Summary of Contents for INNOTRIK AUCTOPUS I-1208 Series
- Page 1 HD Conference Camera with Wireless Speakerphone (Camera Part) AUCTOPUS I-1208 (Camera Part) User Manual V1.0.0 Shenzhen Innotrik Technology Co., Ltd...
-
Page 2: Table Of Contents
Content Legal Statement Preface Safety Precautions 1 Product Overview 1.1 Production Introduction 1.2 Features 1.3 Package list 1.4 Component description 2 Connection 3 Operating Description 4 Specification... -
Page 3: Legal Statement
Legal Statement Copyright Statement © Shenzhen Innotrik Technology Co., Ltd . All rights reserved. Information contained in this document should not be reproduced, spread, distributed or stored by any person in any form without prior written license of Shenzhen Innotrik Technology Co., Ltd (hereinafter referred to as "Yinluo”). -
Page 4: Preface
Preface Overview This document describes in detail the quick configuration of the AUCTOPUS I-1208 series. Symbol Conventions For the purpose of this document, the following signs that may exist herein mean as below: Symbol Description Danger indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 5: Safety Precautions
Safety Precautions Before using the product, read and abide by the following requirements to prevent damage to the product or your belongings. Caution · Transport, use, and store the product only under the appropriate temperatures and humidity. · Install the product in a well-ventilated place and do not block the device's air vents. -
Page 6: Product Overview
Product Overview Product Introduction AUCTOPUS I-1208 is a separate audio-video conference camera,configured with 120 ° shooting angle,1080P HD webcam and 2.4 G wireless speakerp- hone, suitable for small and medium-sized conference scenes, personal business, home or leisure place. Features · 1080P HD camera 120 degree shooting wide-angle, clear and fluid picture ·... -
Page 7: Package List
Product Overview Package list Please check whether the materials are complete according to the following table when opening the box. Name Picture Pcs Function Description Conference shooting Pickup and display conference Camera audio Speaker- phone Jack Optional accessories and goods column in kind prevail Speakerphone charging cable... -
Page 8: Component Description
Product Overview Component description Part 1: HD network camera Lens Lens clamp Horizontal shaft Clamp Adjustable base USB cable (option) Part 2: 2.4G wireless speakerphone Triangular Indicator Mini USB interface Loudspeaker 3.5mm audio interface Microphone Bottom right Bottom left Indicator indicator Microphone mute Loudspeaker mute... -
Page 9: Connection
Connection Connect HD camera to PC and long press to power on speaker phone,long press again to power off. -07-... -
Page 10: Operating Description
Operating Description ·Connecting USB line to computer, the following tips will appear in the lower right corner of the computer when first time using. ·When the device driver is installed successfully, the following prompt will appear on the computer side ·... - Page 11 Operating Description ·Another way to check whether AUCTOPUS I-1208 is being used on the computer, click the "speaker" icorn,and then it will show as following: ·Click "audio device" or "display devices",and then it will shows: ·Check whether the default device is AUCTOPUS I-1208, if not, select it as the default one and the it can work as normal.
- Page 12 Operating Description ·If the color and resolution of video are found to be abnormal, it can be used in camera adjustment special software “Amcap”to check. Check the output size of the white balance and video for the corresponding values. Check the white balance option with a default value of 4600 Video output size, select 1920*1080 Or change the camera effect to "restore the default effect"...
-
Page 13: Specification
Specification Description Specification Camera:104*139*124mm Dimension Speakerphone:155*148*37mm Camera:500g Net weight Speakerphone:337g Black Color USB 2.0 Interface Battery(speakerphone) Built-in lithium battery (7-10H) Lens 1/2.8, fixed focus, 120 degree Angle Sensor Full HD CMOS sensor Voice pickup range 3m max 1920*1080 Video Up to 30FPS Image transmision speed Aperture coefficient F2.0... - Page 14 (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Shenzhen Innotrik Technology Co., Ltd Address: Room 502-504,5/F,Deguanting Business Center,No.88 Xinansan Lu,28 District,Baoan, Shenzhen, P.R.China P.C.: 518101...
