Direct Supply Attendant Series Owner's Manual

Compressor nebulizer

Advertisement

Direct Supply
Compressor Nebulizer
Owner's Manual
Thank you for purchasing a Direct Supply
Direct Supply
Equipment & Furnishings
®
keep it for future reference. This guide will provide you with instructions, warnings,
warranty information and other important information about your Direct Supply Attendant
Compressor Nebulizer. Share this information with your housekeeping, nursing and
maintenance staff to help ensure the compressor nebulizer is used and cared for properly.
Attendant
®
Please keep and refer to this Owner's Manual.
1-800-634-7328
®
Attendant
compressor nebulizer from
®
®
. Please read this entire guide carefully and
directsupply.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Attendant Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Direct Supply Attendant Series

  • Page 1 ™ keep it for future reference. This guide will provide you with instructions, warnings, warranty information and other important information about your Direct Supply Attendant Compressor Nebulizer. Share this information with your housekeeping, nursing and maintenance staff to help ensure the compressor nebulizer is used and cared for properly.
  • Page 2: Table Of Contents

    Table of Contents Table of Contents Definitions and Symbols ....................3 Introduction/Indications for Use ..................3 Warnings ..........................4 Directions for Use ....................... 5 Cleaning ..........................6 Storage ..........................7 Product Specifications ....................... 8 Limited Warranty ....................... 9 Customer Service ......................10 Please keep and refer to this Owner’s Manual.
  • Page 3: Definitions And Symbols

    YOU and YOUR: The facility, community or other entity that has purchased the device. WE, US and OUR: Direct Supply Manufacturing, Inc. Introduction/Indications for Use The Direct Supply Attendant compressor nebulizer is a compact medical device designed to deliver physician-prescribed medication to the bronchial lung passages through inhalation.
  • Page 4: Warnings

    Warnings Warnings • WARNING – To avoid electrical shock: Keep the unit away from water. Do not immerse the power cord or the unit in liquid. Do not use while bathing. Do not reach for a unit that has fallen into water - immediately unplug the unit. •...
  • Page 5: Directions For Use

    Directions for Use Directions for Use • Note: Prior to initial operation, the nebulizer should be thoroughly cleaned. Step 1: Place your compressor nebulizer on a flat and stable surface. Be sure that you can easily reach the controls when you are seated. Step 2: Open the clear cover and remove the inside accessories.
  • Page 6: Cleaning

    Cleaning Cleaning It is recommended that the nebulizer and mouthpiece are thoroughly cleaned with hot water after each use and cleaned with a mild detergent after the last treatment of the day. If your physician or respiratory therapist specifies a different cleaning procedure, follow their instructions.
  • Page 7: Storage

    Storage Storage Store the device in a cool, dry place. Do not store near heaters or other devices that could physically damage the product. Always store the device with the plug disconnected from a power source. 1-800-634-7328 directsupply.com ■...
  • Page 8: Product Specifications

    Product Specifications Product Specifications Power AC 120V, 60 Hz (230V/ 50 Hz available) Power Consumption 180VA Medication Capacity 5 ml Particle Size 0.5 to 10 μm MMAD 4 μm Sound Level Less than 60 dB at 1 meter Average Nebulization Rate ≥0.2ml/min Compressor Pressure Range 29 to 43 Psi (200 to 300 KPa/2.0 to 3.0 bar)
  • Page 9: Limited Warranty

    Limited Warranty Limited Warranty We offer to you, as the original purchaser, a warranty for the Direct Supply Attendant Compressor Nebulizer. Our warranty applies for the limited warranty period stated below. If any device or device part listed below is defective in material or workmanship during the applicable limited warranty period, we will repair or replace it at our cost.
  • Page 10: Customer Service

    Our promise to you is that you will have a convenient and easy ordering experience, receive a quality device and enjoy outrageous customer service. If you have any questions about the compressor nebulizer you have purchased or would like to request warranty service, please contact us at: Direct Supply ® Equipment & Furnishings , 1-800-634-7328, 6767 North Industrial Road, ™...
  • Page 11 1-800-634-7328 directsupply.com ■...
  • Page 12 , a division of Direct Supply, Inc. ® ™ Distributed by Direct Supply Manufacturing, Inc. 6699 N Industrial Road, Milwaukee, WI 53223. © 2011 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply and all associated logos are the registered trademarks of ®...
