  • Page 1 深圳罗克福斯特信息技术有限公司 IOT Lock User Manual Shenzhen Hesibond IOT Technology Corp., Ltd.
  • Page 2 Lockstitch IoT Lock Instructions Manual V2.0.0 Honor produced: Shenzhen Rock Foster Information Technology Co., Ltd. Production address: 4th floor, Shenyi Industrial Building, Nanshan Avenue, Shenzhen Service Phone: 400-016-1008...
  • Page 3 I. Introduction to IoT Lock Parameters…………2 a) Introduction to parameters on the three-type door…2 b) Introduction of parameters on the five-type door…4 c) Introduction to gateway parameters……………………6 II. Quick Guide to IoT Locks……………………8...
  • Page 4 Three-type Lockstitch IoT lock appearance Figure 1.0 Three-type (HB-WLK-01) IoT lock appearance. Note: When the door lock has no power, you can use the external USB emergency power supply interface to unlock.
  • Page 5 Table 1.0 Type III (HB-WLK-01) IoT Lock Parameters Features Technical Parameters 1. Standard: password + IC card + mechanical key + ID Product color: rose gold, red bronze, card + WeChat scan code to open the door + mobile black titanium stainless steel, etc.
  • Page 6 anti-theft lock core, effectively prevent illegal molecular unlock alarm, password input 5 times shackles error alarm, false lock alarm 9. Sensor anti-destructive ability: 4H pencil 20 cm Outdoor panel size: L: 363 x W: 83 x H: continuous impact 1000 times without damage 32 (mm) 10.
  • Page 7 Five-type Lockstitch IoT lock appearance...
  • Page 8 Table 1.1 Type 5 (HB-WLK-02) Internet of Things Lock Parameters Features Technical Parameters 1. Standard: password + proximity card + mechanical Product color: rose gold, red bronze, black key + ID card + WeChat scan code to open the door + titanium, optional other colors (must be fingerprint + mobile phone remote open 100)
  • Page 9 8. Long life, ultra low power consumption, super Safety alarm: anti-smash alarm, key unlock C-class lock core anti-theft lock core, effectively alarm, password input 5 times error alarm, prevent illegal molecular shackles false lock alarm 9. Sensor anti-destructive ability: 4H pencil 20 cm Outdoor panel size: L: 363 x W: 83 x H: 32 continuous impact 1000 times without damage (mm)
  • Page 10 LockstitchIoT lock gateway appearance Figure 2.0 TD-LTE wireless data terminal appearance TD-LTE wireless data terminal function: Insert a SIM flow card on the TD-LTE wireless data terminal, and the terminal receives the information link data packet information of the Internet of Things to send the information to the server.
  • Page 11 communication module inside, and the TD-LTE gateway is connected to the platform through the SIM flow card, and the gateway opening command and the door lock state information report uploading require the gateway as an intermediate information converter. To achieve communication between the Internet of Things door lock and the platform.
  • Page 12 lock and the gateway is successful. Table 2.0 Internet of Things Lock Gateway Parameters Serial number Features Technical Parameters Executive YD/T 2575-2013、YD/T 2576.2-2013 standard Internet of Modulation QPSK 、16QAM Things Frequency Upstream: 2570 MHz – 2620 MHz Lock Range Downstream: 2570 MHz – 2620 MHz Gateway Transmit ≤23dBm...
  • Page 13 I.IoT Lock Quick Start Guide Step 1:The first step: for the code network, plug the power adapter on the gateway below, turn on the power switch, and connect the door lock to the gateway code according to the code process. Gateway and door lock pairing process: Open the gateway power switch, wait 3-5 seconds, the LED red indicator flashes once every 5 seconds, use the small...
  • Page 14 Step 2: Bind the door lock, pay attention to the 'Rock Foster' WeChat public account, open the 'User Center' -> 'Bound Door Lock' menu scan code door lock QR code, fill in the door lock name, detailed address Bind the door lock.
  • Page 15 Step 3: When the mobile phone opens, open the public number ‘phone unlocking’ menu to verify whether the remote opening and scanning code opening is successful.
  • Page 16 Step 4: Set the password, IC card number, fingerprint, ID card, open the ‘Service Butler’-> ‘Unlock Settings’ menu, set the password, card number, etc. Note: The quick-use guide makes it easy for users to quickly familiarize themselves with the operation of the public number and the operation of the door lock.
  • Page 17 深圳罗克福斯特信息技术有限公司 Shenzhen Hesibond IOT Technology Corp., Ltd. Mailbox:aftersales @hesibond.com URL:www.hesibond.com...
  • Page 18 FCC ID: FCC ID: 2ASI7-LKF-05-BRW Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
