- Page 1 User Handbook...
-
Page 2: Table Of Contents
CONTENTS Introduction CE marking and labels Safety precautions Prior to first use Meywalk®4 part names Warranty Assembly Adjustments Cleaning and maintenance Recycling Disposal Pre-assessment Technical specifications Meywalk®4 accessories... -
Page 3: Introduction
INTRODUCTION Meywalk® 4 Micro, Mini, Small, Medium and Large are primarily designed for young children, youths and adults who have difficulty walking without support. The user-friendly Meywalk®4 is designed for indoor and outdoor use. The maximum permitted body weight of the user is: Micro - 60kg, Mini - 80 kg, Small - 100 kg and Medium and Large - 130 kg. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS • Never leave the user in Meywalk®4 unattended! Meywalk®4 is a therapy product and should only be used as such! • The spring system of Meywalk®4 may involve a risk of the walking aid toppling over if used by a very restless user. •... -
Page 5: Prior To First Use
• Check that all parts are securely fastened before using the walker. • Do not use high-pressure cleaning tools or caustic chemicals when cleaning the walker. • Unlike previous generations of Meywalk® Walkers, the Meywalk®4 is now equipped with drag brakes, non-reverse brakes and front wheel swivel-locks as standard. -
Page 6: Meywalk®4 Part Names
Meywalk®4 parts Trunk support Trunk support height adjustment Handlebar Tilt function Seat with rear stop Seat height adjustment Spanner grip for adjustment of upper tube Brakes Rear wheels Swing bar, not for Mini model Fender wheel Front wheels... -
Page 7: Warranty
WARRANTY Warranty is granted on all defects that are proven to be caused by material or manufacturer fault. The warranty period is 24 months from the time of dispatch readiness alternatively time of delivery. The warranty does not cover any damage due to normal wear and tear, intentional, negligent or inexpedient handling or use. -
Page 8: Assembly
ASSEMBLY Joining the top part and bottom frame Place the top part in the tubes on the bottom frame. Remember to position the top part so that the handlebar points in the direction of the swivelling front wheels. Spring loading The two springs inside the tubes can be changed to obtain harder or softer suspension. - Page 9 The springs can easily be interchanged. Grab and open the swing bar so that the frame is lowered. The tube ends are closed with a lid - open the lids to remove the springs. To open the lid push up and turn clockwise before pulling the lid down and off. After removal of the old springs the new ones can be inserted into the tubes.
-
Page 10: Adjustments
ADJUSTMENTS Stanchions Warning! Do not carry out this adjustment while a user is placed in Meywalk®4. The height of Meywalk®4 is adjusted by way of the black spanner grips. Loosen the spanner grips on both sides and adjust the frame to the desired height. Fasten the spanner grips firmly. - Page 11 Seat Warning! Do not carry out this adjustment while a user is placed in Meywalk®4. Adjust the seat height according to the length of the user’s legs. Turn the lower thumb screw located at the front of Meywalk®4. The thumb screw features a “child lock”...
- Page 12 Tilt function Warning! Do not carry out this adjustment while a user is placed in Meywalk®4. By means of the tilt function the user’s posture can be changed. Turn the middle thumb screw to tilt the support. The thumb screw is located at the front of Meywalk®4.
- Page 13 Rear stop The rear stop should always be closed in the upright position when there is a user in Meywalk®4. Pull the rear stop backwards out of the seat and turn it upwards. Now you can push it down into the locked position. Repeat the procedure in reverse order to open the rear stop again.
- Page 14 Brakes The brakes are parking brakes that work by directly blocking the rear wheels with a braking pulley pressing against the tyre. To brake the walking aid, pull the brake levers away from the frame until they come to a definite stop. In this position the brakes are self-locking and it should not be possible to push the walker.
- Page 15 Anti-tip support Anti-tip supports are mounted on each side by first removing the bolts fixing the wheels. Use a 6mm Allen key. Place the anti-tip support against the outside of the rear fork of Meywalk®4 so that they fall into place in the two rear fork recesses. Screw bolts on both sides back on. Re-tighten firmly.
- Page 16 Trunk pad The trunk pad is mounted on the black polyurethane shell of the center box. First remove the screws and washers from the shell. Then mount the trunk pad using the screws that came with the trunk pad. Hip pads The hip-/side pads are to be mounted on the uprights.
- Page 17 Height reductions set Each reduction set consists of 1 pair of 4 units – 2 x special fittings, 2 x threaded rod, 2 x bushing and 2 x Allen screw head (see right). The height reductions set is unavailable for the Mini model.
-
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE Meywalk®4 can be washed in warm water with detergent but take care not to wash the foam padding on the rear of the trunk support, handlebar and rearstop. With time the painted frame may take on a matt appearance if washed with detergent repeatedly. If so, the frame can be polished with car polish. - Page 19 TECHNICAL AND ACCESSORIES...
-
Page 20: Pre-Assessment
PRE-ASSESSMENT Ask for the following: • Inside leg measurement • Body weight (if possible - not essential) • Chest circumference • Seat height* • Trunk support height*... -
Page 21: Technical Specifications
TECHNICAL SPECIFICATIONS MICRO MINI SMALL MEDIUM LARGE Technical data WA1202 WA1200 WA1201 WA1203 WA1204 Length 77 cm 80 cm 85 cm 93 cm 110 cm Outer width 51 cm 56 cm 62 cm 62 cm 68 cm Inner width 42cm 44 cm 49 cm 50 cm... -
Page 22: Meywalk®4 Accessories
MEYWALK®4 ACCESSORIES Part No. Description WA1205 Trunk pad, Small COMPLETE WA1206 Trunk pad, Medium COMPLETE WA1207 Trunk pad, Large COMPLETE WA1208 Trunk pad adjustment set WA1209 Leg divider, Silver METAL - Micro, Mini and Small WA1210 Cover for leg divider - Micro, Mini and Small WA1211 Leg divider, Silver METAL - Medium and Large WA1212... - Page 23 Trunk pads Adjustment set Leg divider Leg divider cover WA1205, WA1206, WA1208 WA1209, WA1211 WA1210, WA1212 WA1207 Leg guides Leg guides Hip pads Anti-tip support Silver METAL Black PLASTIC Complete WA1219, WA1220 WA1213, WA1214, WA1241, WA1242, WA1218 WA1215, WA1216 WA1243, WA1217 Comfort saddle Tray Push and drag bar...
- Page 24 MEY4MAN_1 Tel: 01531 635388 www.Symmetrikit.com sales@Symmetrikit.com The Helping Hand Company Bromyard Road, Ledbury Herefordshire HR8 1NS...
