . -
Page 10: Care And Cleaning
Care and cleaning Care and cleaning Air Filter Cleaning The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up Remove the and cause an accumulation of frost on the cooling coils. air filter Hold the slot under the front panel, then uplift it onwards, and remove the front panel. -
Page 11: Installation Instructions
Installation instructions Installation instructions Suggested tools AWNING 1. Screw driver (medium size Phillips) FENCE 2. Tape measure or ruler 3. Knife or scissors 4. Level gauge Select the best location 1. To avoid vibration and noise, make sure the unit is installed securely and firmly. -
Page 12: Dimensions
Installation instructions Installation of the unit into the Housing Flash or seal around external wall frame or architrave 1. Fit the drain pan to the housing and attach a drain tube to a suitable location if required. 2. Slide the unit into the housing until it is firmly against the rear Ensure louvres of the housing. -
Page 13: Treatment Of Condensed Water
Installation instructions TREATMENT OF CONDENSED WATER To meet different requirement of different type of air conditioner, there are two kinds of methods for your choice to treat the conden- sed water. For Cooling Only Models: You can choose back drainage or non-drainage. See the following procedures to perform back drainage: 1. - Page 14 Installation instructions Step 2. Remove the frame. 1. Remove the two fixing screws from the frame (See Fig.3). 2. Grasp the left corner of the frame's underside, then loosen the frame (See Fig.4). Fig.4 Fig.3 NOTE:For some models, the panel and frame are packed with the unit without installation.
-
Page 15: Troubleshooting Tips
Troubleshooting tips Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workman-ship or materials in this appliance. Problem Solution Wall plug disconnected. Push plug firmly into wall outlet. Air conditioner does not start House fuse blown or circuit breaker tripped.
