Summary of Contents for Clarke APA240
- Page 1 AIR PURIFIER MODEL NO: APA240 PART NO: 3230512 OPERATION & MAINTENANCE INSTRUCTIONS GC1114...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Air Purifier. The APA240 Air Purifier reduces the amount of animal dander (skin cell particles), pollen, and industrial pollutants in the air, and therefore improves the air quality. It also filters out ultra-fine particles larger than 20 nanometers, including bacteria and some viruses.
-
Page 3: Technical Specification
TECHNICAL SPECIFICATION Power source 230 Volts AC 50Hz IP Rating IPX0 Electrical Insulation Class Operation temperature 5 - 40ºC Dimensions (L x W x H) 240 mm x 380 mm x 675 mm Weight 8.7 kg Filter Types Pre-filter, Multi-function, HEPA, Activated Carbon Clean Air Delivery Rate (CADR) Rating;... -
Page 4: Safety Warnings
4. Do not use the appliance if the plug, the power cable or the appliance itself is damaged. contact your Clarke dealer or similarly qualified persons to replace it in order to avoid a hazard. - Page 5 17. Do not use near gas appliances, heaters or fireplaces. 18. Always unplug the appliance after use and before you clean it. 19. Do not use in a room with major temperature changes as this may cause condensation inside the appliance. 20.
-
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 7: The Control System
OVERVIEW THE FILTRATION SYSTEM The air purifier uses a multi-stage filtration system to achieve high air quality: STAGE 1: PRE-FILTER The pre-filter has been treated with antibacterial substances and captures large particles such as human and pet hair etc. STAGE 2: MULTI-FUNCTION (ANTIBACTERIAL/ANTI-FUNGAL) FILTER The second stage filter captures small particles such as pollen. -
Page 8: Design Features
DESIGN FEATURES Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 9 DESIGN FEATURES DESCRIPTION Control Panel Air Quality sensor outlet Air Quality sensor panel Air Quality sensor inlet Light Sensor Remote control receiver Air Quality display Air inlet (around four sides) Remote controller Handle Plasma filter Air outlet Power cable storage facility Mains power cable Panel on/off interlock switch Activated carbon filter...
-
Page 10: Installing The Filters
INSTALLING THE FILTERS The appliance comes with all filters fitted inside, but you must remove the packaging from each one before using the appliance. Remove the filters, discard the packaging and re-fit to the appliance as follows: NOTE: Make sure you insert each filter in the correct position. 1. - Page 11 4. Refit the activated carbon filter into the appliance. NOTE: Ensure that the side with the tab is pointing towards you. 5. Refit the HEPA filter into the appliance. NOTE: Ensure that the side with the tab is pointing towards you. 6.
-
Page 12: Accessory Storage
8. To re-attach the front panel, insert the bottom hooks into the bottom of the appliance, then press the panel against the body of the appliance. • The appliance will not operate without the front panel in its correct position. ACCESSORY STORAGE POWER CABLE STORAGE 1. -
Page 13: Control Panel Operation
CONTROL PANEL OPERATION When the appliance is plugged into the power socket, the POWER button (A) lights up in red. Press the POWER button to start the appliance and the light will change to blue. Press again to return to the standby mode. -
Page 14: Remote Control Operation
REMOTE CONTROL OPERATION All the controls on the machine control panel are replicated on the remote control unit with the addition of the Auto-Mode (J). Press this button to select AUTO-MODE. When the Air Quality indicator flashes, the filters are becoming blocked and need replacement. -
Page 15: Air Quality Indication
When set in AUTO mode, the appliance will switch to NIGHT or DAY Mode automatically, (DAY Mode by default) according to the light level in the room. When the light in the room is beginning to fade for more than 3 minutes, the appliance will switch to Night Mode. -
Page 16: Adjusting The Air Quality Sensor Sensitivity
ADJUSTING THE AIR QUALITY SENSOR SENSITIVITY The appliance allows you to adjust the sensitivity of the air quality sensor for the benefit of people with allergies or asthma. When it is set to a higher sensitivity level, the appliance starts cleaning the air at lower pollution levels to make the air cleaner. -
Page 17: Maintenance
MAINTENANCE WARNING: ALWAYS UNPLUG THE APPLIANCE BEFORE PERFORMING ANY CLEANING OR MAINTENANCE OPERATIONS. CLEANING Regularly clean the body of the appliance to prevent dust from collecting. 1. Wipe away dust with a soft dry cloth from the body and air inlet area of the appliance. -
Page 18: Filter Replacement
FILTER REPLACEMENT This appliance is equipped with a feature to ensure that the filters are in good condition when the appliance is operating. When one of the filters is almost full and has to be cleaned or replaced, the ‘Air Quality’ light starts to flash. If you do not replace the Multi-function, HEPA and Activated Carbon filters, the appliance stops operating and is locked off. -
Page 19: Replacing The Filters And Resetting The Appliance
As a result, the ‘Air Quality’ will start flashing and the appliance be locked off far too soon. REPLACEMENT FILTERS Replacement filters are available from your local Clarke dealer as: • YEAP24004 - Front Pre-filter • YEAP24005 - Multi-Function filter •... -
Page 20: Troubleshooting
TROUBLESHOOTING Problem Solution No operation. One or more of the filters have not been replaced, such that the appliance is now locked and must be reset following the installation of the new filter(s). No air coming from the outlet. Appliance is not switched on or plugged in. The fan speed does not If the room becomes dark, the night mode change when the AUTO mode... -
Page 21: Component Part List
Problem Solution If the system has been re-set, the buzzer will sound and the light on the air quality sensor will indicate that the reset has been successful. COMPONENT PART LIST NO DESCRIPTION NO DESCRIPTION Front Panel Air Quality Sensor Cover Front Panel Frame Air Quality Sensor Sponge Magnetic Tablet 1... -
Page 22: Component Parts
COMPONENT PARTS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 23: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
