SOFTWARE MANUAL
1/25

Advertisement

loading
Need help?

Need help?

Do you have a question about the EDGE 101 and is the answer not in the manual?

Questions and answers

Summary of Contents for HORI EDGE 101

  • Page 1 SOFTWARE MANUAL 1/25...

  • Page 2: Table Of Contents

    TOPICS Software Overview              3 1. MAIN Settings                                        4 2. SENSOR Settings                                14 3. MACRO Settings                                  19 4. LIGHT Settings                                    23 5. TEST Functions                                    24 2/25...
  • Page 3 Software Functions Software Functions Among other features, set macros, adjust sensor settings, save user profiles,  and customize LED lighting of your EDGE 101 Optical Gaming Mouse  with EDGE software by HORI. ⑪ Profile 1 ① ② ③ ④ ⑤ MAIN SENSOR MACRO LIGHT TEST ⑭ GAME LINK Scroll Button Left Button Right Button DPI Button Profile Button Left Side Button 1 Right Side Button 1 Right Side Button 2...

  • Page 4: Main Settings

    1.MAIN Settings 1.MAIN Settings Profile 1 MAIN SENSOR MACRO LIGHT TEST ① GAME LINK ② ② Scroll Button Left Button Right Button DPI Button Profile Button Right Side Button 1 Left Side Button 1 Left Side Button 2 Right Side Button 2 Left Rear Button Right Rear Button Export...
  • Page 5 1.MAIN Settings Assignable Button Functions Button Assignment Profile 1 ボタンの割り当て Scroll Button MAIN SENSOR MACRO LIGHT TEST Button Assignment GAME LINK Scroll Button スクロールボタン Default Default ① Default Default Scroll Button Keyboard Functions ② Left Button Right Button Keyboard Functions デフォルト Mouse Functions DPI Button Profile Button ③...
  • Page 6 1.MAIN Settings ②Keyboard Functions ・Keyboard functions can be assigned to the selected button by double-clicking   the Select a Key After Double Click button then setting the desired key   by typing it on the keyboard. Button Assignment Button Assignment Scroll Button Scroll Button Keyboard Functions Keyboard Functions Key input displayed  here Select a Key Select a Key Select a Key After Double Click ・All keys except ESC, Window, and Function can be assigned. ・ Shift+[key] , Alt+[key] , Ctrl+[key] combinations can also be assigned. Save Cancel Save...
  • Page 7 1.MAIN Settings ③Mouse Functions ・Assign other mouse button functions to the selected button. Button Assignment Scroll Button Mouse Functions Mouse Functions Left Button Left Button Right Button Scroll Button Back Next Scroll Up Save Cancel Assignable Functions Functions Name Left Click Right Click Scroll Button Back Next Scroll Up Scroll Down 7/25...
  • Page 8 1.MAIN Settings ④Sensitivity Setting ・Mouse sensor sensitivity adjustment functions can be assigned to   the selected mouse button. Button Assignment Scroll Button Sensitivity Settings Sensitivity Settings DPI Switch DPI Switch DPI Setting Up DPI Setting Down X-axis Fixed Y-axis Fixed Save Cancel Name Function DPI Switch Cycle through DPI1 to DPI5 settings saved in the SENSOR Settings tab. DPI Setting Up Increase DPI by 50 with each click DPI Setting Down Decrease DPI by 50 with each click. X-axis Fixed While holding the button the cursor will only move along the X-axis (horizontally).  Cursor will not move along the Y-axis even when mouse is moved vertically. Y-Axis Fixed While holding the button the cursor will only move along the Y-axis (vertically). ...
  • Page 9 1.MAIN Settings ⑤Macro Settings ・Record macros using this tool. Button Assignment Scroll Button Click here to display a list of  Macro Settings user-created macros to select from. Macro Selection Macro Selection Repeats Play once Play once Button Assignment Play multiple repeats Playback(While pressing key) Scroll Button Continuous Playback ON Save Cancel Macro Settings Macro Selection Macro Selection Repeats Play multiple repeats ・If "Play multiple times" is selected, ...
  • Page 10 1.MAIN Settings ⑥Switch Profile Button Assignment Scroll Button Switch Profile Switch Profile Switch Profile Profile Up Profile Down Profile 1 Profile 2 Profile 3 Profile 4 Save Cancel Switch Profile Settings Name Function Switch Profile Cycle through profiles 1 through 5 by clicking selected button. Profile Up Click to cycle through profiles in the order of 1 to 5.  If profile 5 is selected, profile will not change further. Profile Down Click to cycle through profiles in the order of 5 to 1.  If profile 1 is selected, profile will not change further. Profile 1 Change to Profile 1. Profile 2 Change to Profile 2.
  • Page 11 1.MAIN Settings ⑦Multimedia Functions It is possible to set media player functions to selected mouse buttons. Button Assignment Scroll Button Multimedia Functions Multimedia Functions Media Player Media Player Play/Pause Stop Previous Track Next Track Volume Up Save Cancel Name Function Media Player Open Media Player Play/Pause Play or Pause media playback Previous Track Skip to previous track Next Track Skip the next track Volume Up Increase volume Volume Down  Decrease volume Mute Mute audio 11/25...
  • Page 12 1.MAIN Settings ⑧Windows Shortcuts It is possible to assign Windows shortcut functions to selected mouse buttons. Button Assignment Scroll Button Windows Shortcuts Windows Shortcuts Close Application Close Application Show Desktop Copy Paste Undo Save Cancel Windows Shortcut Name Function Close application Close currently running application Show Desktop Minimize windows and show desktop Copy Copy function Paste Paste function Cut function Undo Undo function Select all Select all function Start Menu Open Start Menu Computer lock Lock computer Task Manager Start Task Manager...
  • Page 13 1.MAIN Settings Game Link Function Automatically load selected profiles when launching games or application  by using the Game Link function to link saved profiles to specified applications. Profile 1 MAIN SENSOR MACRO LIGHT TEST ① ③ GAME LINK GAME LINK Scroll Button GAME 1.exe Left Button Right Button ② Profile Button DPI Button Left Side Button 1 Right Side Button 1 Left Side Button 2 Right Side Button 2 Left Rear Button Right Rear Button...

