Summary of Contents for Sferasol Energy SFERASOL SF-S
- Page 1 Use and maintenance manual INTEGRATED STORAGE COLLECTOR SFERASOL...
- Page 2 INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL SFERASOL ENERGY S.R.L. VIA G. PASCOLI, 1 10060 SCALENGHE (TO) - ITALIA TEL. +39.011.194.577.34 MOB. +39.335.18.93.453 INFO@SFERASOLENERGY.COM WWW.SFERASOLENERGY.COM The development of continuous product improvement may result, without notice, any changes or modifi cations as described in this manual.
-
Page 3: Table Of Contents
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL INDEX Sferasol ...........4 Safety basic instructions......5 Before starting Sferasol ......5 Technical features........6 Transport and storage........7 Sferasol positioning........8 Sferasol installation.........11 Start-up.............12 Maintenance..........13 10 . Level Control..........14 11 . -
Page 4: Sferasol Tm
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Sferasol SFERASOL is planned to produce sanitary warm water with the aid of the direct and diff used solar energy. Water temperature supplied by a SFERASOL panel depends on several external factors, varying according to the season, the place and the time of the day. -
Page 5: Safety Basic Instructions
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Safety basic instructions. SFERASOL has been manufactured respecting safety rules and in accordance with Machinery Directives: 2006/42CE 2006/95/CE 2004/108/CE Final user could be in danger if the machine components are damaged or worn out or if SFERASOL is improperly used. -
Page 6: Technical Features
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Technical features. • Storage water tank in AISI 304 S.S., thickness 2,0 mm. Capacity 150 litres. Our boilers are duly checked after assembly and welding, in order to ensure tightness and quality. •... -
Page 7: Transport And Storage
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Transport and storage. Follow basic rules for operation with cranes and fork lifts, loading charges ma- chineries, etc. Each lifting operation must be done with machineries with a suffi cient loading power. Move or lift SFERASOL panel with maximum care ensuring lifting systems to... -
Page 8: Sferasol Tm Positioning
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Sferasol positioning. Installation area requirements. Follow carefully instructions below before connecting and starting SFERASOL panel. Manufacturer will not be responsible for damages caused by the failure in re- specting the following requirements Packing removal. - Page 9 INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL • SFERASOL must be installed in a place with total daytime sunlight. If not possible, sunlight should be at least from 11 a.m. to sunset. • When installed, SFERASOL inspection door must be always SOUTH-side oriented •...
- Page 10 INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Connection requirements. Electrical connections must be done by specialized electrician or by instructed staff only. Plumbing connections must be done by specialized thermohydraulic staff or by in- structed staff only. Warning: During all installation and connection operations, the appliance must be cove- red by the special white polyethilene packaging to avoid damages during these operations.
-
Page 11: Sferasol Tm Installation
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Sferasol installation. Installation and connections SFERASOL installation is very easy and and can be carried out by specialized staff following the instructions below: • Make cold water piping and heated water suction piping connections in the apposite well located in the support base. -
Page 12: Start-Up
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Start-up. Staff in charge. Start up operations must be done by allowed staff after the complete reading of the present use and maintenance booklet. All the electrical connections must be done by specialized operators. Ensure that water fl... -
Page 13: Maintenance
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Maintenance. Maintenance operations enable to keep the machine in perfect working con- ditions. The most important components of the machine must be kept clean for in- spection. Inspections must be done in order to keep the machine in perfect functioning. Inspections are split in monthly or annual inspections. -
Page 14: Level Control
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Storage. No particular care is necessary but storage place must be clean and the machine should be covered in case of a quite long non working period. • In case of quite long non working period of the appliance, this one must be covered with the white plastic cover supplied, without disconnecting power supply. -
Page 15: Troubleshooting And Spare Parts
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Troubleshooting and spare parts. In case a satisfying warm water quantity is not assured, follow instructions below: 1. Consider weather conditions . 2. Consider domestic water . 3. Check carefully tightness of all connections of the system and fasten or replace any loose connections. -
Page 16: Sferasol Tm Without Tank Inside Sf-A
TOTAL primary circuit , necessary quantity of thermal liquid shall be quantifi ed de- pending on the realized system). All missing components can be supplied by Sferasol Energy S.r.l. excepting the storage tank. WARNING: During installation of the system primary circuit must not be higher than 0,5 bar. -
Page 17: Sferasol Tm Data Sheet Sf-S
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Sferasol Data Sheet SF-S Integrated Storage Collector SFERASOL made by: 2 external metachrylate hemispheres 2 internal steel 09/10 P06 hemispheres 1 water tank in INOX AISI 304 stainless steel ... -
Page 18: Sferasol Tm Data Sheet Sf-A
INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Sferasol Data Sheet SF-A Product Integrated Storage Collector SFERASOL made by: 2 external metachrylate hemispheres 2 internal steel 09/10 P06 hemispheres 1 INOX AISI 304 stainless steel basement 1 INOX AISI 304 stainless steel structure ... - Page 19 INTEGRATED STORAGE COLLECTOR SFERASOL USE AND MAINTENANCE MANUAL Thank you for choosing SFERASOL...
- Page 20 Via G. Pascoli, 1 - 10060 Scalenghe (TO) - ITALIA Tel + 39.011.194.577.34 - MOB. + 39.335.18.93.453 info@sferasolenergy.com www.sferasolenergy.com...
