Summary of Contents for EV International EV 300i
- Page 2 Dear Customers, We deeply appreciate your business. Serving you is our highest priority. We are available for your questions at any time. Please Contact: We wish you many happy moments with your EV 3000i! From the whole team at E V International Ltd.
-
Page 3: Table Of Contents
Content Theme Page Introduction Scope of supply Safety regulation Technical data Before putting into operation Filling with water Placing the steam hose Connecting attachments Display Attachments Turning on Directions Ironing Air freshener Cleaning and maintenance Legal aspects Accessories for EV 3000i Maintenance... -
Page 4: Introduction
Introduction Your EV 3000i is a result of longtime experience and EV 3000i is designed for home cleaning with dry steam. extensive technological research. The steam and high temperature easily remove troubling We have created EV 3000i for you as a perfect device stains, hard water spots, stubborn dirt, grease etc. -
Page 5: Scope Of Supply
Scope of supply The supply provides you with the following accessories: 1. Steam hose 2. Universal brush 3. Triangular brush 4. Point nozzle 5. Extension pipes 6. Plunger - Drain opener 7. Round copper brush 8. Round plastic brush /small/ 9. -
Page 6: Safety Regulation
Safety regulations Strict compliance with the instructions and maintenance and grounded. You can see the power consumption recommendations is at the basis of the intended of the appliance on the manufacturing plate on the conditions of use. In improper use or non-compliance bottom of the appliance. - Page 7 Safety regulations ▹ ▹ Never use the appliance with wet hands or feet. During repairs use only genuine parts. ▹ ▹ Do not use the appliance within walking distance of Always keep the appliance in horizontal position. ▹ sinks, tubs, showers or water reservoirs. Do not direct the steam jet in or towards electrical ▹...
-
Page 8: Technical Data
Technical data - EV 3000i ▹ Power supply 220 - 240 V - 50/60 Hz ▹ Max. total working power 2850 W ▹ Max. boiler power 2000 W ▹ Max. iron power 850 W ▹ Boiler capacity 2.2 I (0.58 gal) ▹... -
Page 9: Before Putting Into Operation
Before putting into operation Description of the appliance and an explanation of the figures 1. Screw cap of boiler 2. Tank 4/ 4.1/ 4.2 3. Main switch (device) boiler on / off 4. Display 4.1 Shortage of water: H2O appears on the display + acoustical signal 4.2 Steam is ready: 170 °С... -
Page 10: Placing The Steam Hose
Connecting attachments 2. Inserting the steam hose into EV 3000i 4. Display for EV 3000i The protective cover of the contact socket (6) is opened up. Now you have to insert the plug of the steam hose into the socket. Now, the hose is connected to the appliance. -
Page 11: Attachments
Attachments Activation of the cleaning with hot water (A). You can chose the steam level by pressing button (B). NO STEAM, EV1, EV2, EV3 Firmly press the stainless steel sponge to the big round brush. Triangular brush + Universal brush + Thermofiber = Universal and triangular brush with thermofiber. The brush mat provides moisture reduction and temperature accumulation. -
Page 12: Turning On
Turning on The appliance must be filled with water. Your appliance EV 3000i except dry steam function has also a function for hot water under high pressure. Now activate the main switch (3); Boiler on appears on For activation of this function you should press and the display (4), the appliance signals that it is ready for hold button (A). -
Page 13: Directions
Directions Accessories Amount of steam Absorbers Medium, large amount of steam Depositions of fats are difficult to remove. Use the point nozzle to clean the grease from the filters. Clean the absorber from the outside depending on the access opportunities. For this purpose you can use the triangular brush with thermofiber cloth stretched on it. - Page 14 Directions Accessories Amount of steam Shower cabin Medium, large amount of steam If there are significant limestone deposits on glass For rubber seals, glass, doors we recommend joints and plastic surfaces For joints and chutes use the point nozzle with round brush with using some vinegar there are numerous maximum amount of steam.
- Page 15 Directions Accessories Amount of steam Small, medium Animal cages amount of steam Baskets for dogs and cats, For removal of old and cages for birds, cages for stubborn stains you must hamsters and more. repeat the procedure. lean the cages with the nozzle point and attached small or With the steam you large round brush.
- Page 16 Directions Accessories Amount of steam Varnished surfaces Small amount of steam Varnished surfaces are Clean the surface quickly. cleaned very well. Do not hold the steam jet at one point. Use only small amount of steam. Treat the surfaces with a small amount of steam at 10-15 cm./ (3-5 in) distance.
- Page 17 Directions Accessories Amount of steam Metal Small, medium amount of steam Stainless steel, anodized aluminum, perforated Use small amount of steam sheet, brass and others. not to wet the metal too much. Depending on the size of the surface choose the point nozzle or the triangular brush (then polish with the thermofiber) or the triangular brush with thermofiber strained on it.
- Page 18 Directions Accessories Amount of steam Parquet and floor Small, medium laminate amount of steam For parquet floors different types of wood is used, such as beech, oak, maple, ash, For cleaning parquet flooring use the universal brush with birch and many others. stretched thermofiber on it.
