Summary of Contents for Sit & Shower 3007
- Page 1 USER MANUAL MODEL 3007...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION....................3 IMPORTANT SAFETY INSTRUCTIONS ….............. 3 INSTALLATION INSTRUCTIONS ................6 OPERATING INSTRUCTIONS ................11 CARE AND MAINTENANCE ................ 14 TECHNICAL SPECIFICATIONS ................ 15... -
Page 3: Introduction
INTRODUCTION In this user manual, you will find information and advice for using, operating and maintaining Sit & Shower. Sit & Shower is designed for homecare and inpatient purposes. Sit & Shower is to be used exclusively for assistance during showering, bathing or using a toilet. Sit & Shower is not designed for long periods of sitting. - Page 4 6. WARNING: Only allow children to use the appliance without supervision when adequate instructions have been given so that the child is able to use the appliance in a safe way and understands the hazards of improper use. 7. Never drop or insert any object into any opening of the device. 8.
- Page 5 23. CAUTION: Do NOT disinfect the device when it is occupied otherwise injury may occur. 24. ALWAYS wear gloves, protective apron, and face shield protection when disinfecting or cleaning the device. 25. ALWAYS handle disinfectants, cleaning compounds, and powdered sanitizers with extreme care.
-
Page 6: Installation Instructions
44. To obtain additional or electronic copies of the manual; please email info@sitnshower.com 45. The device should be installed above a toilet such that the central hole of the device is aligned with the center of the toilet bowl. 46. To clean the device, please utilize the regular disinfection cycle and follow up with a gentle wash with a mild detergent or disinfecting cleaner. - Page 7 Before installation, please ensure the power socket in your place can fulfill this product’s requirement and ‘ground’ it correctly. If it cannot be ensured, please find a qualified electrician to confirm. Switch of the power supply before connecting the transformer. The transformer should be installed on the ceiling or away from any source of water and at least 2 meters above floor or put on top of the false ceiling.
- Page 8 INSTALLATION OF PRODUCT CONNECTION OF WATER SUPPLY ● Before installing the water inlet pipe, make sure the original water faucets are uninstalled and the water inlet valves are closed. ● From the back view of the device, the pipe on the left hand side is hot water inlet pipe, the pipe on the right hand side is cold water inlet pipe.
- Page 9 2. CONNECT THE 13A 220V POWER SOCKET Reminder: Before connecting power to the power socket, it is highly recommended that all electricity supply is shut off and that an independent switch for the power socket is installed beforehand...
- Page 10 DEVICE TESTING 1. TURN ON THE MAIN POWER SUPPLY AND THE WATER INLET VALVES 2. TURN ON THE DEVICE When the device is turned on, you can hear two long beeps and two short beeps sound. And the display on remote control will be blinking. 3.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS PREPARATION Open hot and cold water supplies and water heater, ensure they operate properly. Please allow enough time for heating up water before using Sit & Shower if you are using storage tank water heater. Warm up the device every time before showering or if the device has not been used for a while. - Page 12 ①：temperature & info display Open hot and cold water supplies and water heater. If you are using storage tank heater, please allow enough time for heating up water before using Sit & Shower. Ensure the shower gel and shampoo bottles contains enough shower get and shampoo for shower.
- Page 13 b. Extra features selection： selected features will be included in shower program. “Hair wash ” i. Press ⑥ 洗髮 once to select/deselect hair nozzles 1. Hair wash button light is on: hair nozzles are selected 2. Hair wash button light is off: hair nozzles are unselected ii.
-
Page 14: Care And Maintenance
CARE AND MAINTENANCE The device requires regular inspection. Check the device frequently for rips or tearing, breakage, holes or lost parts and/or non-functioning parts. Check all nuts and bolts are present and secured and any straps are in a good state of repair. Remove dirt and grease from the castors and check that the brakes are working effectively. -
Page 15: Technical Specifications
2. Stop spraying and leave device wet for contact with the sanitizer 3. Rinse off sanitizer with water During the auto-disinfection cycle, device will keep beeping for warning user the disinfection function is on. WARNING: To avoid eye or skin irritation, Do NOT be anywhere near the device during auto-disinfection cycle. - Page 16 Voltage 12V 5A Water supply G1/2 tube LIMITED WARRANTY Automation for Humanity Limited (the “Company”) provides limited warranty to the original purchaser of this Product against defects in material or workmanship for a period of 365 days from the initial date of delivery. If this Product is determined to be defective, the Company will repair or replace the Product, at its sole discretion, at no additional charge.
- Page 17 First name Last Name Address line 1 Address line 2 Country Email Product serial number Purchase date The product comes with a user manual that provides instructions on how to use, operate and maintain the device. Please make sure you understand the instructions. If necessary, refer to the Sit &...
