- Page 1 Installation + User Guide SNYSC1 Sony Compatible SiriusConnect Interface ™...
- Page 2 SIRIUS Satellite Radio Tuner. The SNYSC1 is compatible with all Sony SAT-Radio-Ready headunits. It can be con- nected to either the SCC1 SiriusConnect Vehicle Tuner or the SCVDOC1 SiriusCon- nect Vehicle Dock with a compatible Dock and Play or portable SIRIUS radio attached.
-
Page 3: Table Of Contents
Mounting the SNYSC1 Interface ..... . 12 Wiring the SNYSC1 Interface ..... . . 15... -
Page 4: Copyrights & Trademarks
© 2007 Sirius Satellite Radio Inc. All Rights Reserved. ® “SIRIUS”, the SIRIUS dog logo, channel names and logos are trademarks of Sirius Satellite Radio Inc. “Sony” is a registered trademark of Sony Electronics Inc. “iPod” is a registered trademark of Apple Inc. All Rights Reserved. -
Page 5: Warning And Safety Information
Warning and Safety Information FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Canadian Compliance
Canadian Compliance This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Safety Precautions Be sure to observe the following warnings. Failure to follow these safety instructions and warnings may result in a serious accident and/or personal injury. -
Page 7: Package Contents
Package Contents The following items are included with your purchase of the SNYSC1. Unpack the ma- terials carefully and make sure that everything shown is present. If anything is missing or damaged, or if the device fails to operate properly, notify your dealer immediately. It is recommended that you retain the original carton and packing materials in case you need to ship your kit in the future. - Page 8 Unilink™ data Cable Unilink™ data Cable Package Contents audio Cable audio Cable mounting screws (x4) mounting screws (x4)
-
Page 9: Compatibility
Compatibility The SNYSC1 SiriusConnect Interface is compatible with all Sony SAT-Radio-Ready headunits. The UniLink input pass-through connector on the SNYSC1 can support the Sony iPOD adapter or Sony CD Changer. Compatibility... -
Page 10: Connectors
Connectors Figure 1 and the table following identify and describe the connectors of the SNYSC1. AUDIO IN UNILINK AUDIO IN UNILINK IN description of the SNYSC1 Connectors Connector Audio In Connectors L/R UniLink In Connector Audio Out Cable Connectors INPUT... - Page 11 UniLink Out Connector Power Connector description Connects to the SCC1 tuner or the SCVDOC1 dock Connects to the UniLink connector on the Sony headunit Connects to the vehicle’s DC power/ground using the provided power harness Yellow: Connects to a positive DC voltage source...
-
Page 12: Installation
By removing the mounting plate from the SNYSC1, and instead mounting it directly to a surface using either double-sided stick tape, hook and loop, or other adhesive material (not provided). - Page 13 By attaching the SNYSC1 and the SIRIUS SCC1 tuner together. To connect the devices together, simply remove the mounting brackets from each device, rotate them 90°, and connect them together as shown in Figure 4. figure 2 figure 2 figure 3...
- Page 14 figure 4 figure 4 Installation...
-
Page 15: Wiring The Snysc1 Interface
1 amp of power. Connect the black wire to the vehicle ground. (Figure 5) The power harness for the SNYSC1 has power filter box which contains a fuse for the 12V battery connection. Figure 5 also shows the location and type of fuse, and also the identifies the pin-outs of the power connector. - Page 16 A simple configuration which utilizes only the SNYSC1 Interface. (Figure 6 on page 17.) A configuration which utilizes an iPod adapter in addition to the SNYSC1 Inter- face. (Figure 7 on page 18.) A configuration which utilizes an iPod adapter and a CD changer in addition to the SNYSC1 Interface.
- Page 17 SIRIUS SCC1 SC OUTPUT ANTENNA SIRIUS SNYSC1 UNILINK IN AUDIO IN AUDIO OUT SC INPUT UNILINK OUT Sony Headunit figure 6 figure 6 SIRIUS SCVDOC1 POWER Installation...
- Page 18 Sony XA-110IP iPod Adapter Installation SIRIUS SCC1 SC OUTPUT ANTENNA AUDIO IN UNILINK IN AUDIO OUT SC INPUT UNILINK OUT Sony Headunit figure 7 figure 7 SIRIUS SCVDOC1 SIRIUS SNYSC1 POWER...
- Page 19 XA-C40 or XA-300, it is important to connect the devices to the correct UniLink inputs on the source selector: Input 1 = SIRIUS SNYSC1 Input 2 = Sony XA-110IP iPod Adapter Input 3 = Sony CD Changer Sony Headunit Sony CD Changer SIRIUS...
-
Page 20: Operation
Operation For operation instructions, please consult the instruction manual which accompanied your headunit. Additional instructions may also be found in the manual which accompanied your SIRIUS SCC1 tuner or SCVDOC1 dock and SIRIUS radio. Operation... -
Page 21: Specifications
Specifications Power Requirements ........11-14 VDC, 1A In-Line fuse (Located inside Filter Box) . - Page 24 SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 800.869.5590 SNYSC1 SiriusConnect™ Interface (SNYSC1120407a) OO.ABCD1.001...
