Xeleum Hercules G2 Series Installation Manual

READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
SAVE THIS GUIDE FOR FUTURE
REFERENCE
WARNING!
Risk of Electric Shock. Turn power
off before installation or servicing.
1) Suitable for Installation in wet locations (IP66 rated)
2) Follow all standards specified by the NEC for installation. Consult a local licensed
electrician or electrical contractor if you are unsure.
3) When using electrical equipment, basic safety precautions should always be
followed. Ensure the local voltage corresponds to the fixture's working voltage.
4) Fixture has substantial weight. Use assistance and take care during mounting.
5) Always ensure the fixture is secure when mounted, temporarily or permanently,
at any height above ground.
www.xeleum.com
Xeleum Lighting, LLC. 3430 Quantum Blvd. Boynton Beach, FL 33426 * Phone 954 617 8170 * Fax 954 571 9777 * www.xeleum.com

IMPORTANT ADVISORIES AND SAFEGUARDS

Hercules G2 Series
LED Sports Light and High Power
High Bay

Installation Guide

General Product Information

The Hercules G2 is a high-power High Mast or Sports
Lighting LED luminaire. Designed for outdoor
applications and providing superior illumination for wide
areas such as sports fields. The housing is designed for
efficient heat dissipation. Fixture is waterproof,
dustproof, anticorrosive.

Unpacking

This fixture has been packed carefully with the intent to
prevent damage from occurring during shipment.
Inspect the contents to confirm.

Fixture Specifications

Input 120-277VAC and 480VAC. Dimensions max.
(22.9x18.6x18.6)in. Weight: (35, 67, 89)lbs. Packaged.
IP66, UL1598 Certified.
Page 1 of 10
