Tonton C8204DN4-H Instruction Manual

Wifi speed dome ip camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

W I F I S P E E D D O M E I P C A M E R A
INSTRUCTION MANUAL
Statement:
The manual will be updated from time to time. If you use this manual have not encountered problems, please
contact our technical support department or product vendor. The company has the right without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C8204DN4-H and is the answer not in the manual?

Questions and answers

Summary of Contents for Tonton C8204DN4-H

  • Page 1: Instruction Manual

    W I F I S P E E D D O M E I P C A M E R A INSTRUCTION MANUAL Statement: The manual will be updated from time to time. If you use this manual have not encountered problems, please contact our technical support department or product vendor.
  • Page 2 Introduction The IP Camera combines a high quality digital video camera with network connectivity and a powerful web server to bring clear video to your desktop from anywhere on your local network or over the Internet. Notice: This product may cause interferences with other wireless equipment that operates at 2.4GHz ISM band.
  • Page 3 Product Assurance This camera will emit electromagnetic wave, just like other wireless products, but its transmitting power is less than other wireless products such as mobile phones. The 2.4GHz wireless camera meets wireless frequency security standards and recommended indexes while working. These standards and indexes are certificated by academic organization and represent the cogitative research of the scientific workers who continuously explore and annotate the involved fields.

  • Page 4: Appearance And Interface

    Appearance and interface IP66 Metal Housing Microphone DC12V Input LAN Port Vertical: 6PCS 0°～120° Reset Button IR LED Array Speaker (Waterproof) Lens See Wider Angle Horizon: 0°～355° Micro SD Card Slot Built-in, Waterproof Photoresistor - 4 -...
  • Page 5  Mobile APP view quick guide Wired network connection 1. Connect network cable to camera, Plug in the power adapter. - 5 -...
  • Page 6 2. The IP Camera and phone are in the same LAN, Connect your phone to a WiFi network, Monitoring software download. Install App: ① Open the Google Play & App Store . ② Search for “ iSmCam ”. ③ Tap INSTALL APP to download and install. iSmCam Android iSmCam App iOS iSmCam App...
  • Page 7 - 7 -...
  • Page 8 4. Click the camera icon to open real-time monitoring screen - 8 -...
  • Page 9 4.1 Monitor screen buttons Introduction - 9 -...
  • Page 10 5. Change password Can change the access password of camera (Default password: admin) - 10 -...
  • Page 11 6. Alarm Settings: You need the cameras settings, click the Settings button in the rear of the camera - 11 -...
  • Page 12 7. Action with Alarm: Alarm Push: open your phone can receive alarm information tips;  Alarm Notifications Click ON,open alarm Notifications  SD Card record while alarm Choose on, means the alarm video will save to SD Card;  Email alarm and send pictures Choose on, means it will send pictures to specified mailbox when alarm - 12 -...
  • Page 13 8. Recording Schedule  Video file length: 15-900seconds can be set, default is 600seconds  whether video on: on off can be set, default is off - 13 -...
  • Page 14 9. Audio Setting Input type Linear input and microphone input can be set when audio input type is microphone input, the input volume and output volume is 80 and 95; when audio input type is linear input, the input volume and output volume is 15 and 95; - 14 -...
  • Page 15 10. Video settings Code rate The device code rate of first stream and second stream can be self-define; scope range 32kbps-6144kbps Frame rate The device frame rate of first stream and second stream can be self-defined; Video coding level 1-6 can be set, default is 1; the smaller the value, the better the image level, the big the stream Video system 50HZ and 60HZ can be set - 15 -...
  • Page 16 - 16 -...
  • Page 17 11. WIFI setting Find WIFI setting at bottom of page in the advance setting page - 17 -...
  • Page 18 Click Wi-Fi manager button then set wifi ssid； Choose router’s ssid Type WIFI password Camera will successfully connect wif(user need unplug power plug and network cable first then plug power again） - 18 -...
  • Page 19 12. SD Card setting Can obtain the total space of the SD card and the size of the available space, can format SD card - 19 -...
  • Page 20 13. Time setting ①The device time can synchronization mobile phone time ②can set device time zone, after setting successfully, the device will restart - 20 -...
  • Page 21 14. Email Setting Eg: sending mailbox is hotmail mailbox Smtp server：smtp.live.com Server port：465 Secure connection：SSL user name and password is hotmail account and password Receive address ： the mailbox that receive alarm pictures Send address: sender’s mailbox address, if it is gmail mailbox, need to fill the hotmail mailbox address (the same as user name) Theme and information can be filled in casually After...
  • Page 22 15. FTP Setting FTP server： fill in the FTP address Server port：fill in FTP port； fill in the user name and password setted on FTP server after completed, click Apply; then click test to know whether can send pictures to FTP server - 22 -...
  • Page 23 16. System Setting Restart the camera and restore the factory Settings - 23 -...
  • Page 24 17. Device information You can obtain device information: including network status, user connection number, IP address, Subnet mask, gateway, DNS and so on. - 24 -...
  • Page 25 18. Local pictures Click , enter into playback interface ① Local pictures are saved by ID ② Long press one picture can delete it - 25 -...
  • Page 26 19. Watch the video Click , enter into watching interface You can playback the videos in SD Card, including timing video and alarm video. - 26 -...
  • Page 27 The instructions of WIFI configuration in AP mode - 27 -...
  • Page 28 1. Please connect power supply, do not connect network cable（The AP mode will disappear after the network wire is connected to the network.） 2. Wait around one minute, through the mobile phone WIFI Settings, search out the camera AP SSID; 3.
  • Page 29 The specific operations as shown in below picture: - 29 -...
  • Page 30 - 30 -...
  • Page 31 Tip: After WIFI configuration in AP mode successfully, AP mode will disappear. If you want to use the AP mode, need to restore the camera to factory Settings; please press the RESET button in the equipment base for 10s. - 31 -...
  • Page 32  PC CMS view quick guide You can also use the computer monitor; The first step: Open the CD and select the (iP2P client) software Step 2: Click on the icon monitoring software installation is complete, run the monitoring software - 32 -...
  • Page 33 Click on the icon to enter the settings interface, Add the camera as follows: - 33 -...
  • Page 34 The third step: enter the setup interface Follow these steps to complete the installation: ① click “search: ② Check the left to search for the camera and the right area: ③ Click “Add” Complete the installation Step Four: Watch the monitor screen Click the icon Enter the monitoring interface;...
  • Page 35 - 35 -...
  • Page 36 Tonton Security Address: Room 101, Building 28, Jindi Dynamic Port Business Park, No.29 Xianggong Road, Zhuhai, China Tel: +1 (213) 443-6766 Tonton security Email: service@tontonsecurity.com Service website://www.tontonsecurity.com...
