FISCHER EA16 Series Operating Manual

Measured value display. component for panel installation.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating manual
EA16
Measured value display
Component for panel installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EA16 Series and is the answer not in the manual?

Questions and answers

Related Manuals for FISCHER EA16 Series

Summary of Contents for FISCHER EA16 Series

  • Page 1 Operating manual EA16 Measured value display Component for panel installation...
  • Page 2 Great care was taken when compiling the texts and illustrations; Nevertheless, errors cannot be ruled out. The company FISCHER Mess- und Regeltechnik GmbH will not accept any legal responsibility or liability for this.

  • Page 3: Table Of Contents

    FISCHER Mess- und Regeltechnik GmbH Table of Contents Table of Contents 1 Safety guidelines ............................ 5 1.1 General .............................. 5 1.2 Personnel Qualification.......................... 5 1.3 Risks due to Non-Observance of Safety Instructions ................ 5 1.4 Safety Instructions for the Operating Company and the Operator............ 5 1.5 Unauthorised Modification ........................ 5...
  • Page 4 Table of Contents FISCHER Mess- und Regeltechnik GmbH 5.4.6 Menu: System [Level 2] ...................... 76 5.4.6.1 Menu: Configuration [Level 3] .................. 77 5.4.6.2 Menu: Overview inputs/outputs [Level 3] .............. 77 5.4.6.3 Menu: System info [Level 3] .................. 78 5.4.6.4 Menu: Firmware update [Level 3]................ 79 5.4.6.5 Menu: Date/Time [Level 3] ..................

  • Page 5: Safety Guidelines

    FISCHER Mess- und Regeltechnik GmbH Safety guidelines | 1 1 Safety guidelines 1.1 General WARNING This operating manual contains instructions fundamental to the installation, op- eration and maintenance of the device that must be observed unconditionally. It must be read by the assembler, operator and the specialized personnel in charge of the instrument before it is installed and put into operation.

  • Page 6: Inadmissible Modes Of Operation

    1 | Safety guidelines FISCHER Mess- und Regeltechnik GmbH 1.6 Inadmissible Modes of Operation The operational safety of this instrument can only be guaranteed if it is used as intended. The instrument model must be suitable for the medium used in the system.

  • Page 7: Product And Functional Description

    FISCHER Mess- und Regeltechnik GmbH Product and functional description | 2 2 Product and functional description 2.1 Use as intended The EA16 is a measuring value display unit for measuring transducers with out- put signals for current and voltage acc. to IEC 60381. Up to four measuring transducers in two or three-conductor versions can be connected.

  • Page 8: Design And Mode Of Operation

    2 | Product and functional description FISCHER Mess- und Regeltechnik GmbH 2.3 Design and mode of operation The measuring signals of up to four connected measuring transducers can be analysed simultaneously by the microcontroller electronics. The configurable 3.5" touch display can display up to four measuring values at the same time. A configurable colour switch serves to present specific operating modes.

  • Page 9: Installation And Assembly

    FISCHER Mess- und Regeltechnik GmbH Installation and assembly | 3 3 Installation and assembly The EA16 is designed for panel installation and is supplied fully assembled. Please see the supplied electro-technology documents for the dimensional drawings and information about the electrical connection of the panel. Panels can always be supplied in the following mounting types.

  • Page 10: Commissioning

    4 | Commissioning FISCHER Mess- und Regeltechnik GmbH 4 Commissioning 4.1 General All electrical supply, operating and measuring lines, and the pressure connec- tions must have been correctly installed before commissioning. NOTICE Illustrations All illustrations are examples to demonstrate a certain situation. The contents of the screen may vary greatly on the unit.

  • Page 11: Measured Value Display

    FISCHER Mess- und Regeltechnik GmbH Commissioning | 4 4.2 Measured value display There are two options for the measured value display presentation. • Tile view • List view The colour of the individual chapters can be changed depending on the respect- ive input signal.
  • Page 12 4 | Commissioning FISCHER Mess- und Regeltechnik GmbH Detail view channel 1 Tip the respective tile to go to the detail view of a channel. Return to the meas- ured value screen in the same way. The following uses the detailed view of the first channel to demonstrate all channels.
  • Page 13 FISCHER Mess- und Regeltechnik GmbH Commissioning | 4 The second page of the status display appears. Touch anywhere on the status display to show the next page. At the end, you automatically return to the first page. Pressure 35.8 Pressure too high 50.00...
  • Page 14 4 | Commissioning FISCHER Mess- und Regeltechnik GmbH Detail view channel 1 Tip the respective list entry to go to the detail view of a channel. Return to the measured value screen in the same way. The following uses the detailed view of the first channel to demonstrate all channels.

