Summary of Contents for Mira Leap Walk In
- Page 1 Leap Walk In These instructions must be left with the user Installation Guide 1245548-W2-A...
- Page 2 1245548-W2-A...
-
Page 3: General Information
INTRODUCTION Thank you for purchasing a quality Mira product. To enjoy the full potential of your new product, please take time to read this guide thoroughly, having done so, keep it handy for future reference. The following pages aim to provide comprehensive installation instructions, plus advice on how to care and maintain your product. -
Page 4: Recommended Usage
Ensure the size of door/panel is suitable for the installation. Tempered safety glass cannot be cut. Ensure nothing can impact the door or glass panels during operation. When Fitting the Enclosure The wall channels must be installed onto a tiled or waterproof finished flat and even wall surface. -
Page 5: Pack Contents
PACK CONTENTS Tick the appropriate boxes to familiarise yourself with the part names and to confirm that all of the parts are included. 1700 Top Cap Slotted 1400 Top Cap Grub Screw Filler Cap Allen Grub Screws RH Lintel Glass LH Lintel Glass Mounting Block Mounting Block... - Page 6 INSTALLATION FITTING INSTRUCTIONS Fit the curved panel wall channel to the wall. The tray should be fitted and the walls tiled before installation of the enclosure. Mark the position of the wall channel from the wall tiles on the back wall. NOTE: LH VERSION SHOWN.
- Page 7 Carefully slide the jamb onto the wall channel. Place the corner of the glass into the mounting block. Wall channel Jamb STEP Adjust the glass until it is vertical and equally Carefully remove the curved panel from the tray. spaced around the lip of the tray. Remove the mounting block.
- Page 8 Carefully lift the curved panel back into place and Drill 3 x 3mm holes through the jamb into the check that the glass is vertical and equally spaced wall channel. around the lip of the tray. Secure the jamb to wall channel with 3 x screw B.
- Page 9 Place the lintel on top of the glass. Fit the corner glass gasket to the glass then place the lintel glass mounting block on top. Ensure the glass is vertical and and the lintel is horizontal. When the lintel is horizontal and the inner edge of the wall mount is against the mark, draw around the wall mount.
- Page 10 If any adjustment is required, move the lintel in or out until the glass is vertical. Ensure the glass is vertical and and the lintel is horizontal. When the glass and lintel are in the correct position tighten the grub screws at both ends. STEP Fit the cover strip.
-
Page 11: General Maintenance
MAINTENANCE General Maintenance Providing the shower enclosure has been correctly installed and is operated in accordance with the instructions contained in this guide, difficulties should not arise. If any maintenance is required then it must be carried out by a competent tradesperson to whom the maintenance instructions are provided. - Page 13 NOTES 1245548-W2-A...
- Page 14 NOTES 1245548-W2-A...
-
Page 15: Declaration Of Performance
The performance of the products described above, are in conformity with the relevant community harmonisation legislation. This declaration of performance is issued under the sole responsibility of Kohler Mira Ltd. Signed for and on behalf of Kohler Mira Ltd. Signature:... - Page 16 United Kingdom and the Republic 5 013181 080216 of Ireland). Ask about our fi xed price service repairs. Mira is a registered trade mark of Kohler Mira Limited. The company reserves the right to alter product specifi cations without notice. 1245548-W2-A...
- Page 17 Shower Screens From Top Brands Coram Shower Enclosures Mira Shower Enclosures Hydrolux Shower Enclosures Diamond Shower Enclosures With quality shower trays to match your enclosure Square Shower Trays Rectangular Shower Trays Quadrant Shower Trays Coram Shower Trays Mira Flight Shower Trays...
