- Page 1 Extractor Gun EG - 1007 Instruction Manual...
- Page 2 EG-1007 Extractor Gun Q ty Q ty Description Tool Description Tool Part No . Part No . Housing EG1007001 EG1007021 Screw Screw Nozzle EG1007002 EG1007022 Cone 1 Weighted Tube Ass y ' EG1007003 EG1007023 Screw EG1007004 EG1007024 Cone 2 EG1007005 EG1007025 Trigger Adapter 26...
- Page 3 Extractor Gun Instruction Manual EG-1007 Extractor gun packs all the features of EVERGREEN into a lightweight, convenient cleaning geek. Perfect tools for professionals. A hypersonic-like cleaning action with detergent mist efficiently releases dirt and grease on short to medium pile fabric, carpet or solid surfaces, and the extension vacuum hose allows to suck the dirt when being connected with a wet/dry at the same time.
- Page 4 DIRECTION FOR USE (PREPARATION) Cone Installation/Replacement Attach standard cone with internal cone, and internal tube with internal liquid tube (See inset below). Please notice that internal liquid tube might bend during the instal- lation, please attach it with care. Make sure all the parts are completely installed.
- Page 5 Adjustment of Liquid Adjusting Valve / Fixed Valve Method of Liquid Adjusting Valve / Fixed Valve Fixed Valve screw allows to adjust the air flow. Once the Air pressure is fixed, please tighten the fixed valve. Fixed Valve Liquid Adjusting Valve The tighter the liquid adjusting valve screw, the thinner and smaller the spray volume is;...
-
Page 6: Direction For Use
DIRECTION FOR USE Please use the strainer to filter out all the liquid deposit in advance. (Containers for water or other cleaning solvents are not included in this package) First, turn off the air reverse switch. Vacuum the dirt without triggering the tool. To achieve the best result, use the vacuum function ONLY to remove loose dirt and dust first, then pull the trigger to break down stubborn dirt and contaminants Second,... -
Page 7: Maintenance Methods
MAINTENANCE METHODS First, Detach the cone, and clean the Standard Cone cone and joint adaptor. Standard Cone (or cone with brush) Please detach the standard cone /cone with brush and Caution liquid tube with care. It might cause damages to the device. Second, place the internal cone and internal liquid tube into water tank, release... -
Page 8: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read and observe the safety notes in the Instructions manual and the safety labels located on the device. 1. The air pressure must be set below 115 Psi. 2. Use only as described in this manual. Use only the manufacturer’s recommended attachments. -
Page 9: Safety And Operation Rules
Notice Provides information on particular characteristics and how to operate properly. SPECIFICATION Model No. EG-1007 NANOSKIN CAR CARE PRODUCTS Weight (kg) Division of Total Import Solutions, Inc. La Habra, CA 90631 Air Pressure (Psi) 75~115 Engineered in Japan Air Consumption (L/min)