  • Page 15: Presentation Variants

    FISCHER Mess- und Regeltechnik GmbH Commissioning | 4 4.2.3 Presentation variants The unit is available in a 2-channel and 4-channel version. This setting is made ex-works. The detail views are identical to the detail views of the 4-channel version. The analogue inputs on both versions can be switched off individually. This status is indicated by OFF in the respective tile (or list).

  • Page 16: Control Elements

    4 | Commissioning FISCHER Mess- und Regeltechnik GmbH 4.3 Control elements The unit is equipped with a TFT Touch LCD colour display. It is operated via a list menu and the input interfaces that depend on the functions. The touch function is not explained because so many devices have this state- of-the-art function.
  • Page 17 FISCHER Mess- und Regeltechnik GmbH Commissioning | 4 û Enter the password and complete the input by pressing the OK button message appears on the screen stating which user you have logged in with. Once you have acknowledged the message, you return to the main menu.

  • Page 18: Parameterization

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5 Parameterization 5.1 General Information The EA16 is a highly complex measured value display with a control system that can be learned intuitively. Due to its complex structure and the possibility of supplementing functions by means of a firmware update, it is not possible to present all functions in details in these operating instructions.

  • Page 19: Value Input

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.3 Value input The following provides a description of the input interfaces that are used to enter the values. A differentiation is made between the input of numbers and the input of texts. The screens shown are examples only and may vary in terms of their layout and presentation.

  • Page 20: Select Parameter Values

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.3.3 Select parameter values Some inputs are made by selecting defined parameter values. This occurs either by switching the button or by selection from a list. Changeover button Assignment: Input 1 Button...

  • Page 21: Main Menu [Level 1]

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4 Main menu [Level 1] Menu path: Main menu/ Level 1 History Data logger Event log Display of events and parameter changes Login Login Configuration Configuration of the unit Language Menu language...

  • Page 22: Menu: History [Level 2]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.1 Menu: History [Level 2] Menu path: Main menu/History/ 1st level History Data logger Fig. 27: Menu: History The recorded measured values are presented in a chart in this menu. There is a wide range of functions available to analyse the data.
  • Page 23 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.1.1.1 Pres. of measurem. When presenting the measurements, you can choose between three options: Δt Time Fig. 30: Presentation of measurements (maximum values) The maximum value that occurred will be shown in the respective time interval Δt.
  • Page 24 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.1.1.2 Channel selection Channel change Scale of Selected channel selected channel 50.0 25.0 -25.0 -24h mbar 35.8 24.7 12803 Selected channel Unit of selected channel Fig. 33: Graphic display channel selection Each channel is assigned to a colour. The white colour marks the selected channel for which the unit and scale are shown.
  • Page 25 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Detailed presentation -24h 35.8 24.7 12803 Fig. 35: Graphic display to change to the detailed presentation A longer touch on the channel tile changes the display into the detailed present- ation for this channel.
  • Page 26 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.1.1.3 Cursor The cursor is shown as a vertical line. If this line is touched, a time stamp apears on the right (date + time). -24h 35.8 24.7 12803 Fig. 37: Graphic display swipe Swiping left or right moves the cursor The line follows the movement until the new position is reached.
  • Page 27 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.1.1.4 Circular menus The so-called circular menu is a context menu that offers various functions for navigation and presentation of the historical data. Touch any point on the display to call up the circular menu.
  • Page 28 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Submenu: Channels zoom / scaling Scaling (max) Period (+) Period (-) Scaling (min) Fig. 41: Submenu: Channels zoom / scaling Touch the right segment of the circle to enter the submenu: Channels zoom / scaling.

