Summary of Contents for Elife LA GRANDE
- Page 1 POWER ASSISTED BICYCLES LA GRANDE OWNERS MANUAL...
-
Page 2: Welcome To The World Of E.bike Cycling
Welcome to the World of e.bike cycling. Simply explained this is how your e.life bike basically works. POWER ASSISTED BICYCLES Press the button under the battery to ON. (Fig.12) Firstly may we congratulate Switch the power on by pressing the top left button on your controller on you on purchasing your new the handlebars. - Page 3 INDEX POWER ASSISTED BICYCLES Page 1 Welcome to E.Life Contents check list There arevideotutorials onlineoronIdealWorld’s website designed to assist you if you need help. Page 2 Index & CheckList 1. Your E.Life 2. Box containing: Page 3 Unpacking your new E.Life a.
-
Page 4: Unpacking Your New E.bike
Unpacking your new e.bike Your bike comes 100% assembled in the Carton POWER ASSISTED BICYCLES Before you begin to unpack your e.bike we recommend you get another person to assist you as it s much easier with 2 persons to lift out of the box. Remove all the packing materials used to protect the bike and dispose of it later in a responsible manner. -
Page 5: Fitting The Saddle
Unfolding your e.bike NOTE: Should you ever need to replace the pedals remember the right pedal tightens clockwise and the left pedal anti-clockwise. POWER ASSISTED BICYCLES Step 2. Pedals To fold the pedals for storage or transportation, pull the pedal outwards and fold downwards.) Photo shows pedal movement direction Fig.5... -
Page 6: Pre-Ride Checks
Pre-Ride Checks POWER ASSISTED BICYCLES Complete these checks before every ride Check to make sure all nuts/fastenings are tight Check that your tyres are inflated sufficiently (see tyre wall ) Check that the brakes are working correctly. (These are set by thefactory and should not require adjusting). -
Page 7: Understanding Your Controller
Understanding your controller Your Module Controller has many functions and is relatively simple to use, to the left is POWER ASSISTED BICYCLES listed the the buttons and their functions. Press to switch ON/OFF Press to increase assist level 0-3. Fig.11 Your Controller is ÿtted to the left side of the Handlebar. -
Page 8: Understanding Your Battery
Understanding your battery 1. Security POWER ASSISTED BICYCLES You are supplied with 2 keys to secure your battery to your bike. It is advisable to separate the keys as they cannot be replaced iflost. Insert the key and unlock the battery enabling you to remove for security or to charge away from the bike. -
Page 9: Charging Your Battery
Charging your Battery POWER ASSISTED BICYCLES Your Lithium Battery arrives partially charged. Your Battery can be charged on or off your bike. Plug your charger into the mains, the LED light will illuminate GREEN Connect the charger to the battery using the lead provided, the LED light on the charger will change to RED. -
Page 10: Weekly Inspection
Maintenance of your e.bike General POWER ASSISTED BICYCLES Wipe your bike over with a dry cloth, or neutral detergent. Use lubrication oil for metal parts. i.e. chain, axles. Wipe down Plastics, paint coated parts with a quality cloth. Increase the frequency of lubricating oil at wet or humid areas ( Recommend 30SAE lubricating oil) Weekly Inspection It is recommended that after this period you should inspect your bike as... -
Page 11: Simple Troubleshooting
Simple Troubleshooting Problem Check Action POWER ASSISTED BICYCLES Low Speed battery power Charge Battery Tyre pressure Inflate tyre If unsure on any of these If tyre flat Repair tyre points, or you fail to correct Load Do not overload the problem, please call the helpline who will be able to The Motor is not Every plug... -
Page 12: Warranty
Warranty Subject to the following, Ideal World warrants that the goods will correspond with their specification at the time of POWER ASSISTED BICYCLES purchase and will be free from defects in material and workmanship. Ideal World offers a 2 year warranty on the frame from any problems relating to manufacturer workmanship or arising from material defects including breakages or cracking caused whilst riding ( other than rider misuse). - Page 13 Replacement Batteries & Chargers Replacement batteries and chargers are available to fit your bike and can be purchased POWER ASSISTED BICYCLES separately from Ideal World. Should you ever need to remove or replace your pedals it is important to know that left-hand pedal screws in ANTI-CLOCKWISE and the right-hand pedal screws in CLOCKWISE.
- Page 14 Nation service Centre ELIFE have teamed up with POWER ASSISTED BICYCLES IMPORTANT! PLEASE REMEMBER THAT to offer all Ideal World customers a IT IS IMPORTANT TO KEEP Nationwide Service for your e.bike. THE CARTON YOUR BIKE If you live in Scotland or Cornwall or...
- Page 15 Therearevideotutorialsonlineor onIdealWorld’s website designed to assist you if you need help. POWER ASSISTED BICYCLES DistributedintheUKby Ideal World Please call our Ideal Home House, Technical help line: (weekdays 9am-5pm) Newark Road, 01702208187 Peterborough, PE1 5WG (standard call rate charge applies)
