Summary of Contents for Nitto Fantasy Forest Bowling
- Page 1 Fantasy Forest Bowling User Manual （Please read this User Manual carefully before you installing this product.）...
-
Page 2: Table Of Contents
Content Ⅰ．Features and description of games............1 Ⅱ． DIMENSION AND TECHNICAL PARAMETER......2 Ⅲ. ENCLOSED LIST OF THE MACHINE..........3 Ⅳ．METHODS OF PUT ,FIXED AND MOVED........4 V、 Power connection method..............5 VI. Power box description................6 VII. Use and maintenance guide..............6 VIII. -
Page 3: Ⅰ．features And Description Of Games
Ⅰ．Features and description of games Features 1．Carnival machine of lottery 2．The methods of playing the games are new, exciting and full of leisure entertainment 3 ． The shape design are elegant, colorful patterns, delicate and use exquisite materials 4 ． Using large-scale integrated circuits, which built-in programs. The functionality are stable and reliable 5. -
Page 4: Ⅱ． Dimension And Technical Parameter
Ⅱ． DIMENSION AND TECHNICAL PARAMETER 1． Working voltage: AC220V ± 5%50Hz (or AC 110V ± 5%,60Hz, specific voltage, please refer to the nameplate of the machine); Maximum power consumption: 500 W； Overall dimensions: ：W2500*D3600*H2500 （mm）; 2500 3600 2500 4. Weight:：About 400 kg; 5. -
Page 5: Ⅲ. Enclosed List Of The Machine
Ⅲ. ENCLOSED LIST OF THE MACHINE FOR USING THE MACHINE SATELY, PLEASE CHECK WHETHER IT INCLUDS ALL THE PARTS BELOW BEFORE YOU USE. ONE MAINFRAME SPART PARTS, LIST OF THE TABLE BELOW: NAME SIZE UNITE PICTURE REMARK 1．8m POWER WIRE 5XΦ20mm Insurance tube MANUAL... -
Page 6: Ⅳ．methods Of Put ,Fixed And Moved
METHODS OF PUT ,FIXED AND MOVED Ⅳ． 1. This machine is suitable for indoor use, they are not allowed for outdoor use. Outdoor use will affect the performance of the machine. Mounted range size:Machines should be placed, there is enough 2．... -
Page 7: Power Connection Method
V、 Power connection method Attention 1. the power cord cannot be heavy pressure, which can damage the wires easily to short circuit, and in severe cases may cause fire. 2. When you unplug the power cord from outlet, grasp the plug has been removed, can not catch wires to unplug. -
Page 8: Power Box Description
Power box description 电源开关 Power supply 电源插座 Power socket 1. This machine uses“220V±5% 50HZ（or 110V±5% 60HZ）。 2. insurance device installed the exchange insurance，the size is“220V 5A diameter is 20mm（or 110V 10A diameter 20mm）。 3. power switches are used to connect/shut off connection. 4. - Page 9 to the Board, and no device 3．Don't arbitrarily split the Royal, Assembly, alter equipment. This can cause fire or an electrical short circuit, mechanical failures, and so on. 4 ． Confirm the move, flip, transport and so on to meet manufacturers request.
- Page 10 12．Does not stretch, distort, hard folding power line, power line exposed to high humidity cannot be object. These practices have damaged wires, causing short circuits and fires. 13．Power cord can not be kicked or contact easily. This will harm the human body and damage the machine 14．Power cord cannot easily be kicked or have access to.
-
Page 11: Error And Trouble Shooting
VIII. Error and Trouble shooting Error solution 1.The computer and IO board are 1.Please check the COM line, and pull it disconnected. out and re-plug it. 2.The IO board is broken. 2.Please contact after-sell. 1.Press the restore button of ticket 1.Ticket dispenser error. -
Page 12: Sensors Introduction And Repair Instruction
Sensors Introduction and Repair Instruction Sensor：transmitter and receiver. Normally, the transmitter lights up all the time, and the receiver would not light up. If the receiver lights up, it means that it is not aligning to the corresponding transmitter or it is blocked by something. ... - Page 13 Jungle Fantasy Bowling IO connecting V1.0 Input： ADC: INPUT Content INPUT Content INPUT Content Item Content Content 1P ray input 1 purple 1P ray of ball check blue IN17 2P ray input 3 orange +3.3V 1P ray input 2 grey IN10 1P ray of ball delivery purple IN18...
