Gardner Bender SP-7 Manual

Exclusively from Gardner Bender, new SnapSHOT™ Universal Stud Insulators provide
code mandated* 360° protection for cable runs through increasingly poplar metal
studs, where sharp hole edges could otherwise gouge plastic or rubber-jacketed
electric, communications or network cable. The patented one-piece design and folding
tabs make installation literally a snap, resulting in a tight and secure attachment
to the stud. The smooth, hang-free surface eases pulls, while the high-density
SnapSHOT™ design accommodates any shape pre-punched hole or standard 1¹¹/ ³² "
field-punched holes.
Code-compliant protection for NM Cable in
both factory and field punched metal studs.
Feature Comparison
Fits factory punched holes/standard holes
Easy to install design
One-piece installation
UL approved
REPAIR AND SERVICE INSTRUCTIONS: For repair service and parts contact your nearest Gardner Bender Service Center.
The Gardner Bender Service Center will provide complete and prompt service on all Gardner Bender products.
PARTS AND SERVICE: For quality workmanship and genuine Gardner Bender parts, select an Authorized GB Service Center for your repair needs.
Only repairs performed by an Authorized Service Center displaying the official GB Authorized sign are backed with full
factory warranty. Contact Gardner Bender (414)352-4160 for the name of the nearest GB Authorized Service Center.
WARRANTY: Gardner Bender warrants its product against defects in workmanship and materials for 1 year from date of delivery to user.
Warranty does not cover ordinary wear and tear, abuse, misuse, overloading, altered products or use of improper fluid.
WARRANTY RETURN PROCEDURE: When question of warranty claim arises, send the unit to the nearest GB Authorized Service Center for inspection, transportation
prepaid. Furnish evidence of purchase date. If the claim comes under the terms of our warranty the Authorized Service Center
will REPAIR OR REPLACE PARTS AFFECTED and return the unit prepaid.
IMPORTANT: RECEIVING INSTRUCTIONS
Visually inspect all components for shipping damage. If you find damage, notify the carrier at once. Shipping damage is NOT covered by warranty.
The carrier is responsible for all repair or replacement costs resulting from damage in shipment.
www.gardnerbender.com
PO Box 3241 Milwaukee, WI 53201-3241 | 414.352.4160 | fax 414.352.2377
6615 Ordan Drive | Mississauga, Ontario L5t 1x2 | 905.564.5749 | fax 905.564.0305
RPS-0153 | February 2007
STUD PUNCH ACCESSORIES
Patented One-Piece Design
*Meets requirements of NEC Article 300-4(b) and CEC Rule 12-516.
• •
•
•
•
Part # Description Pkg
SI-25 Metal Stud Insulator Bag
SI-100 Metal Stud Insulator Bag
• •
• •
Qty
25
100
CAUTION
!
Read & understand
before operating product. Failure to understand safe
operation of this tool can cause injury.
GARDNER BENDER is not RESPONSIBLE FOR DAMAGE OR INJURY CAUSED BY UNSAFE USE, MAINTENANCE OR
THE APPLICATION OF ITS PRODUCTS. Please contact Gardner Bender for guidance when you are in doubt as to the
proper safety precautions to be taken in designing and setting up your particular application.
PO Box 3241 Milwaukee, WI 53201-3241 | 414.352.4160 | fax 414.352.2377
6615 Ordan Drive | Mississauga, Ontario L5t 1x2 | 905.564.5749 | fax 905.564.0305
Stud Punch
Punches 1
or pipe in aluminum and mild steel studs
this instruction book completely
R E PAI R PAR TS S H E E T
www.gardnerbender.com
RPS-0153 | January 2007
SP-7
⁄ " holes for ½" to 1" conduit
11
32