  • Page 14: Sensor Settings

    2.SENSOR Settings MAIN DPI1 ① 2.SENSOR Settings Profile 1 MAIN SENSOR MACRO LIGHT TEST ⑦ DPI1 DPI2 DPI3 Polling Rate ① 125Hz 250Hz 500Hz 1000Hz ⑧ Sensor Adjustment ② X/Y-Axis DPI4 DPI5 Optimize for mouse pad Mouse Pad Profile ③ Acceleration ④ Mouse Pad Calibration Pointer Speed Lift-off Distance...
  • Page 15 Profile 1 2.SENSOR Settings SENSOR MACRO LIGHT TEST ⑦ DPI2 DPI3 Polling Rate 125Hz 250Hz 500Hz 1000Hz ⑧Sensor Adjustment ① Sensor Adjustment DPI5 Optimize for mouse pad ② Mouse Pad Profile ③ Mouse Pad Calibration ④ Lift-off Distance ment Lock ５ ４ ３...
  • Page 16 2.SENSOR Settings Mouse Pad Calibration ・Calibrates the surface of the mouse pad for optimized mouse sensor   performance. Profile 1 MAIN SENSOR MACRO LIGHT TEST ④ ① Mouse Pad Calibration ② ③ Delete ※ Click New to calibrate mouse pad. Hold the left mouse button and move mouse over entire mouse pad surface. Export Import Default Save Cancel...
  • Page 17 DPI1 ① 2.SENSOR Settings ▼ How to calibrate DPI4 1. Click on Calibration to switch to the calibration screen.  2. Click on New to add a mouse pad. ※Click on the Mouse Pad Name to change the name of the mouse pad. ※Click on Delete to remove a mouse pad. Click and hold the left mouse button to commence calibration. ② Move the mouse over the entire mouse pad surface. X/Y-Axis Adjustm Calibration will be complete after moving the mouse for 10 seconds. ③ ※Optical mouse may not be able to track movement on surfaces such as  Acceleration  clear (i.e. Glass), mirrored, and finely patterned surfaces. ④ Pointer Speed ※If the mouse sensor movement is not stable, repeating the calibration steps  ⑤  may improve performance. Scroll Speed ⑥ MAIN Double-Click Speed DPI1 ①...
  • Page 18 ⑦ DPI3 Polling Rate 125Hz 250Hz 500Hz 1000Hz 2.SENSOR Settings Sensor Adjustment Lift-Off Distance DPI5 Optimize for mouse pad ・The lower the number, the shorter lift-off distance. Mouse Pad Profile ・The higher the number, the longer lift-off distance. ・Adjusting the Lift-off distance after setting the Sensor Calibration may   improve tracking performance. Mouse Pad Calibration Lift-off Distance ５ ４ Profile 1 ３ ２ MACRO LIGHT TEST ⑦...

