SP206
INSTRUCTIONS
Supplied by Laser Levels Online – The Laser Level Specialists
www.laser-level.co.uk
Tel: 08000 869 769
Thank you for purchasing the Orient SP206
RED
beam, rotating laser kit.
These instructions are intended to explain the quick basics to operating this
equipment. Please read them carefully.
For any more information, or if the laser requires calibration or repair; then
please contact our Service Department on Tel. 01246 260 007.
Email: sales@laser-level.co.uk We are here to help.
Power source:
This is a special battery pack located in the base of the laser. Remove & refit
via a central screw - finger tight (no tools are required).
It contains 4pc x "sealed for life" Ni-MH type C, 3500mAh, 1.2V cells. Please
note that this battery pack can be charged either in or outside of the laser.
The Mains Charger (supplied) will charge these batteries in around 7 hours to
give around 40 hrs of continuous use. It takes 4 to 5 charge/discharge cycles
for these battery packs to reach their maximum capacity.
Important: Do NOT allow battery to go completely dead before recharging.
1
Advertisement
Table of Contents
Summary of Contents for Orient SP206
- Page 1 Supplied by Laser Levels Online – The Laser Level Specialists www.laser-level.co.uk Tel: 08000 869 769 Thank you for purchasing the Orient SP206 beam, rotating laser kit. These instructions are intended to explain the quick basics to operating this equipment. Please read them carefully.
- Page 2 Even though the Green light is ON, we still recommend a full 6 hour charge. The SP206 can be operated with the charger connected to the mains supply, if required and site conditions permit. On receipt of your new laser, we suggest charging the batteries fully for approx.
- Page 3 Exterior Groundworks – run the SP206 at its maximum speed of 600rpm, which gives the best working range when used with the supplied Laser Detector. Even with its bright Red beam, a detector will still be required for most outdoor work.
- Page 4 Operated via top, right-hand yellow button, showing a "picture of a tilted instrument". Once the SP206 is ON and rotating in the auto (self) levelled mode, the automatic drift system can be activated. Press the button & the green LED will flash continually.
- Page 5 If the sun is low in the sky & shining into the red window, shield it with a cupped hand to prevent false readings. Positioning the SP206 itself in full sun is no problem, but the detector window can, in some instances, be affected by direct bright sunlight or reflections.
- Page 6 Laser accuracy +/-3.9mm @ 30m. Operating range 20m (visible) or 500m diameter with detector. IR Remote control range: 20m ...for full details, see website data for SP206 at www.laser-level.co.uk There are NO User Serviceable Parts. (This would void the warranty) We offer a full Back-up service including repairs, calibration &...
