Woodley g-Pet User Manual

Glucose veterinary monitoring system
Hide thumbs Also See for g-Pet:
Table of Contents

Advertisement

Quick Links

Download this manual
Veterinary Monitoring System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the g-Pet and is the answer not in the manual?

Questions and answers

Related Manuals for Woodley g-Pet

Summary of Contents for Woodley g-Pet

  • Page 1 Veterinary Monitoring System...

  • Page 3: Table Of Contents

    About the Product ....................3 About the g-Pet Meter ................4 About the g-Pet Meter Display ...............6 About the g-Pet Test Strip ..............8 About the g-Pet Test Strip vial ..............9 About the Glucode Chip ...............10 Installing/Replacing the Battery ............11 Setting Up the Meter ..................12 Setting Up the Date, Time ..............12...
  • Page 4 The Control Solution Test .................20 Blood Glucose Testing ..................24 Preparing the Test Strip ...............25 Obtaining a Blood Sample ..............26 Applying Blood Sample to the g-Pet Test Strip ........27 Memory Features .....................29 Care and Storage .....................31 Display Messages ....................32 Specifications ....................39 Limitations of the Procedure ..............40...

  • Page 5: About The Product

    About the Product Your g-Pet System is made up of several components. This booklet is designed to guide you through the operation of the system with detailed directions and pictures. Your g-Pet System contains: ● g-Pet Meter ● One vial of g-Pet Test Strips (10 strips) ●...

  • Page 6: About The G-Pet Meter

    About the g-Pet Meter FRONT BACK...
  • Page 7 1. Display Your test results are displayed here. The large, easy to read screen guides you through the test by using numbers and symbols. 2. M Button The M (mode) button is used to set the year, month, day and time, enters the memory mode to show the consecutive 7/14/30-day average results, and turns the Meter on and off.

  • Page 8: About The G-Pet Meter Display

    About the g-Pet Meter Display 1. Date 2. Time 3. Control Solution Test Appears when doing a control solution test and marking the result as a control solution test. 4. Units of Measurement Unit of mmol/L or mg/dL will appear with the test result.
  • Page 9 6. Memory Symbol Indicates in memory mode. 7. Temperature Message Appears if your meter is out of operating temperature range. 8. Battery Symbol Appears when the battery is low or must be replaced. 9. Blood Drop Symbol Flashes when it is ready to apply sample to Test Strip.

  • Page 10: About The G-Pet Test Strip

    About the g-Pet Test Strip The g-Pet Test Strip is used to perform the blood glucose test in conjunction with the g-Pet Meter. Each strip can be used only once. 1. Confirmation Window This is where you can confirm that enough blood has been applied to the target area.

  • Page 11: About The G-Pet Test Strip Vial

    About the g-Pet Test Strip Vial VIAL LABEL TEST STRIP VIAL For Veterinary Use Only Store in a dry place at 4-30°C ( 39-86°F). Date opened........Do not refrigerate. meter only ! Do not store test strips outside this vial.

  • Page 12: About The Glucode Chip

    About the Glucode Chip Each g-Pet test strip vial is supplied with three glucode chips. One for cats, one for dogs and one for horses. The Glucode Chip is used to ensure that your g-Pet Meter provides you with accurate results. Before performing the blood glucose test or starting a new...

  • Page 13: Installing/Replacing The Battery

    When the battery is low, the Meter will show a warning signal. When this display appears, it is time to replace the battery. When the low battery warning signal is shown, the g-Pet Meter will provide accurate results for approximately 50 more measurements. How to Replace the Battery 1.

  • Page 14: Setting Up The Meter

    Setting Up the Meter To turn the Meter on, first insert a battery, then press the reset button located at the back of the Meter and proceed with the following instructions. Setting Up the Date, Time 1. Press the M button for 3 seconds to enter setting mode.

