Operation Guide
Hydraulic Leveling Systems #2000, #2010, #3000, and #30130
Introduction
Page
The Level Best leveling and stabilizing system is an electronically controlled/hydraulical-
ly operated unit that consists of a 12 volt DC powered motor/pump/manifold assembly
1
with fluid reservoir, hydraulic hoses, four hydraulically operated jacks, a control unit with
switch panel, and optional level sensor unit and pressure sensor. It is designed to meet
1
the varying requirements of vehicles ranging from class "C" motorhomes to the large
2
class "A" motorhome.
3
If, after thoroughly reading this manual, you still have questions in regard to the opera-
3
tion and maintenance of the Level Best system, please contact the Kwikee Service
3
Department at 1-800-736-9961.
4
4
WARNINGS
5
Do not use the Level Best system as a lift for changing tires or working
5
under the vehicle.
6
Never check for hydraulic fluid leaks using your hands and/or any other body part. The
6
leaking fluid is under pressure and is capable of cutting and penetrating your skin
resulting in severe injury.
7
When extending the rear stabilizers, do not lift the wheels beyond ground contact. This
8
overrides the braking effect of both the transmission park and parking brake. Without
this braking, it is possible for the vehicle to roll unexpectedly forward (or backward) off
the jacks. This could cause severe injury or even death.
Holding a control switch in the "extend" or "retract" position for a time period longer
than necessary to fully extend or retract the hydraulic cylinders, can cause overheating
and damage to the pump motor as well as the electrical components.
Do not use the leveler as an emergency brake, They are not designed for any type of
vehicle braking purpose.
Do not use the levelers on icy or slick surfaces on which the foot pads may slip.
IN THE EVENT OF ACCIDENTAL EXTENSION
1.
2.
3.
Bring the vehicle to a safe and complete stop as soon as possible.
Turn the leveling systems power switch on and press the all up switch.
Visually inspect the vehicle undercarriage for any problems.
Operation
Guide
Advertisement
Table of Contents
Related Manuals for Kwikee Level Best 2000
Summary of Contents for Kwikee Level Best 2000
-
Page 1: Table Of Contents
“A” motorhome. Control Panel If, after thoroughly reading this manual, you still have questions in regard to the opera- Manual Mode tion and maintenance of the Level Best system, please contact the Kwikee Service Auto Mode Department at 1-800-736-9961. Stabalizing... -
Page 2: Operation
Level Best Operation Guide Page 2 Operation NOTE: To prevent improper operation of the leveling The Level Best system performs the dual function of leveling the vehicle and, once a level system, which could result in plane has been achieved, stabilizing the vehicle. When leveling the vehicle, it may not be necessary to use all of the leveling jacks however, to stabilize the vehicle, all jacks should be damage to the levelers and/or extended to contact the ground. -
Page 3: Auto Mode
Level Best Operation Guide Page 3 Control Panel Functions The ON/OFF switch, located in the upper left hand corner, controls the supply of power for all panel functions, activation of this switch is indicated by its green LED. The ALL UP (leg retract) switch is located in the lower left hand corner of the control panel. Activation of this switch causes all legs to retract to the travel position. - Page 4 Level Best Operation Guide Page 4 Stabilizing NOTE: To prevent the Observing the precautions set forth on the previous pages of this manual, you are now ready possibility of damaging the to begin leveling your motor home. With the vehicle engine running, place the transmission in levelers and/or vehicle, it is park and set the parking brake.
-
Page 5: Setting Level Sensor
The Level Best hydraulic leveling system should be routinely checked as part of a regular vehicle maintenance program. Kwikee recommends checking the system twice a year: in the spring prior to the heavy travel season and in the winter, prior to storage. -
Page 6: Error Codes
6. To retract jacks with a control failure, see Control Panel Jumper Instructions on Page 7. This list represents a cross section of some possible problems and the corresponding solutions. After reviewing the manual, if you still have problems or questions, please contact the Kwikee Service Department at 1-800-736-9961. -
Page 7: Control Panel Jumper
Level Best Operation Guide Page 7 Control Panel Jumper Instructions To be used in the event of a control failure. 1. Remove the control panel from the bezel and disconnect the wire harness. (See Figure 2.) 2. Make sure the area around and below the motorhome is clear of all obstructions and that no personnel are under the vehicle. -
Page 8: Limited Warranty
Level Best Warranty 5 years from the date of purchase. Kwikee’s obligation under this warranty is limited to the repair or Registration. replacement of defective parts returned to Kwikee's' factory.
