2. General description of the product
a. Technical specification
Model:
Port:
End connection:
Service fluid
Service temp.
Nominal Size NPS
Nominal Size DN
Nominal pressure LBS
Shell Material
Note 1: User shall consider the material's anti-corrosion feature of components which directly contact
with the fluid. The corrosion data information is available in this user manual.
b. Safety features
Appropriate shell strength
Anti-blow out stem design
Anti-static design
Pressure release hole at ball
Pressure release channel at ball seat
c. Dimensions and Parts list
See the following drawing for the detailed
external dimensions of each nominal size,
the components list and materials available.
User shall
anti-corrosion feature of seals and packing
which directly contact with the fluid. The
corrosion data information is available in this
user manual.
d. Equipment category according to ATEX
Directive (94/9/EC)
Designed and
engineering practice and the ignition hazard
assessment ensure that the equipment does
not contain any effective ignition sources in
normal operation and during expected
malfunctions. Therefore we classified as
Group II, Category 2 equipment. The Type
of ignition protection is 'c', constructional
safety according to EN 13463-5:2003.
Gate valve
Standard Port
Flanged end
Dangerous or non-dangerous gas or liquid
-20° C to 180°C
2" 2½"
50 65
300 300
consider the material's
constructed to
3" 4"
80 100
300 300
ASTM A351 Gr.CF8M
e. Equipment category according to PED
Directive (97/23/EC)
Nominal Pressure
CLASS 300
good
6" 8" 10"
150 200 250
300 300 300
S.E.P Category II
12"
300
300
DN50
DN65
DN80
DN100
DN150
DN200