  • Page 15: Setting Up The Alarm

    4. To enter the day and move on to choose the hour setting, press the M button. 5. To change the hour, press the S button. To enter the hour and move on to change the minutes, press the M button. 6.
  • Page 16 8. To set the second alarm, press the M button (y). If you press S button (n), it will move to health management alarm setting (step 11). To change the hour, press S button. To enter the hour and move on to change the minutes, press M button. To change the minutes, press S button.

  • Page 17: Setting Up The Hi And Lo Alarm

    10. To set the fourth alarm, press the M button (y). If you press S button (n), it will move to health management alarm setting (step 11). To change the hour, press S button. To enter the hour and move on to change the minutes, press M button. To change the minutes, press S button.
  • Page 18 12. To change the “LO alarm setting” press the S button. To enter the “LO alarm setting” and move on to PC link setting, press M button. To finish the setting, press S button (no) to turn off the meter. 13.
  • Page 19 Checking the Performance of Your g-Pet Meter The Glucode Chip is used for checking and coding your g-Pet Meter. To Check your Meter: 1. Insert the Glucode Chip into meter’s Glucode Chip slot. All segments of the LCD display will appear indicating that the g-Pet Meter is functioning properly.

  • Page 20: Coding Your G-Pet Meter

    In order to ensure an accurate result, the code number on the display must also match the code number found on the g-Pet Test Strip vial for your animal type. 1. The meter must be switched off before inserting the g-Pet Glucode chip Insert the g-Pet Glucode Chip, Conductive Bar’s end...
  • Page 21 Glucode Chip, a “000” will appear on the screen and then turn off automatically after 3 sec. 3. Match the code number on the g-Pet Meter display with the code number on the Test Strip vial for cat, dog or horse. If the code matches you may begin to test or press M to turn off.

  • Page 22: The Control Solution Test

    4. If the test results appear to be abnormally high or low, or are not consistent with clinical presentation. 5. The g-Pet test strip vial has been left open or has been exposed to temperatures above or below 10-40ºC (50-104ºF)
  • Page 23 To Perform a Control Solution test: 1. Make sure the Control Solution is at room temperature prior to testing. 2. Insert a g-Pet Test Strip, white side face up, Contact Bar’s end first, into the test port. The g-Pet Meter will turn on automatically.
  • Page 24 5. After the “ ” symbol appears, press the S button for 3 sec to switch control solution mode. The “ ” symbol indicates that the Meter will mark your current test as a Control Solution test. Now you are ready to apply the Control Solution. 6.
  • Page 25 Comparing Control Solution Results The g-Pet is functioning properly if the result falls inside the specified range printed on the Test Strip vial. If the test result falls outside the specified range, repeat the test. Results falling outside the specified range may be caused by: ●...

  • Page 26: Blood Glucose Testing

    ● Never share a lancing device and lancet with another animal. ● Always use a new and sterile lancet. Lancets are for single use only. ● Always use a new g-Pet Test Strip. Test Strips are for single use only.

  • Page 27: Preparing The Test Strip

    1. Wash hands using soap and warm water. Rinse and dry thoroughly. 2. Pull out a g-Pet Test Strip from the vial and re-cap the vial immediately. 3. Insert the Test Strip white side face up, into the test port.

  • Page 28: Obtaining A Blood Sample

    Obtaining a Blood Sample SAMPLE MAY BE OBTAINED FROM CAT OR DOG USING AN INSULIN SYRINGE OR THE LANCING DEVICE PROVIDED. FOR HORSES USE A JUGULAR SAMPLE. For further instructions please see the insert provided with lancing device. 1. Unscrew and remove the endcap of the lancing device. 2.

  • Page 29: Applying Blood Sample To The G-Pet Test Strip

    Applying Blood Sample to the g-Pet Test Strip 1. After obtaining a blood sample, place the drop onto the test well of the g-Pet Test Strip. 2. Blood is automatically drawn into the g-Pet Test Strip. ENSURE CONFIRMATION WINDOW IS COMPLETELY FILLED WITH BLOOD 3.
  • Page 30 Fig.7 Test Strip to confirm the result.(Fig.7) 6. If a “LO” message appears on your display, your g-Pet Meter has detected that your blood glucose level is lower than 1.1 mmol/L (20mg/dL) It is suggested that you review your testing procedure and test again with a new g-Pet Test Strip Fig.8...

