Summary of Contents for Etec EFL240
- Page 1 Portable CD/Cassette Boombox MODEL: EFL240 PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE. For technical assistance or troubleshooting please call 1-855-994-3832 or visit www.SIBrandssupport.com...
-
Page 2: Table Of Contents
Table of Contents Warnings ..............Using the CD Player ............. 12 About Compact Discs .............. Loading a Disc ................Warnings/Safety ............Playing a Disc ................Repeat Playback ............... Programming a Playlist ............Overview ................Using the Cassette Player .......... 14 Connect Power ............... -
Page 3: Warnings
WARNINGS To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. • To reduce the risk of electric shock, do not open the cabinet. No user serviceable parts are inside. Refer • servicing to qualified personnel. -
Page 4: Warnings/Safety
FCC WARNINGS WARNING: Changes or modifications to this unit not expressly approved in this manual could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Overview
Overview Handle Raise the handle to transport the unit safely and easily. CD compartment Load compact discs here. The label side should face up. CD door latch Press here to open/close the door of the CD compartment [2]. Never open the compartment while a CD is playing or spinning! Speakers Full-range drivers deliver powerful... - Page 6 POWER Press to turn the unit on. Press and (Standby) hold to turn the unit off. CD: Press to Play, Pause, or resume CD playback. Radio: Press to automatically scan for and save stations to preset memory. CD: Stop CD playback. BAND Radio: Change the radio band (AM, FM).
- Page 7 Pause. Press to pause tape playback or recording. Depress the key again to ewsume playback or recording. Stop/Eject. Press to stop tape playback. When playback is stopped, press to open the cassette compartment [23]. Fast-forward. Press to fast forward through the tape when playback is stopped.
- Page 8 23 Cassette Load cassette tapes for playback or compartment recording. 24 AUX Input Play audio from a device that is jack connected to this 3.5mm input jack. 25 Headphone Connection for headphones with a 3.5mm output jack plug. The speaker output is disabled when headphones are in use.
-
Page 9: Connect Power
Connect Power Battery Power Install 8 “C” size batteries to enjoy music wherever The unit can be powered by AC household power, you are. or by batteries. Remove the lid from the battery compartment [27] found on the bottom of the main unit. AC Power Load eight “C”... -
Page 10: Basic Functions
Basic Functions Batteries contain chemicals that may be regulated by your local government. Dispose of them properly according to Turning the Unit On and Off regulations. To turn the unit on, press the POWER (Standby) key [5]. Do not incinerate the batteries. The The power indicator [22] will light up. -
Page 11: Using The Radio
Using the Radio output jack [25]. Once connected, press VOL+ or VOL– 13, 14] to slowly adjust the volume to a comfortable level. Listen to FM or AM radio broadcasts. Press FUNCTION [8] to change the active source mode to Radio. The FM or AM indicator will light on the LCD screen and the station frequency will The speakers will be disabled when be displayed. -
Page 12: Saving Stations To Preset Memory
Using the CD Player Saving Stations to Preset Memory Press [6] to automatically scan for stations and Listen to CD and CD-R/RW discs. save them to preset memory. This will overwrite any previously saved stations. Press FUNCTION [10] to change the active source mode to CD. -
Page 13: Playing A Disc
3. Close the CD compartment [2]. Gently lower the door • To select a track to play: to close it. • Press SKIP+ [11] to skip to the next track. 4. The player will attempt to read the disc once the •... -
Page 14: Programming A Playlist
Using the Cassette To return to normal playback, press MODE [9] until none of the mode Player indicators appear on the LCD screen. Listen to cassette tapes. Programming a Playlist Press FUNCTION [10] to change the active source When the CD is stopped, you can select up to 20 mode to TAPE. -
Page 15: Recording To Cassette Tapes
Recording to Cassette Tapes 2. Load the cassette into the compartment with its exposed magnetic tape facing up. You can record from different sources to cassette tape. The tape will spool from the right to Record with quality cassettes only (e.g., IEC type 1). left reel. -
Page 16: Record Protection
Record Protection The exposed magnetic tape of the cassette should face up. Protect your cassette tape from accidental erasure with the Record Protection tab. Take up any slack in the tape before loading the cassette into the compartment. 1. Locate the tab on your cassette tape. It can be found Turn the cassette reel with your finger or a on the long side of the cassette, opposite the side pencil until the tape is taut. -
Page 17: Caring For The Cassette Mechanism
If you would like to record with a cassette Never lubricate any part of the player un - der any circumstance. tape that is missing its record protection tab, use a small piece of adhesive tape to Never turn o the player during playback, cover tab opening. -
Page 18: Using The Aux Input
Using the AUX Input Listen to devices connected to the AUX input jack [24]. Press FUNCTION [10] to change the active source mode to AUX. The LCD screen [21] will display AUX. 1. Connect the audio source to the player. Use an optional audio patch cable to connect the 3.5mm headphone or line-out jack of the audio source to the 3.5mm AUX Input jack [24] found on the front... -
Page 19: Specifications
Speaker Output 12 W peak, 2.4 W RMS Media Support CD, CD-R/RW, Cassette Radio Tuner AM, FM Preset Memory 20 AM, 20 FM Input 3.5mm AUX jack Output 3.5mm headphone jack Power Source AC 120 V 8 x C batteries (not included) Standby Power Operating Power 12 W... -
Page 20: Warranty
Under no circumstances shall ETEC be liable We will replace the unit free of charge should it become defective...
