Summary of Contents for Smartlink Smartfall-Blue
- Page 1 Smartfall-Blue The intelligent pendant with auto fall detection & Bluetooth LE capabilities User Guide Product Number 106-383...
-
Page 2: Table Of Contents
Contents Intended use What is the Smartfall? What is in the box? Before first use Wearing the Smartfall … … on a neck chain “Recommended” ......8 … as a brooch/clipped to clothing ......9 … on a belt ............... 10 Important things to remember How it works Manual alarm operation... -
Page 3: Intended Use
Intended use This device is intended to enable a user in a non- medical setting to request assistance by providing a method of activating their home base unit, from within the operating range, in the event of a potential medical emergency. The device also provides an additional automatic request for assistance to the home base unit if it detects that the user has fallen while wearing it... -
Page 4: What Is The Smartfall
What is the Smartfall? Your Smartfall is an intelligent pendant. Like other pendants, it allows you to press a help button to generate an alarm call when you need help. The Smartfall also provides an added layer of protection by automatically generating a call for assistance if a fall is detected and you are unable to push the help button. -
Page 5: What Is In The Box
What is in the box? The box contains this user guide, a Smartfall intelligent pendant and neck chain, Smartfall Neckchain intelligent pendant... -
Page 6: Before First Use
Before first use Ensure the Smartfall is programmed correctly to your home base unit. To test this, press the help button and ensure that it generates an alarm call to the monitoring center. Tell the monitoring centre that you are making a test call and follow their instructions. -
Page 7: Wearing The Smartfall
Wearing the Smartfall … Your Smartfall will have been setup with a specific wearing accessory. Once setup you should not change the wearing accessory without contacting your supplier. The correct wearing positions for the different wearing accessories available are shown on the following pages. -
Page 8: On A Neck Chain "Recommended
WARNING – if you wear the Smartfall under your clothing ensure you do not restrict access to the help button. … on a neck chain “Recommended” A neck chain is provided which may be adjusted to ensure the Smartfall is worn at the same height as your sternum and at least one metre [3 ft.]... -
Page 9: As A Brooch/Clipped To Clothing
WARNING – only use the neck chain supplied with the Smartfall as it includes safety break links to reduce the risk of entanglement or injury. Taking off/Putting on the Smartfall Avoid trying to adjust the length of the neck chain each time you take off/put on the Smartfall. …... -
Page 10: On A Belt
The Smartfall must be worn at chest height and at least one metre [3 ft.] from the floor when using a clothing clip. … on a belt If any type of belt clip is used (Not Supplied) please ensure that the belt clip is fixed to firmly hold the Smartfall in place. -
Page 11: Important Things To Remember
Important things to remember Remember, the Smartfall will only detect a fall if you are wearing it. Due to the wide variety and type of falls, some falls may not be detected. For example, a slow gradual slide out of a chair is unlikely to be detected as a fall. -
Page 12: How It Works
How it works The Smartfall is a simple to use device that includes a help button to enable you to generate a call for help if you require assistance or fall. If you are unable to press the help button, the Smartfall has intelligent sensors that will automatically generate a call for assistance if a fall is detected. -
Page 13: What Happens If You Fall
If the red LED flashes, the Smartfall is still sending an alarm call, but is also indicating to you that the battery needs to be replaced (see battery replacement). What happens if you fall Stage 1 The Smartfall detects an event and analyses it for a few seconds. -
Page 14: Cancelling An Automatic Fall Alarm
Cancelling an automatic fall alarm If the Smartfall lights flashes the green LED and plays high/low/high tones every second when you know you have not fallen, you can stop the Smartfall from generating an alarm by tapping the case 3 or more times rapidly. Tap case 3 times rapidly to cancel Help button... -
Page 15: Taking Care Of The Smartfall
Taking care of the Smartfall Your Smartfall is fully water resistant and should be worn at all times including in the shower and bath. When wearing in the bath you should avoid submerging the Smartfall in water for more than a minute. ... -