  • Page 29: Menu: Event Log [Level 2]

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.2 Menu: Event log [Level 2] Menu path: Main menu/Event log/ Level 1 Level 2 (display) filters Event log Scroll bar Incidents (example) Main menu/Event log/ Empty data record Fig. 43: Menu: Event log A filter can be used to select which type of event should be shown.

  • Page 30: Menu: Log On / Log Off [Level 2]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.3 Menu: Log on / log off [Level 2] Login Menu path: Main menu/Login/ 1. Level 2. Level (input) Log-on Please enter your password Main menu/Log-on/ Fig. 46: Menu: Login û Enter the password and complete the input by pressing the OK button message appears on the screen stating which user you have logged in with.

  • Page 31: Menu: Configuration [Level 2]

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.4 Menu: Configuration [Level 2] Menu path: Main menu/Configuration// Level 1 Level 2 (submenu) Configuration Display Switch outputs Inputs Outputs Data logger Fig. 48: Menu Configuration Signpost [►Page] Menu: Display [Level 3] [} 32] Menu: Switch outputs [Level 3] [} 33]...

  • Page 32: Menu: Display [Level 3]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.4.1 Menu: Display [Level 3] Menu path: Main menu/Configuration/Display/ Level 2 Level 3 (parameters) Display List view Colour scheme 1 (dark) Brightness Input 100% Device designation Input Display: Date/Time Limit lines: Format date dd.mm.yyyy...

  • Page 33: Menu: Switch Outputs [Level 3]

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.4.2 Menu: Switch outputs [Level 3] Menu path: Main menu/Configuration/Switch outputs/ Level 2 Level 3 (submenu) Switch outputs Switch output 1 Switch output 2 Switch output 3 Switch output 4 Fig. 50: Menu Switch outputs All switch outputs are configured in the same way.
  • Page 34 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Menu: Switch output 1 [Level 4] The switch outputs can be assigned to both the input signals and also the col- our changes. Depending on the selected assignment, the following submenu also changes.
  • Page 35 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Hysteresis function Key: (a) Activation point = Deactivation point Switch-on point Input signal Measuring range Increasing input signal Decreasing input signal Start Close Switch-off point NO: Make contact Contact closed Contact open NC: Break contact (b) Activation point >...
  • Page 36 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH B. Assignment to the colour changes Menu path: Main menu/Configuration/Switch outputs/Switch output 1 3. Level 4. Level (Parameter) Switch output 1 Assignment Colour change Contact type: NO Function: Hysteresis Colour change: red...
  • Page 37 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Traffic light function The so-called 'traffic light' function is activated by setting the parameter Assign- ment colour change. It serves to control external signalers by a switch output depending on the colour change of the measuring value display.
  • Page 38 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Example2: External signaler for colour-change 'red' and 'yellow' to channel 1 • A signal lamp is connected to contact K1 (switch output 1) and should shine if the colour of the first channel changes to red.
  • Page 39 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Example3: External signaler for colour-change 'red', 'yellow' and 'green' to channel 1 • A signal lamp is connected to contact K1 (switch output 1) and should shine if the colour of the first channel changes to red.