- Page 19 Directions Accessories Amount of steam Radiators Small, medium, large amount of steam There are smooth and ribbed radiators. Put behind and under the radiator an old cloth. Dust Clean smooth radiators with the triangular brush with is collected even better thermofiber strained on it.
- Page 20 Directions Accessories Amount of steam Rattan Small, medium, large amount of steam Cleaning the dust from rattan furniture and knitted Keep a cloth behind armchairs is difficult. the braid to absorb the deposited dust. Treat knitted furniture with the point nozzle and little steam and then wipe with thermofiber.
- Page 21 Directions Accessories Amount of steam Car windows Medium amount of steam During rain deposition of silicone and dirt causes the Clean windows are safe Use the point nozzle and then rub with thermofiber. Keep a formation of lines. The result windows.
- Page 22 Directions Accessories Amount of steam Car upholstery Small amount of steam Different materials are Move the triangular brush used for car upholstery. So several times briefly over please do a test cleaning the surfaces. Regular on a hidden place maintenance leads to (for example on the long-term result.
- Page 23 Directions Accessories Amount of steam Tiles / joints Small, medium amount of steam There are many different types of tiles. Almost each Now without much efforts tile can be cleaned very you can make the steam well with your EV 3000i. Clean your tiles with the universal brush with strained works.
-
Page 24: Ironing
Ironing Instructions Description Before using the iron must be connected to EV 3000i. The iron is equipped with the following features: Before using the iron read the instructions. Steam button Do not leave the iron unattended while connected to Rotating button for fabric selection the appliance. - Page 25 Ironing Connecting and turning on Vertical ironing Steam output is independent of the iron In order to facilitate your work, we recommend always slope. Therefore, the steam can be used using the Teflon mat. In any case you have to take in for refreshment of curtains, clothing and mind that here you must always use higher temperature.
-
Page 26: Air Freshener
Air Freshener ON/OFF Fig. 1 Air freshener use (option) Before using the air freshener wait until the machine heats up to operating temperature. Connect it to the appliance as shown in Fig. 1. Note that the air freshener does not start automatically. Please press the ON/OFF button to activate and deactivate the air freshener. -
Page 27: Cleaning And Maintenance
Cleaning and maintenance ▹ Always pull out the plug before cleaning and mainte- After complete cooling of the appliance reopen nance of the appliance. the screw gate of boiler (1) and pour out the water; ▹ The following operations must be carried out by compe- Close the boiler again using the screw. -
Page 28: Legal Aspects
Legal aspects This user guide contains the information necessary According to Art.13 of the Law enforcement No 151 of for correct use, proper handling and skilled technical July 25, 2005 Implementation of Directives 2002/95 /EU, support of the machine. 2002/96/EU and 2003/108/EU for reduction of the use of hazardous substances in electrical and electronic Knowledge of and compliance with this guide is a equipment and removal of waste. - Page 29 Legal aspects General Vapeur Ltd. Company, Strada per Castelletto 19-21, 20080 Albairate (MI), declares on own responsibility that the device referred to in this declaration of conformity complies with the following safety requirements laid down in the Directives for the CE marking: ELECTRICAL SAFETY AND EMC ▹...
-
Page 30: Accessories For Ev 3000I
Additional accessories Steam hose Universal brush Triangular brush Point nozzle Extension pipes Round stainless Plunger - Drain steel brush opener Round copper brush Iron Round plastic brush Thermofiber towel /small/ Round plastic brush Air Freshener /large/ Boiler key Universal and Triangular Bottle for filling Round steel brush Round horsehair brush... -
Page 31: Maintenance
Maintenance...
Need help?
Do you have a question about the EV 300i and is the answer not in the manual?
Questions and answers
When I put water to fill and it spills out as I put water into it
If water spills out when filling the EV International EV 300i, ensure you are pouring distilled water into the correct tank (tank 2) and not overfilling it. Be careful not to let water enter other parts of the machine, as this could cause damage to the water circulation system and heating element.
This answer is automatically generated
Where can I get the fluid mentioned in the manual for cleaning my EV Atlantis steamer?
The cleaning fluid for the EV International EV 300i steamer is provided by the service of EV International Ltd. It is not included in the standard kit and must be obtained from their service.
This answer is automatically generated
when plugged in the boiler light switch flashes but boiler does not heat and light does not stop flashing
The EV International EV 300i boiler light switch may flash, but the boiler does not heat due to a shortage of water. When there is not enough water, the steam output is interrupted, and the boiler automatically shuts off to prevent damage. The display will show "H2O" along with an acoustical warning signal. To resolve this, refill the tank with tap water and ensure the boiler cap is securely tightened before restarting the appliance.
This answer is automatically generated
Si può pulire la mochette?
Yes, the EV International EV 300i can clean carpets. Use a point nozzle with steam at an obtuse angle (without touching the nozzle to the carpet) to treat stains. Then mop up spots with a towel and clean with a small amount of steam using the universal brush.
This answer is automatically generated
What does it mean to press 7 bar