  • Page 19: Macro Settings

    3.MACRO Settings 3.MACRO Settings MAIN マクロを選択 Profile 1 MAIN SENSOR MACRO LIGHT TEST Macro Selection Macro Editor ① CUSTOM 0 Delete Insert ⑩ ⑦ ⑧ ⑨ ③ ② Delete 設定 Setting ④ Recorded Interval ⑤ Fixed Interval 0.05 Seconds ⑥ Record/Stop Export Import Default Save...
  • Page 20 3.MACRO Settings Macro Editor MACRO MACRO MACRO MACRO MACRO MACRO LIGHT TEST Profile 1 マクロを編集 MAIN SENSOR MACRO LIGHT TEST Macro Selection Macro Editor CUSTOM 0 Delete Insert Delete 0.6 SECOND ① Setting Recorded Interval 1.5 SECOND Fixed Interval 0.05 Seconds 0.6 SECOND 0.65 SECOND Record/Stop ②...
  • Page 21 3.MACRO Settings Recording Macros When recording macros you can choose between two types of time intervals. ①Recorded Interval ・ Recorded interval records the timing of the macro exactly as entered by   the user, including the length of time the key is held down and the length of  Profile 1  time between key presses. MAIN SENSOR MACRO LIGHT TEST Macro Selection Macro Editor CUSTOM 0 Delete Insert Time key is held down Delete Time between key presses 0.6 SECOND Setting Recorded Interval 1.5 SECOND Fixed Interval 0.05 Seconds User input timing recorded exactly 0.65 SECOND Record/Stop ②Fixed Interval ・...
  • Page 22 3.MACRO Settings Deleting commands ・The selected command s push icon, release icon, and time intervals   should be deleted together. ・By deleting the time interval between button inputs, time interval will become   0 (zero) seconds which is the equivalent of pressing the buttons   simultaneously in the macro. Moving Commands ・Click   or   when the command is highlighted it to move it up or down. ※ Release icon cannot come before Push , etc. Profile 1 ②Click insert MAIN SENSOR MACRO LIGHT TEST Macro Selection Macro Editor CUSTOM 0 Delete Insert Delete ①Select insert position 0.6 SECOND Setting Recorded Interval 1.5 SECOND Fixed Interval 0.05...

  • Page 23: Light Settings

    4.LIGHT Settings 4.LIGHT Settings Profile 1 MAIN SENSOR MACRO LIGHT TEST ① Light Color Brightness Level ③ ② Light Color Setting Blink Speed ④ Export Import Default Save Cancel LANGUAGE ENGLISH Lighting Tools Function Standard Colors ① Select the lighting color from the standard color palette. Custom Colors ② Further customize the lighting color using Custom Colors tool. Brightness Level ③ Turn the dial to set the brightness to 3 levels. Setting to 0 (zero) will turn the light off.

  • Page 24: Test Functions

    LIGHT TEST Test ① Clicking Speed Test “This test will record your fastest clicking speed and demonstrate the performance of the EDGE 101 Optical Gaming Mouse proprietary microswitch.” Personal Best Times/Seconds Begin Test ② Reaction Time Test “Test your reaction time by clicking when the circle turns red. This demonstrates the performance of EDGE 101 Optical Gaming Mouse proprietary microswitch.”...
  • Page 25 5.TEST Functions ①Clicking Speed Test ・Click in the blue area to begin the test. ・Number of clicks in 10 seconds will be measured. Turbo Test ０ Time Seconds ０ Number of times Frequency Times ・Click within the blue area or   the click will not be counted. Begin Test ②Reaction Time Test ・Click in the blue circle area to begin the test. ・Click on the mouse when the color of the circle changes from blue to red to   measure your reaction time. ・Number of seconds you took to react will be measured 5 times. Before Test During Test Click inside the circle  Reaction Time Test Reaction Time Test when it turns red. Seconds Seconds Click here Click here Seconds Seconds Seconds...