  • Page 40: Menu: Inputs [Level 3]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.4.3 Menu: Inputs [Level 3] Menu path: Main menu/Configuration/Inputs/ Level 2 Level 3 (submenu) Inputs Analogue input 1 Analogue input 2 Analogue input 3 Analogue input 4 Fig. 58: Menu: Inputs All analogue inputs are configured in the same way. Therefore the associated parameters are explained below using the example of Analogue input 1.
  • Page 41 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Pos. Value range Description Input The respective analogue input can be de- activated with this parameter. Active (standard value) Inactive Designation Designation is entered (e.g. pressure) that Pressure should appear on the measured value dis- play.
  • Page 42 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Submenu: Messages [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Messages Level 4 Level 5 (parameters) Messages Messages Message low - red Input Message low - yell. Input Message ok - green Input Message high - yell.
  • Page 43 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Submenu: Input signal [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Input signal Level 4 Level 5 (parameters) Input signal Type: Voltage Signal min. Input 0.000V Signal max Input 10,000V Fig. 63: Menu Input signal...
  • Page 44 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH (a) Function: linear [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Characteristic curve/ Level 4 Level 5 (parameters) Function: linear Characteristic curve Unit Input Measur. range start Input -50,000 Pa Measur. range end...
  • Page 45 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 f(x) -NPF -NPF Measurement exit +NPF +NPF exit NPF [%] = Measuring range start LiN = Linear approximation range = Measuring range end NPF = Zero-point window Linear approximation: Fig. 65: Zero-point window...
  • Page 46 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH b) Function: root extracted [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Characteristic curve/ Level 4 Level 5 (parameters) Function: Rooted Characteristic curve Lin. input range Sub menu Rooted measur. range Sub menu...
  • Page 47 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Pos. Value range Description Unit A unit for the measuring value display is defined with this parameter. It must have a length of at least 5 characters. Measuring range start The start of the measuring range is defined with this parameter.
  • Page 48 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH c) Function: Flow rate [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Characteristic curve/ Level 4 Level 5 (parameters) Function: flow characteristic curve Lin. Input range Sub menu Flow measur. range Sub menu...
  • Page 49 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Pos. Value range Description Unit Unit of the connected linear differential pressure transmitter Measuring range start The start of the measuring range is defined with this parameter. Measuring range end The end of the measuring range is defined with this parameter.
  • Page 50 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH d) Function: Table [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Characteristic curve/ 4. Level 5. Level (Parameter) Function: Table Characteristic curve Unit Input Number of value pairs: 5 Input Value pairs Submenu Inputs -->Display value...
  • Page 51 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Value pair 5 Input signal Fig. 73: Table function (n=7) The table should comprise 7 value pairs. Of the input signal 0 … 10 V, the range 2 … 8V should be used. The basic measuring range is 0 … 100 Pa. The display should display in the start of the measuring range 10 Pa and at the end of the measuring range 80 Pa.
  • Page 52 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Submenu: Value pairs [Level 6] Menu path: Main menu/ Configuration/ Inputs/Analogue input 1/Characteristic curve: Table/value pairs/ NOTICE! An empty table is available as standard. The user needs to calcu- late and enter the support points.
  • Page 53 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 e) Function: Difference [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Characteristic curve/ 4. Level 5. Level (Parameter) Function: Difference Characteristic curve Channel x (x-y): 1 Channel y (x-y): 2 lin. Input range...
  • Page 54 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH NOTICE! As stated at the outset, the parameters are explained using the example of the analogue input 1. The menu for the characteristic curve therefore refers to the analogue input 1. This function can be used to calculate the difference between two random input channels and assigned this to the analogue input 1.
  • Page 55 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Submenu: Lin. input range [Level 6] Menu path: Main menu/ Configuration/ Inputs/Analogue input 1/Characteristic curve: Difference/lin. measuring range/ Level 5 Level 6 (parameters) Unit Lin input range Input Measur. range start Input 10.000 Pa...
  • Page 56 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH f) Function: dyn. filter monitoring [Level 5]> Menu path: Main menu/Configuration/Inputs/Analogue input 1/Characteristic curve/ 4. Level 5. Level (Parameter) Fct.: Filter monitoring Characteristic curve lin. Approximation Channel dP: 1 Characteristic curve dp Submenu Max.
  • Page 57 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Pos. Value range Description Channel 1 V:1 This parameter determines the channel for the volume flow measurement. 1 … 4 Channel 2 V:- This parameter can determine a second -,1 … 4 channel for the volume flow measurement.
  • Page 58 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Explanations about dynamic filter monitoring Δp Δp Δp SUP Fig. 81: Filter monitoring principle sketch Zones with variable supply air volume flow Supply air pressure control with ventilator speed control Differential pressure sensor of the filter monitoring...
  • Page 59 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 This is not necessary for dynamic filter monitoring. An approximation of the filter characteristic curve is calculated by determining some system-specific paramet- ers. This approximating characteristic curve can now be used to determine the level of soiling of the filter at any time without changing the ventilator speed.
  • Page 60 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Explanation of the variables used: The flow rate states how much volume of a gas flows through a defined Flow rate The flow rate is stated in m³/h. Maximum flow rate of the ventilator.
  • Page 61 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Submenu: Offset correction [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Offset correction Level 4 Level 5 (parameters) Offset: Auto Zero Offset correction Function 0.000 Pa Offset: adapt Input 0.000 Pa Offset: reset Function Fig. 86: Menu Offset correction...
  • Page 62 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Submenu: Colour change [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Colour change/ 4. Level 5. Level (Parameter) Hysteresis Colour change Input 0.500 Pa Delay Submenu Thresh. low - red: Thresh. low - red Input 10.000 Pa...
  • Page 63 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Pos. Value range Description Threshold high red The name threshold is activated with this parameter. Threshold high red Input of the threshold -100.00 … 100.00 Pa Colour change limit thresholds Colour changes that correspond to certain operating statuses can be defined with the thresholds.
  • Page 64 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH A. delay: simple Menu path: Main menu/ Configuration/ Inputs/Analogue input 1/Colour change/ Delay time/ 5. Level 6. Level (Parameter) Delay: simple Delay Delay 1 Input 0.000 s Fig. 91: Submenu: Delay: simple Pos. Value range...
  • Page 65 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Submenu: Acoustic alarm [Level 5] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Acoustic alarm/ Level 4 Level 5 (parameters) Acoustic alarm Alarm: Menu expansion (1) Alarm: Alarm thresholds.. Sub menu Function test Alert Confirmation: unlimited...
  • Page 66 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Submenu: Alarm thresholds [Level 6] Menu path: Main menu/Configuration/Inputs/Analogue input 1/Acoustic alarm/ Alarm thresholds Level 5 Level 6 (parameters) Alarm thresholds Alarm high: Input Threshold high - ON Input 80.000 PA Threshold high - OFF Input 60.000 PA...
  • Page 67 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Key: low-OFF high-OFF Input signal Measuring range Increasing input signal Start Close low-ON high-ON Decreasing input signal No alarm Alert Fig. 95: Alarm thresholds Input: Sensor serial number [Level 5] Menu path: Main menu/ Configuration/ Inputs/Analogue input 1/Sensor serial number/ 4.

