Summary of Contents for Alfa Network Data Traveller
- Page 1 User Manual...
-
Page 2: Product Overview
Product Overview 1: Proximity Sensor 2: Receiver /Speaker 3: LCD Touch Display 4: LED Indicator (Red - Low Battery; Yellow - Normal; Green - High Battery) 5: Micro USB Port (Input) 6: SIM Slot 7: USB Port (Output) 8: Microphone 9: Volume Down Button 10: Volume Up Button 11: Power Button... - Page 3 User Interface 1. Device info 2. Data Consumption 3. Number of device connections 4. Battery level 5. SIM card signal strength 6. More info...
- Page 4 Product Info Brand：Alfa Data Traveler Box Content: Device, User Manual, Micro USB cable Note: Adapters (Charging) 100-240V~50/60Hz 0.15A are recommended Technical Specification： • LTE FDD: Band 1/2/3/4/5/7/8/9/17/19/20 • LTE TDD: Band 38/39/40/41 • WCDMA: Band 1/2/4/5/6/8/9/19 • CDMA/EVDO: BC0 BC1 •...
- Page 5 Quick Start Guide Step 1: Subscribe to an Alfa Data Traveler bundle If you are not subscribed to a data bundle yet, you can start by activating a data bundle through Alfa website, by SMS or by dialing *111# from your Alfa line. For more info, please follow the steps below: From Alfa website https://www.alfa.com.lb...
-
Page 6: How To Use The Power Bank
Quick Start Guide Step 2: Turn on the router Press the power button for 3 seconds, once it’s on, the homepage will be displayed as below: Step 3: Switch on the Wi-Fi on your smartphone, to connect to the Wi-Fi network of Alfa Data Traveler router (Wi-Fi name is shown on the homepage), enter the Wi-Fi password, once connected you can enjoy the internet How to use the Power bank... -
Page 7: Change The Password
Quick Start Guide Change the password The password of the router can be modified in “Wi-Fi settings” page. Local SIM Guide 1. Local SIM is supported by the router, which has two SIM slots (both are Nano SIM Slots) 2. Open the SIM card tray with a needle, and insert the SIM card as shown in the picture below. Please contact customer service if any issue encountered. -
Page 8: Apn Setting
Quick Start Guide & FAQ APN Setting Follow the steps below to set the APN for local SIMs on the router: 1) Insert the local SIM, and select it in “SIM Manager” page 2) Click “Local SIM” on the homepage 3) Click “Data Connection”... - Page 9 Warning Specific Absorption Rate (SAR) information. SAR tests are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value, in general, the closer you are to a wireless base station antenna, the lower the power output.
- Page 10 Warning Information on the disposal and recycling of the device This symbol (with or without a solid bar) on the device, batteries (if included), and/or the packaging, indicates that the device and its electrical accessories (for example, a headset, adapter, or cable) and batteries should not be disposed of as household garbage. These items should not be disposed of as unsorted municipal waste and should be taken to a certified collection point for recycling or proper disposal.
