Sdataway EasyBus3 Series Technical Documentation Manual

Easy3 System – Technical documentation
Property of SDATAWAY SA- © 2018 SDATAWAY SA All Rights Reserved
Easy3-H – Easy3-M
230 VAC Power Line Communication system

Interactive colour touch screen 4"

Easy-to-Use graphical interface

Up to 128 devices on each Sub-Network

Up to 1000m length by Sub-Network

Up to 3 Sub-Networks on the same display
o Up to 384 devices in one installation
o Up to 3000m total network length installation

Advanced power line communication
o 255 communication channels
o Up to 28800 bps
o Automatic adaptive modulation

Configurable inputs and outputs
o 8 universal digital inputs/outputs
o 2 output relays
o Configurable I/O functions

Integrated 2 ports ethernet switch

Monitoring function with USB or SD card

Integrated filter

Device groups
o 2 groups on each network
o Group by priority or function

Group control/monitoring with digital I/Os

Modbus RTU/RS-485 and TCP/IP

BACnet MS/TP or BACnet IP by gateway

DIN rail or screw fixation
Page 1 / 38
EasyBus3® System
Technical documentation
Revision 1 / April 2019