  • Page 68: Menu: Outputs [Level 3]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.4.4 Menu: Outputs [Level 3] Menu path: Main menu/Configuration/Outputs/ Level 2 Level 3 (submenu) outputs Analogue output 1 Analogue output 2 Analogue output 3 Analogue output 4 MODBUS Slave Option Fig. 97: Menu Outputs All analogue outputs are configured in the same way.
  • Page 69 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Item Value range Description Output max. This parameter is used to define the output signal that is issued in the measuring range 0.000 … 10.500V end of the assigned input signal. 0.000 … 21.500mA Limit min.
  • Page 70 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Menü: MODBUS Slave Menu path: Main menu/Configuration/Outputs/MODBUS Slave/ Level 3 Level 4 (parameters) Slave address MODBUS Slave Input Baud rate Input 19200 Configuration Input t3.5 Input 0 ms Endianness: Big Endian Fig. 100: Menü MODBUS Slave...
  • Page 71 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 RTU Framing (t3.5) Frame 1 Frame 2 Frame 3 3.5 char 3.5 char 3.5 char 4.5 char Modbus message Starting Address Function Data CRC Check ≥3.5 char 8 bit 8 bit N x 8 bit 16 bits ≥3.5 char...

  • Page 72: Menu: Datalogger [Level 3]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.4.5 Menu: Datalogger [Level 3] Menu path: Main menu/Configuration/Datalogger/ Level 2 Level 3 (parameters) Data logger Datalogger: Input 1 Sub menu Input 2 Sub menu Input 3 Sub menu Input 4 Sub menu...
  • Page 73 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Menu: Event log [Level 4] Menu path: Main menu/Configuration/Datalogger/Event log/ Level 3 Level 4 (parameters) Event log Event log: Changed param.: Device start: Switch outputs Sub menu Input 1 Sub menu Input 2...
  • Page 74 5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Submenu: Switch outputs [Level 5] Menu path: Main menu/Configuration/Datalogger/Switch outputs/ Level 4 Level 5 (parameters) Switch outputs Switch output 1: Switch output 2: Switch output 3: Switch output 4: Fig. 107: Menu Switch outputs...
  • Page 75 FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 Item Value range Description Thresh. ok - green Thresh. high – yell. Thresh. high red BA_EN_EA16 75 / 88...

