FEATURES
Outdoor bullet camera
20m IR distance
2 . 8
SPECIFICATIONS
Model Number
AS-HDX20-F CASE:G
Sensor Chip
1�4" Omnivision 1.0 MP sensor
/
TV System
NTSC PAL (selectable by OSD menu)
1.0MP
IR Distance
20 meters (24 pcs IR LED's)
Lens
2 . 8
0.01 Lux F1.2
>50dB
Scanning System
2:1 interlace scan
Up to 1100,000 s
Video Output
1Vp-p, 75Ω
Video Compression
N A
Bit Rate
N A
Max Image Size
N A
Frame Rate
N A
Streaming
N A
Protocol Compliancy
N A
Protocol
N A
Wide Dynamic Range
DWDR
Auto Gain Control
DNR
DNR
White Balance
Auto
Storage Temperature
30- to °60C
10- to °50C
٪95 max
Power Source
DC12V 450mA
AHD
/
/
/
/
/
/
/
/
DISTRIBUTED BY:
/
Yes
www.aswar-g.com
www.facebook.com�aswarME
/
AS-HDX20-F CASE:G
20m Outdoor Bullet Camera
NOTES:
Before providing power for the camera, please read this
user guide.
does not work, please contact us or your local distributor.