Page 16: Cleaning
Cleaning If required, the Smartfall may be cleaned periodically with a damp cloth and mild detergent or an alcohol wipe. Remember that the Smartfall will not detect falls while it is not being worn therefore you should put the Smartfall back on again as soon as you have finished cleaning it. -
Page 17: Battery Replacement
Battery replacement The battery will need replacing approximately every 12 to 24 months. When a low battery is indicated the battery should be replaced immediately/as soon as possible. If it is necessary for you to change the battery, the fall detector uses a CR2430 3 Volt lithium battery. -
Page 18: To Replace The Battery
To replace the battery 1) To access the battery, turn the battery cover anti-clockwise to the unlocked position, replace the battery then replace and lock the battery cover in a clockwise rotation. 2) NOTE. Insert the new battery with the Positive (+) side facing downwards in the lid. -
Page 19: Frequently Asked Questions
Frequently asked questions Can I wear the Smartfall in the shower or bath? Yes, the Smartfall is fully water resistant and should be worn at all times including in the shower. When wearing in the bath you should avoid submerging the Smartfall in water for longer than a minute. - Page 20 Can I wear the Smartfall under my clothes? Yes, the Smartfall can be worn under clothing however please make sure you can easily press the help button if you need assistance. What happens if I accidentally press the help button? The Smartfall will generate a call to the monitoring center.
- Page 21 If I stand up again after falling, will the Smartfall automatically call for help? Possibly, the Smartfall is designed to allow a short period of time after a fall for you to recover. Don’t forget when the Smartfall starts to beep and the green LED is flashing you can cancel the alarm to stop it from sending a call for help.
- Page 22 What happens if I cannot press the cancel button to stop the alarm? The cancel function has been designed to prevent accidental cancellation of alarm calls. The Smartfall has also been designed to avoid activation when you have not fallen. If you cannot cancel the alarm for any reason, don’t worry, just inform the monitoring center operator that you are ok and do not require assistance.
- Page 23 Can I wear the Smartfall in bed? Yes, if you wish you can wear the Smartfall in bed. This will help to ensure the Smartfall is to hand if you require it at night. However it may not detect a fall from a lying position in bed to the floor.
-
Page 24: Test Conditions
Test Conditions The Smartfall has been tested under the following user height conditions: Neck worn – minimum user height 4ft 6in (137cm) Waist worn – minimum user height 5ft (153cm) A reduction in performance may be experienced with users below these heights. NB: Fall detector option is disabled from the factory. -
Page 25: Troubleshooting
Troubleshooting If the area around the button becomes damaged please contact your supplier. LED operation Event LED/Sounder action Action Red LED on for 2 seconds If possible, Alarm and unit beeps rapidly 3 speak clearly to button times . If Red LED flashes the monitoring pressed battery is low. -
Page 26: Specifications
Specifications The Smartfall operates on a frequency of 915 to 928 MHz (Australia & New Zealand). Technical information Weight: 25g [0.88oz] Dimensions: 52 x 32 x 12mm [2.1” x 1.3” x 0.45”] (WxHxD) Battery: CR2430 (3v Lithium cell) Battery Life: 12 to 24 months Radio Freq: 915 to 928 MHz... - Page 27 To the best of our knowledge, the information contained in this manual is correct at the time of print. SmartLink “A division of NESS CORPORATION PTY LTD” reserves the right to make changes to the features and specifications at any time without prior notice in the course of product development.
- Page 28 “A division of Ness Corporation Pty Ltd”...
Need help?
Do you have a question about the Smartfall-Blue and is the answer not in the manual?
Questions and answers
I cannot turn the battery compartment around to the change the battery on the Smartfallblue pendant. . It looks like it has seized after a year of use. what do I do? How do I open compartment to change battery. Any suggestions?
To open the battery compartment on the Smartlink Smartfall Blue pendant:
1. Turn the battery cover anti-clockwise to the unlocked position.
2. Remove the old battery.
3. Insert a new CR2430 battery with the Positive (+) side facing downwards in the lid.
4. Replace the battery cover and turn it clockwise to lock it.
This answer is automatically generated
