Summary of Contents for HartwellMedical EVAC-U-SPLINT EV3000
- Page 1 APPLICATION GUIDELINES Model Number: EV 3000 EV 3000SR _________________ Rx Only...
-
Page 2: Product Terminology
APPLICATION GUIDELINES roduct erminology Splint Straps Flange Tubing MaxiValve™ Red Leashed Cap Model Number and Splint Size (S, M, L,) EVAC-U-SPLINT EVAC-U-SPLINT ® ® PecificationS Dimensions: Large Splint Medium Splint Small Splint Length: 40.0" ( 101.6 cm) 27.5" (69.9 cm) 19.5"... -
Page 3: Table Of Contents
ntroduction able of ontentS The EVAC-U-SPLINT has been designed to aid in ® stabilization of an injured or ill person with a minimum amount Product Terminology ........2 of movement to the injured area or extremity. Unlike a rigid board splint or a metal ladder splint, the EVAC-U-SPLINT uses Important Information vacuum technology to conform to the exact shape and contours Specifications ........... 2 of the patient’s anatomy, providing improved immobilization Introduction .......... -
Page 4: Operating Instructions
APPLICATION GUIDELINES Perating nStructionS It is recommended by the Centers for Disease Control that emergency medical personnel wear eye and face protection, in addition to protective gloves, whenever there is a possibility of coming into contact with patient blood or any body fluids. Positioning Always make sure that the basic ABC’s of airway, breathing and circulation are intact prior to any splinting activities. -
Page 5: Application
• The EVAC-U-SPLINT should be soft enough to easily and ® comfortably conform to the injured area, yet firm enough to keep the beads in place if positioned vertically. This adjustment method can easily be made by simply removing or allowing air to enter the splint. TIP: When working on a dislocated shoulder, evacuate enough air from the splint to make it resemble modeling clay, then conform the splint to your partner who is mimicking the patient’s injury. Then, simply transfer the “shaped splint” to the patient. (See special applications on... -
Page 6: Evacuation
APPLICATION GUIDELINES Evacuation • While holding the flange tubing on the splint, connect the MaxiValve™ coupling on the pump hose to the MaxiValve on the EVAC-U-SPLINT . You should hear a “click” when ® the connection has been made. If the red leashed cap has not been removed from the MaxiValve, remove the cap prior to connecting the pump hose. Photo 7. • Evacuate the air from the splint by using the manual pump until the splint is firm. You will feel resistance on the pump handle when the splint has been sufficiently evacuated. Photo 8. • Remove the pump hose from the MaxiValve by depressing the metal tab on the pump hose coupling. The evacuated splint has now formed a rigid supportive “cast” around the injured area. Photo 9. Place the red leashed cap back on the MaxiValve. -
Page 7: Valve And Pump Operation
Valve and Pump Operation To Evacuate Air: (Manual Pump) • Manually remove the red leashed cap from the Maxi-Valve™. Photo 11. • While holding the flexible flange tubing just below the MaxiValve, attach the vacuum pump hose to the MaxiValve. You should hear a “click” when the connection has been made. Photo 12. • Evacuate the air from the splint. • Remove the pump hose from the MaxiValve by depressing the metal tab on the pump hose connector. Place the red leashed cap back on the MaxiValve. - Page 8 APPLICATION GUIDELINES Special Applications The EVAC-U-SPLINT is a versatile product that can be ® used in many ways for immobilizing and support of a variety of suspected injuries. The EVAC-U-SPLINT is only limited by the creativity of the users. Some of the unique applications of the EVAC-U-SPLINT are noted below. Dislocated Shoulder The EVAC-U-SPLINT can be especially helpful when caring for a patient with a dislocated shoulder. Frequently, these patients are in extreme pain and are holding their injured arm in a position that causes them the least amount of discomfort. • Evacuate a small amount of air out of the splint to make it like modeling clay. • Have your partner pose in the same position as the patient and then mold the splint around your partner’s arm. NOTE: You can do this same type of pre-forming by using your own lower leg and foot. Photo 15. • Transfer the splint to the patient and complete the molding of the splint around the patient’s injured area.
-
Page 9: Storage
NOTE: The EVAC-U-SPLINT can be machine washed using torage a washing machine without an agitator. Make sure the MaxiValve The EVAC-U-SPLINT set comes in a duffel bag style carry is protected with the red leashed cap prior to placing the splint ® case that easily fits in most vehicle compartments or under a into the washing machine. squad bench. The splints and the manual pump should always be stored in their carry case to reduce the potential for getting them soiled or damaged. They should NOT be stored in compartments exposed to extreme heat or cold and should NEVER be placed next to a muffler or exhaust system. Photo 19. aintenance To properly maintain your EVAC-U-SPLINT, establish a preventative maintenance program that meets the needs of your particular service area. Daily inspection should include looking for anything that would affect the integrity of performance of the... -
Page 10: Customer Service
APPLICATION GUIDELINES ePair rocedureS uStomer ervice These instructions are intended for minor repairs of small holes The lot number is located on the front of the splint underneath the “Property of” area. Record this number with other important or tears in the fabric material of the extremity splints. Large rips information, such as date of purchase and dealer name in the or tears may require the product to be replaced. Contact your space provided. Retain this manual for reference and include it authorized Hartwell Medical dealer or call us directly if you have with any change in ownership of this product. -
Page 11: Parts List
artS iagram artS Replacement Ref# Part Number Description Quantity EV 15P MaxiValve™ Replacement Kit (3 MaxiValves, 3 Leashed Caps and 3 Hose Clamps) EV 101 EVAC-U-SPLINT Small Extremity Splint ® EV 102 EVAC-U-SPLINT Medium Extremity Splint EV 103 EVAC-U-SPLINT Large Extremity Splint EV 14 EVAC-U-SPLINT Carry/Storage Case EV 12C... -
Page 12: Training And Maintenance Log
APPLICATION GUIDELINES ocumentation of raining Everyone who will be using or operating the EVAC-U-SPLINT should be required to actively participate in the initial ® training and all subsequent refresher training sessions. This will ensure a clear understanding of the function and capabilities of the EVAC-U-SPLINT. These are suggested documentation formats. Additional copies may be necessary to meet your organization’s needs. Photocopy or create additional forms according to your medical director’s guidelines. Instructor’s Date Attendees Name Training Site aintenance Routine inspection and maintenance is required to keep the EVAC-U-SPLINT ready for immediate use. If, at any time, the EVAC-U-SPLINT is suspected of not functioning properly it should be taken out of service until such time that it can be thoroughly inspected and properly repaired or replaced. Technician’s Date Maintenance Performed Name Signature 6354 Corte del Abeto, Suite F • Carlsbad, CA 92011 1-800-633-5900 • (760) 438-5500 • Fax (760) 438-2783 www.HartwellMedical.com ©2016 Hartwell Medical LLC - All rights reserved AGEV 10/16...