  • Page 31: Memory Features

    It also provides you with a consecutive 7/14/30-day average of your blood glucose test results. 1. Press the M button to turn on the g-Pet Meter. All segments of the LCD display will appear. The date and time will appear first.
  • Page 32 6. Press S button, the most recent test result will appear. Each time you press the S button, the g-Pet Meter will recall the last 300 test results accordingly. When the memory is full, the oldest result is removed and replaced with the newest result.

  • Page 33: Care And Storage

    Care and Storage 1. Handle the g-Pet Meter with care. Dropping or throwing the Meter may cause damage to the device. 2. Do not expose the Meter, Test Strips, and Control Solution to extreme conditions, such as high humidity, heat, freezing cold or dust.

  • Page 34: Display Messages

    This message appears Code Meter. immediately if your Meter has (see page 18) not been encoded. This is the current code This code number should number in use. match the code number printed on your g-Pet Test Strip vial.
  • Page 35 The system is ready to accept You may now apply a drop of a Control Solution sample. Control Solution sample. g-Pet Meter detects blood Indicates high blood glucose glucose level is higher than level. Repeat test. 33.3 mmol/L (600 mg/dL).
  • Page 36 DISPLAY WHAT IT MEANS ACTION The g-Pet Meter detects Indicates low blood glucose blood glucose level is lower level. Repeat test. than 1.1 mmol/L (20 mg/dL). Temperature is too low to Repeat the test in a warmer perform the test.
  • Page 37 DISPLAY WHAT IT MEANS ACTION An error message indicating Review the instructions and a problem with the g-Pet Test try again with a new g-Pet Strip. Test Strip. Battery power is too low for Replace with a new 3-Volt further usage.
  • Page 38 An error message indicating Press ”reset” button and check the meter again with a problem with the g-Pet the Glucode chip. If the Meter. problem persist, contact your local supplier. Indicate the result is HIGHER For reference you can than the “HI alarm setting”...
  • Page 39 DISPLAY WHAT IT MEANS ACTION Indicate the result is LOWER For reference you can than the “LO alarm setting” of change the default setting the health management. value. Refer to page 15. Temperature is low during the Result may be larger variation.
  • Page 40 4 minutes to turn off the shown. meter. Other problems that may occur ACTION The g-Pet Test Strip has not been inserted Review the instructions and re-insert the into the Meter properly. Test Strip correctly (white side face up). Defective g-Pet Test Strip.

  • Page 41: Specifications

    3-Volt lithium battery (CR-2032) Battery Life: Approximately 1000 tests Dimension and Weight: 102 x50 x15 mm ; 55 g Woodley Equipment Company Old Station Park Buildings St Johns Street *Calibrated for cat, dog and horse use. Horwich, Bolton, Lancashire, BL6 7NY UK...

  • Page 42: Limitations Of The Procedure

    Limitations of the procedure Caution: The g-Pet System is designed for in vitro use only and is not intended to test on newborn animals. The g-Pet System is calibrated for cat, dog and horse use, not intended for humans. The g-Pet Test Strips are designed for use with fresh capillary whole blood samples.

  • Page 43: Service And Warranty

    System when used with Test Strips other than those designed for the g-Pet Meter. The g-Pet System manufacturer warranty is valid only when used properly within the guidelines of the provided User’s Guide and is invalid when the g-Pet System and g-Pet Test Strip are used improperly.
  • Page 44 Read Instructions for use Keep away from sunlight Caution, consult accompanying documents OLD STATION PARK BUILDINGS, ST.JOHNS STREET, HORWICH, BOLTON, LANCASHIRE. BL67NY. UK Keep dry Tel: +44 (0)1204 669033 WEEE Fax: +44 (0)1204 669034 Do not reuse or E-mail us at :sales@woodleyequipment.com B03G106730(03) Rev.