  • Page 76: Menu: Language [Level 2]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.5 Menu: Language [Level 2] Menu path: Main menu/Language/ Level 1 Level 2 Language German English Spanish French Portuguese Hungarian Italian Fig. 109: Menu Language The menu language can be changed in this menu. A dialogue box opens in which the change needs to be confirmed.

  • Page 77: Menu: Configuration [Level 3]

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.6.1 Menu: Configuration [Level 3] Menu path: Main menu/System/Configuration../ Level 2 Level 3 (submenu) Configuration.. Factory settings Key functions. In order to… Export parameters Key functions. In order to… Import parameters Key functions. In order to…...

  • Page 78: Menu: System Info [Level 3]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH Example Level 2 Level 3 (display) Overview inputs/outputs Analogue input 1: 4,000 mA Analogue input 2: Analogue input 3: 5,000V Analogue input 4: 7,500V Analogue output 1: 0.000 mA Analogue output 2:...

  • Page 79: Menu: Firmware Update [Level 3]

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.6.4 Menu: Firmware update [Level 3] Menu path: Main menu/System/Firmware update/ 1. Level 2. Level (Function) Overview Inputs / Outputs System System Info Carry out firmware update via Firmware Update USB stick?

  • Page 80: Menu: Unmount Sd Card [Level 3]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.6.6 Menu: Unmount SD card [Level 3] Menu path: Main menu/System/Umount SD card/ Level 2 Level 3 (Function) Firmware update Unmount SD card Date/time Unmount SD card? Unmount SD card Data transfer SD ->USB...

  • Page 81: Menu: Data Transfer Sd->Usb [Level 3]

    FISCHER Mess- und Regeltechnik GmbH Parameterization | 5 5.4.6.7 Menu: Data transfer SD->USB [Level 3] Menu path: Main menu/System/data transfer SD>USB/ Level 2 Level 3 (Function) Data transfer SD-USB Start: . 2016 End.: ../Data transfer SD ->USB Fig. 120: Menu: Data transfer SD ->USB This function is used to copy the logger and event data from the SD card to a USB stick.

  • Page 82: Menu: Delete Sd Card [Level 3]

    5 | Parameterization FISCHER Mess- und Regeltechnik GmbH 5.4.6.9 Menu: Delete SD card [Level 3] Menu path: Main menu/ System/Delete SD card/ 2. Level 3. Level (Function) Data transfer SD -> USB Delete SD card Convert log data Delete SD card?

  • Page 83: Technical Data

    FISCHER Mess- und Regeltechnik GmbH Technical data | 6 6 Technical data 6.1 Generalities The stated technical data only refer to the measuring value display unit EA16 and never take into account the properties of the connected measuring trans- ducer.

  • Page 84: Digital Outputs I/O1

    6 | Technical data FISCHER Mess- und Regeltechnik GmbH 6.3.2 Digital outputs I/O1 ... I/O4 The number of outputs depends on the number of Flex I/O channels configured as an input. It is configured ex-works and, like the level of output voltage, it must be stated on the order.

  • Page 85: Digital Interfaces

    FISCHER Mess- und Regeltechnik GmbH Technical data | 6 6.5 Digital interfaces Type USB interface Micro USB 2.0 SD card slot Micro SD up to 32 GB Field bus interface (option) Modbus RTU Digital 2-wire interface (option) FF62 Temperature and moisture sensor 6.6 Display and operating interface...

  • Page 86: Order Codes

    7 | Order Codes FISCHER Mess- und Regeltechnik GmbH 7 Order Codes Code no. Type Display ← Code no. 3.5‘‘ TFT Touch LCD (horizontal) Version [2.3] ← Code no. 2 channels (2 inputs, 2 outputs, 2 switch outputs) 2 channel...

  • Page 87: Attachments

    FISCHER Mess- und Regeltechnik GmbH Attachments | 8 8 Attachments 8.1 EU Declaration of Conformity C€ EU Declaration of Conformity (Translation) For the product described as follows Measuring value display Product designation EA16 Type designation it is hereby declared that it corresponds with the basic requirements...
  • Page 88 8 | Attachments FISCHER Mess- und Regeltechnik GmbH 88 / 88 BA_EN_EA16...
