Summary of Contents for bell marine Viper S Series
- Page 1 Viper Series Gravity Feed Free Fall Anchor Winch USER GUIDE bellmarine.com.au Factory 1, 2 Network Drive Carrum Downs Victoria Australia 3201 Tel: 61 3 9708 2846 Fax: 61 3 9708 2845 sales@bellmarine.com.au...
- Page 2 This Limited Warranty gives you specific legal rights and you may also have other rights which vary from state. Bell Marine reserves the right to alter...
- Page 3 bellmarine.com.au VIPER PERFORMANCE...
- Page 4 Typical Winch Installation Samples Diagram 3 Diagram 1 Deck Mount Installation Anchor Well Installation using Hawse Pipe Diagram 4 Diagram 2 Cuddy Cab Installation Anchor Well Installation Using An Anchor Roller Installation Note For the gravity feed winch, rope can only be wound onto the drum in one direction due to its working design - see the list below to help you work out which direction will work for your installation.
- Page 5 OPERATING INSTRUCTIONS Viper S Series GRAVITY FEED (free fall) Anchor Drum Winch HOW TO ANCHOR USING THE GRAVITY FEED: • Please make sure your engine is running while operating your winch. • Engage the circuit breaker to power up your winch.
- Page 6 RRP $149. P/N 30029 35LB/16KG GALVANISED PLOUGH ANCHOR RRP $189. P/N 30038-A ALLOY FITMENT KIT FOR VIPER S SERIES MICRO WINCH RRP $ 30. P/N 30013 5kg S/S PLOUGH ANCHOR RRP $379. P/N 30021-A ALLOY FITMENT KIT FOR VIPER S SERIES RAPID WINCH RRP $ 35.
Need help?
Do you have a question about the Viper S Series and is the answer not in the manual?
Questions and answers
Achour will not come up
Possible reasons for the Bell Marine S Series anchor not coming up include:
1. The winch installation is not aligned properly with the bow sprit or is not square to it.
2. Rope and/or chain jams on the baseplate due to:
- Using a non-factory rope/chain kit with too much rope on the drum.
- Creating a loose line effect by driving too far forward when retrieving the anchor.
3. The anchor may not fall correctly due to lack of gravity force when the anchor is up in the bow sprit, which may require a replacement bow roller/sprit or lowering the front roller.
This answer is automatically generated
why would motor get hot an trip out breaker switch
The Bell Marine Viper S Series motor may get hot and trip the breaker switch if water enters the electric motor. The manual states that every Viper winch motor is pressure tested and sealed at the factory to prevent water ingress. If water enters the motor, it could cause overheating, leading to the breaker switch tripping as a safety measure.
