Ultratune SBT247 Owner's Manual

6v/12v wireless battery and system tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SBT247
6V/12V Wireless Battery and System Tester
OWNERS MANUAL
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
WARNING
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH.
0099002064-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBT247 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ultratune SBT247

  • Page 1 SBT247 6V/12V Wireless Battery and System Tester OWNERS MANUAL READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT. WARNING FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH. 0099002064-00...
  • Page 2 IMPORTANT: READ AND SAVE THIS SAFETY AND INSTRUCTION MANUAL. SAVE THESE INSTRUCTIONS – This manual will show you how to use your tester safely and effectively. Please read, understand and follow these instructions and precautions carefully, as this manual contains important safety and operating instructions.

  • Page 3: Personal Precautions

    WARNING RISK OF EXPLOSIVE GASES. 1.6 To reduce the risk of a battery explosion, follow these instructions 1.5 WORKING IN THE and those published by the battery VICINITY OF A LEAD-ACID manufacturer and the manufacturer BATTERY IS DANGEROUS. of any equipment you intend to use in BATTERIES GENERATE the vicinity of the battery.

  • Page 4: Preparing The Battery

    3. PREPARING THE BATTERY RISK OF 3.4 If the battery is not a sealed WARNING WARNING CONTACT WITH maintenance-free battery, check the BATTERY ACID. level of each cell and if necessary, BATTERY ACID add distilled water until the battery IS A HIGHLY acid reaches the level specified by CORROSIVE SULFURIC ACID.

  • Page 5: Installing The App

    5. INSTALLING THE APP 5.1 Download and install the App: 5.2 NEW USER SETUP “SBT247 Ultratune” When using the App for the first time, (Apple store or Google Play). you must complete Registration. Look for the icon. 1. Open the App on your mobile device.

  • Page 6: Battery Test

    OPERATING INSTRUCTIONS 7.1 BATTERY TEST 1. Open the App on your mobile device and log in. 2. Press “Scan+” in the upper right corner of the HOME screen. (If the TEST icon is red, the tester is connected; no need to proceed to In this screen, the user may create Scan+.) a name for the tester.
  • Page 7 7. Select “BATTERY TEST”. 9. Confirm whether the battery has been charged. Set up test by swiping up or down on each column to select Battery Type, Rating and Set Capacity (or Rated CCA). 10. The test report is displayed. 8.

  • Page 8: System Test

    11. Press “EMAIL /TEXT RESULTS”, 7.2 SYSTEM TEST and then select the application. 1. Follow steps 1-6 for "BATTERY TEST". NOTE: Your mobile device must 2. From the TEST menu, select have text capability to use the TEXT “SYSTEM TEST”. RESULTS feature.
  • Page 9 6. Press “EMAIL /TEXT RESULTS”, and then select the application. NOTE: Your mobile device must have text capability to use the TEXT RESULTS feature. 7. Results will be sent. 7.3 EV BATTERY TEST 1. Follow steps 1-6 for "BATTERY TEST". 2.

  • Page 10: Start-Stop Test

    5. The test report is displayed. 4. Follow all screen prompts. 6. Press “EMAIL /TEXT RESULTS”, 5. The test report is displayed. and then select the application. 6. Press “EMAIL /TEXT RESULTS”, NOTE: Your mobile device must and then select the application. have text capability to use the NOTE: Your mobile device must TEXT RESULTS feature.

  • Page 11: Specifications

    8. SPECIFICATIONS Connectivity ...............Wireless 4.0 class 2 (BLE) Radio frequency range..........2.402 GHz ~ 2.480 GHz Maximum radio frequency transmitted power ........4.18 dBm Internal battery ..........Lithium ion battery 3.7 V, 1150 mAh Operation range ..............40~2,000 (CCA/SAE) Voltage range ..................1.5V~32V Rating system ..............SAE, DIN, EN, IEC, CA Wireless connection range............10m (32.8 feet) Ingress protection rating ................IP65...
  • Page 12 c. Manufacturer does not have any warranty obligations if the alleged defects were caused by abnormal usage, fair wear and tear, unauthorized use of the Product or use of the Product differing from the description in the applicable manual or other specifications given by the Manufacturer, insufficient care, repairs carried out by persons or entities or with parts not approved by Manufacturer, poor care, accidents, unauthorized changes or modifications, incorrect transport,...
